Although plenty of the impact of precipitation hardening is misplaced with growing temperature over 1300 Degree F, warmness-treated material has beneficial power as much as 1800 Degree F. Monel Alloy Eccentric Reducer Pipe Fittings additionally has extremely good properties right all the way down to cryogenic temperatures. Depending at the software and the properties desired, numerous warmness remedies are employed.
For carrier above 1100 Degree F, mainly in which hundreds are to be sustained for lengthy times, optimum properties are performed through answer treating (2100 Degree F) plus stabilization treating (1550 Degree F) plus precipitation treating (1300 Degree F). For carrier under 1100 Degree F, Hastelloy Alloy Eccentric Reducer Pipe Fittings might also additionally through precipitation treating after warm or cold working or through precipitation treating after equalizing or answer treating. A furnace-cooling remedy is likewise used to expand optimum properties for some applications.
Specification Chart of Eccentric Reducer
Dimensions |
ASME B16.25, B16.28, MSS-SP-43, ANSI/ASME B16.9 |
Fabricated Size |
1/2" (15 NB) to 48" (1200NB) |
Seamless Size |
1/2"~24" |
Thickness |
5s, 10s, 40s, 80s, 10, 20, 40, STD, 60, 80, XS, 100, 120, 140, 160, XXS available with NACE MR 01-75 |
Schedule |
SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS |
Type |
Welded, Seamless, Fabricated |
Material Grades Of Eccentric Reducer
Stainless Steel Eccentric Reducer |
ASTM A403 WP316, 316L, WP304, 304L, ASTM A182 F316L, 304L, 304H, 309, 310, 316, 316L, 317L, 321, 347, 904L, DIN 1.4301, DIN1.4306, DIN 1.4401, DIN 1.4404 |
Alloy Steel Eccentric Reducer |
ASTM A234, ASME SA234 WP1, WP5, WP9, WP11, WP22, WP91 |
Super Duplex Eccentric Reducer |
ASTM A815 / ASME SA815 UNS No S32750, S32950 |
Duplex Steel Eccentric Reducer |
ASTM A815 / ASME SA815 UNS No S31803, S32205 |
Nickel Alloy Eccentric Reducer |
ASTM B336, ASME SB336, Nickel 200 (UNS N02200), Nickel 201 (UNS N02201), Monel 400 (UNS N04400), Monel 500 (UNS N05500), Inconel 800 (UNS N08800), Inconel 825 (UNS N08825), Inconel 600 (UNS N06600), Inconel 625 (UNS N06625), Inconel 601 (UNS N06601), Hastelloy C 276 (UNS N10276), Titanium (Grade I & II), Alloy 20 (UNS N08020), Cupro Nickel 70/30, CuNi30Mn1Fe, CuNi10Fe1Mn. |
Carbon Steel Eccentric Reducer |
ASTM A234, ASME SA234 WPB , WPBW, WPHY 42, WPHY 46, WPHY 52, WPH 60, WPHY 65 & WPHY 70. |
Low Temperature Carbon Steel Eccentric Reducer |
ASTM A420 WPL3, A420 WPL6 |
View Thickness Table Of Welded Eccentric Reducer, We have Global sales network for Buttweld Reducer, Wide Stockist Of Eccentric Pipe Reducer, Buttweld Reducer In India.
Eccentric Reducer Dimensions
REDUCERS |
inches |
mm |
D |
d |
H |
3/4 x 3/4 |
20 x 15 |
26,67 |
21,34 |
38,10 |
3/4 x 3/8 |
20 x 10 |
26,67 |
17,14 |
38,10 |
1 x 3/4 |
25 x 20 |
33,40 |
26,67 |
50,80 |
1 x 1/2 |
25 x 15 |
33,40 |
21,34 |
50,80 |
1 1/4 x 1 |
32 x 25 |
42,16 |
33,40 |
50,80 |
1 1/4 x 3/4 |
32 x 20 |
42,16 |
26,67 |
50,80 |
1 1/4 x 1/2 |
32 x 15 |
42,16 |
21,34 |
50,80 |
1 1/2 x 1 1/4 |
40 x 32 |
48,26 |
42,16 |
63,50 |
1 1/2 x 1 |
40 x 25 |
48,26 |
33,40 |
63,50 |
1 1/2 x 3/4 |
40 x 20 |
48,26 |
26,67 |
63,50 |
1 1/2 x 1/2 |
40 x 15 |
48,26 |
21,34 |
63,50 |
2 x 1 1/2 |
50 x 40 |
60,32 |
48,26 |
76,20 |
2 x 1 1/4 |
