Alloy 20 Fasteners

Carpenter 20 Bolts, Alloy 20 Fasteners In Indonesia, Incoloy® Alloy 20 Stud Bolts In Malaysia, ASTM B366 Alloy 20 Washers, Alloy 20 Nuts Price in India.

Bagoda Steel is a popular trader and manufacturer of Alloy 20 Fasteners, which is an alloy that became evolved for max resistance to acid attack, in particular sulphuric acid. Chromium is the major agent for conferring corrosion resistance in impartial or oxidizing environments. Chromium, molybdenum and nitrogen boom resistance to pitting corrosion. Nickel imparts the austenitic structure. Nickel and molybdenum each offer extended resistance to chloride strain corrosion cracking in lowering environments. Alloy 20Cb3 Fasteners gives an Excellent resistance to pitting and crevice corrosion in chloride solutions, Practical immunity to strain corrosion in NaCl environments, at the side of High Strength and toughness. It is nitrogen more advantageous steel that turned into evolved to fight not unusual place corrosion issues encountered with the collection steels.

Industrial Product
Alloy 20 fasteners

2.4660 Nuts, Alloy 20 Hex Bolts, Alloy 20 Flat Washers, UNS N08020 Allen Cap Screw, Alloy 20CB-3® Screws, Alloy 20 Anchor Bolts, Incoloy® Alloy 20 Carriage Bolts Stockist, Carpenter 20Cb-3® Threaded Rod Supplier in Mumbai, India.

+91 22 - 66151721
sales@bagodasteelproject.com
+91 9011334411

It is regularly utilized in Reverse osmosis desalination system and pumps; FGD Scrubbers; Chemical system tanks and pipelines; Seawater warmth exchangers; Tall oil distillation columns and packing; Offshore oil and fueloline manufacturing system; Pulp bleaching plant washers, vats, press rolls and pipelines; etc. This superalloy has notable resistance to popular corrosion, pitting, and crevice corrosion in chemical substances containing chlorides and sulphuric, phosphoric, and nitric acids. UNS N08020 Fasteners additionally consists of niobium for stabilization towards sensitization and resultant intergranular corrosion. Although at the start designed to be used in sulphuric acid associated industries, it's far now a famous preference for a huge form of industries such as the chemical, food, pharmaceutical, and plastics industries.

In addition, this superalloy is utilized in warmth exchangers, blending tanks, steel cleansing and pickling system, and piping. WNR 2.4660 Fasteners combines notable corrosion resistance with improved mechanical properties and comparatively cleans fabrication. It gives an Excellent fashionable corrosion resistance to sulphuric acid, Excellent resistance to chloride pressure corrosion cracking, and Excellent mechanical properties and fabricability. It is meant for usage of metallic need to be constrained to temperatures underneath 600 Degree F. The shape of metallic includes austenite swimming pools surrounded via way of means of a non-stop ferrite phase. They are acknowledged for its Minimal carbide precipitation throughout welding, and Excels in resisting corrosion to warm sulphuric acids.

Material Specification Chart of Alloy 20 Fasteners

Standard ASTM B366, ASME SB366,
Size M 02 to M 33
Length 3 mm to 200 mm
Threads: METRIC, BSW, BSF, UNC, UNF or as required
Standard: DIN, ISO, JIS, GB, IS, BS, ASTM, ANSI – American National Standards Institute
  • ANSI B 18.2.4 2M
  • ANSI B 28.2.4 1M
  • Stud Bolt length are defined in ASME B16.5 standard
  • Hex nuts are defined in ASME B18.2.2
  • ASME B18.5
  • BS en iso 3506

