It is the free-machining grade. It’s more sulfur content material complements machinability. It has basically the equal corrosion resistance and physical properties as different alloys, however a barely unique variety of mechanical properties. Monel Alloy Pipe Nipples is an alloy which mixes the extremely good corrosion resistance with the brought blessings of more strength and hardness. The increased properties are acquired with the aid of using including aluminum and titanium to the nickel-copper base, and with the aid of using heating below managed situations in order that submicroscopic debris of Ni3 (Ti, Al) are brought on at some point of the matrix.
It is used mainly for automated screw device inventory and isn't normally endorsed for different applications.Typical applications for these Hastelloy Alloy Pipe Nipples Pipe Fittings are chains and cables, fasteners and is derived for marine service; pump and valve additives for chemical processing; physician blades and scrapers for pulp processing in paper production; oil nicely drill collars and instruments, pump shafts and impellers, non-magnetic housings, protection lifts and valves for oil and fueloline production; and sensors and different digital additives.It is broadly used in lots of fields, in particular marine and chemical processing.And so the thermal processing used to impact precipitation is normally known as age hardening or aging.
Specification Chart of Pipe Nipple
| Dimensions |
ASME B16.25, B16.28, MSS-SP-43, ANSI/ASME B16.9 |
| Fabricated Size |
1/2" (15 NB) to 48" (1200NB) |
| Seamless Size |
1/2"~24" |
| Thickness |
5s, 10s, 40s, 80s, 10, 20, 40, STD, 60, 80, XS, 100, 120, 140, 160, XXS available with NACE MR 01-75 |
| Schedule |
SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS |
| Type |
Welded, Seamless, Fabricated |
Material Grades Of Pipe Nipple
| Stainless Steel Pipe Nipple |
ASTM A403 WP316, 316L, WP304, 304L, ASTM A182 F316L, 304L, 304H, 309, 310, 316, 316L, 317L, 321, 347, 904L, DIN 1.4301, DIN1.4306, DIN 1.4401, DIN 1.4404 |
| Alloy Steel Pipe Nipple |
ASTM A234, ASME SA234 WP1, WP5, WP9, WP11, WP22, WP91 |
| Super Duplex Pipe Nipple |
ASTM A815 / ASME SA815 UNS No S32750, S32950 |
| Duplex Steel Pipe Nipple |
ASTM A815 / ASME SA815 UNS No S31803, S32205 |
| Nickel Alloy Pipe Nipple |
ASTM B336, ASME SB336, Nickel 200 (UNS N02200), Nickel 201 (UNS N02201), Monel 400 (UNS N04400), Monel 500 (UNS N05500), Inconel 800 (UNS N08800), Inconel 825 (UNS N08825), Inconel 600 (UNS N06600), Inconel 625 (UNS N06625), Inconel 601 (UNS N06601), Hastelloy C 276 (UNS N10276), Titanium (Grade I & II), Alloy 20 (UNS N08020), Cupro Nickel 70/30, CuNi30Mn1Fe, CuNi10Fe1Mn. |
| Carbon Steel Pipe Nipple |
ASTM A234, ASME SA234 WPB , WPBW, WPHY 42, WPHY 46, WPHY 52, WPH 60, WPHY 65 & WPHY 70. |
| Low Temperature Carbon Steel Pipe Nipple |
ASTM A420 WPL3, A420 WPL6 |
View Thickness Table Of Welded Pipe Nipples, We have Global sales network for Buttweld Pipe Nipple, Wide Stockist Of Pipe Nipples, Concentric Pipe Nipple In India.
Pipe Nipple Dimensions
| I.D. or Nominal Size |
Outside Diameter |
Length |
| NU |
EUE |
NU |
EUE
| 1/8 |
-- |
-- |
-- |
-- |
| 1/4 |
.540 |
-- |
2 1/4 |
-- |
| 3/8 |
.675 |
-- |
2 1/2 |
-- |
| 1/2 |
.840 |
-- |
2 3/4 |
-- |
| 3/4 |
1.050 |
-- |
3 |
-- |
| 1 |
1.315 |
1.469 |
3 1/2 |
4 1/2 |
| 1 1/4 |
1.660 |
1.812 |
4 |
6 |
Check available Sizes of Pipe Nipple, Ask For Ready Stock of Pipe Nipple, Welded Pipe Nipple. Pipe Nipple in Mumbai, India.