50 x 32 |
60,32 |
42,16 |
76,20 |
2 x 1 |
50 x 25 |
60,32 |
33,40 |
76,20 |
2 x 3/4 |
50 x 20 |
60,32 |
26,67 |
76,20 |
2 1/2 x 2 |
65 x 50 |
73,02 |
60,32 |
88,90 |
2 1/2 x 1 1/2 |
65 x 40 |
73,02 |
48,26 |
88,90 |
2 1/2 x 1 1/4 |
65 x 32 |
73,02 |
42,16 |
88,90 |
2 1/2 x1 |
65 x 25 |
73,02 |
33,40 |
88,90 |
3 x 2 1/2 |
80 x 65 |
88,90 |
73,02 |
88,90 |
3 x 2 |
80 x 50 |
88,90 |
60,32 |
88,90 |
3 x 1 1/2 |
80 x 40 |
88,90 |
48,26 |
88,90 |
3 x 1 1/4 |
80 x 32 |
88,90 |
42,16 |
88,90 |
3 1/2 x 3 |
90 x 80 |
101,60 |
88,90 |
101.60 |
3 1/2 x 2 1/2 |
90 x 65 |
101,60 |
73,02 |
101.60 |
3 1/2 x 2 |
90 x 50 |
101,60 |
60,32 |
101.60 |
3 1/2 x 1 1/2 |
90 x 40 |
101,60 |
48,26 |
101.60 |
3 1/2 x 1 1/4 |
90 x 32 |
101,60 |
42,16 |
101.60 |
4 x 3 1/2 |
100 x 90 |
114,30 |
73,02 |
101.60 |
4 x 3 |
100 x 80 |
114,30 |
88,90 |
101.60 |
4 x 2 1/2 |
100 x 65 |
114,30 |
73,02 |
101.60 |
4 x 2 |
100 x 50 |
114,30 |
60,32 |
101.60 |
4 x 1 1/2 |
100 x 40 |
114,30 |
48,26 |
101.60 |
5 x 4 |
125 x 100 |
141,30 |
114,30 |
127,00 |
5 x 3 1/2 |
125 x 90 |
141,30 |
101,60 |
127,00 |
5 x 3 |
125 x 80 |
141,30 |
88,90 |
127,00 |
5 x 2 1/2 |
125 x 65 |
141,30 |
73,02 |
127,00 |
5 x 2 |
125 x 50 |
141,30 |
60,32 |
127,00 |
6 x 5 |
150 x 125 |
168,27 |
141,30 |
139,7 |
6 x 4 |
150 x 100 |
168,27 |
114,30 |
139,7 |
6 x 1/2 |
150 x 90 |
168,27 |
101,60 |
139,7 |
6 x 3 |
150 x 80 |
168,27 |
88,90 |
139,7 |
6 x 1/2 |
150 x 65 |
168,27 |
73,02 |
139,7 |
8 x 6 |
200 x 150 |
219,07 |
168,27 |
152,4 |
8 x 5 |
200 x 125 |
219,07 |
141,30 |
152,4 |
8 x 4 |
200 x 100 |
219,07 |
114,30 |
152,4 |
8 x 3 1/2 |
200 x 90 |
219,07 |
101,60 |
152,4 |
10 x 8 |
250 x 200 |
273,05 |
219,07 |
177,8 |
10 x 6 |
250 x 150 |
273,05 |
168,27 |
177,8 |
10 x 5 |
250 x 125 |
273,05 |
141,30 |
177,8 |
10 x 4 |
250 x 100 |
273,05 |
114,30 |
177,8 |
12 x 10 |
300 x 250 |
323,85 |
273,05 |
203,2 |
12 x 8 |
300 x 200 |
323,85 |
219,07 |
203,2 |
12 x 6 |
300 x 150 |
323,85 |
168,27 |
203,2 |
12 x 5 |
300 x 125 |
323,85 |
141,30 |
203,2 |
14 x 12 |
350 x 300 |
355,60 |
323,85 |
330,2 |
14 x 10 |
350 x 250 |
355,60 |
273,05 |
330,2 |
14 x 8 |
350 x 200 |
355,60 |
219,07 |
330,2 |
14 x 6 |
350 x 150 |
355,60 |
168,27 |
330,2 |
16 x 14 |
400 x 350 |
406,40 |
355,60 |
355,6 |
16 x 12 |
400 x 300 |
406,40 |
323,85 |
355,6 |
16 x 10 |
400 x 250 |
406,40 |
273,05 |
355,6 |
16 x 8 |
400 x 200 |
406,40 |
219,07 |
355,6 |
18 x 16 |
450 x 400 |
457,20 |
406,40 |
381,0 |
18 x 14 |
450 x 350 |
457,20 |
355,60 |
381,0 |
18 x 12 |
450 x 300 |
457,20 |
323,85 |
381,0 |
18 x 10 |
450 x 250 |
457,20 |
273,05 |
381,0 |
20 x 18 |
500 x 450 |
508,00 |
457,20 |
508,0 |
20 x 16 |
500 x 400 |
508,00 |
406,40 |
508,0 |
20 x 14 |
500 x 350 |
508,00 |
355,60 |
508,0 |
20 x 12 |
500 x 300 |
508,00 |
323,85 |
508,0 |
22 x 20 |
550 x 500 |
558,80 |
508,00 |
508,0 |
22 x 18 |
550 x 450 |
558,80 |
457,20 |
508,0 |
22 x 16 |
550 x 400 |
558,80 |
406,40 |
508,0 |
22 x 14 |
550 x 350 |
558,80 |
355,60 |
508,0 |
24 x 22 |
600 x 550 |
609,6 |
558,80 |
508,0 |
24 x 20 |
600 x 500 |
609,6 |
508,00 |
508,0 |
24 x 18 |
600 x 450 |
609,6 |
457,20 |
508,0 |
24 x 16 |
600 x 400 |
609,6 |
406,40 |
508,0 |
Check available Sizes of Eccentric Reducer, Ask For Ready Stock of Eccentric Pipe Reducer, Welded Eccentric Reducer. Eccentric Reducer in Mumbai, India.