DIN: DIN 931, DIN 933, DIN 934, DIN 970

UTS – Unified Thread Standard : UNC, UNF, UNEF, UNS, NPT, NPTF

ISO – International Organization for Standardization : ISO 4032, ISO 4033, JIS standards
Scope of Manufacturer
  • Up to M36 / 1-1/2” Dia, up to 1100mm lg
  • CNC Machined Fasteners, up to M100 / 4” Dia, up to 1500mm lg
Dia M6 to M64 (1/4" - 2.5")
Length 12 MM - 500 MM (Upto 20 Inch)
IS 1363, 1364
DIN 931, 933
ISO ISO 3506
Form of: Hex, Square, Round, Threading as per Gauge Etc.
Head Drive: Phillips, Slotted, Phillips/Slot, Six-Lobe, etc
Test Certificate: Manufacturer Test Certificate as per EN 10204 / 3.1
Finishing: Zinc (yellow, white, blue, black), black oxide, , Geometry, Dacroment, anodizing, nickel plated, plated zinc-nickel, Passivated, Self-Colour, Hot Dip Galvanised (HDG), Bright Zinc Plated (BZP), Sherardized, Mechanically Applied coating and some special one like DACROMET
Production Process M2-M24: Cold Froging, hot forging M24-M100, , machining and CNC for Customized connecting element
Types Nuts, Bolts, Screws, Socket Screw, Sockets, Studs, Screw, Nut, Spring Washers, Hex Set Screw, Socket Hexagon Head Screw, Cap Screw, Wing Screw, Pan Head Screw, Machine Screw, Socket Head Cap Screw, Allen Cap screw, Wing Screw, Washers, Studs, Anchors, Hex Nut,Marine Anchors, Hexagon Nut, Hex Coupling Nut, Hex Domed Cap Nuts, Square Nut, Stud Bolts, Hex Head Bolts, Anchor Bolt, U- Bolts, J Bolts, T-Head Bolts, Mushroom Head Square Neck Bolts, Eye Bolt, Foundation Bolts, Structural Bolts

ANSI and/or ASME Standards (inch series)

ASME B18.1.1 Small Solid Rivets ASME B18.8.1 Clevis Pins and Cotter Pins
ASME B18.1.2 Large Rivets ASME B18.8.2 Taper Pins, Dowel Pins, Straight Pins, Grooved Pins and Spring Pins
ASME B18.2.1 Square and Hex Bolts and Screws ASME B18.9 Plow Bolts
ASME B18.2.2 Square and Hex Nuts ASME B18.10 Track Bolts and Nuts
ASME B18.2.6 Fasteners for use in Structural Applications ASME B18.11 Miniature Screws
ASME B18.3 Socket Cap, Shoulder and Set Screws ASME B18.13 Screws and Washer Assemblies (Sems)
ASME B18.5 Round Head Bolts ASME B18.15 Forged Eyebolts
ASME B18.6.2 Slotted Head Cap Screws, Square Head Set Screws, and Slotted Headless Set Screws ASME B18.17 Wing Nuts, Thumb Screws and Wing Screws
ASME B18.6.3 Machine Screws and Machine Screws Nuts ASME B18.21.1 Lock Washers
ASME B18.6.4 Thread Forming and Thread Cutting Tapping Screws and Metallic Drive Screws ASME B18.22.1 Plain Washers
ASME B18.7 General Purpose Semi- Tubular Rivets, Full Tubular Rivets, Split Rivets and Rivet Caps ASME B18.23.1 Beveled Washers

Various Types Of Alloy 20 Fasteners

Alloy 20 Bolts
Alloy 20 Bolts
  • 2.4660 Heavy Hex Bolts
  • Alloy 20 Hex Bolts In Indonesia
  • UNS N08020 Flange Bolts
  • Alloy 20CB-3® Bolts In Malaysia
  • ASME SB366 Alloy 20 Bolts
  • ASTM B366 Carpenter 20 Bolts
Alloy 20 Nuts
Alloy 20 Nuts
  • ASTM B366 Alloy 20 Nuts
  • 2.4660 Heavy Hex Nuts In Philippines
  • En NiCr20CuMo Wing Nuts
  • ASME SB366 Carpenter 20Cb-3® Nuts
  • Alloy 20 Hex Nuts In Mexico In Japan
  • UNS N08020 Nuts
Alloy 20 Screw
Alloy 20 Screw
  • Alloy 20 Screw In Italy
  • ASME SB366 Alloy 20CB-3® Screw
  • Alloy 20 Allen Cap Screw In Spain
  • 2.4660 Hex Cap Screws
  • ASTM B366 Incoloy® Alloy 20 Screw
  • UNS N08020 Socket Set Screws
Alloy 20 Washers
Alloy 20 Washers
  • Alloy 20 Washers In Kuwait
  • ASTM B366 Carpenter 20 Washers
  • UNS N08020 Lock Washers
  • Alloy 20 Flat Washer In Singapore
  • ASME SB366 En NiCr20CuMo Washers
  • 2.4660 Beveled Washers
Alloy 20 Threaded Rods
Alloy 20 Threaded Rods
  • Alloy 20 Threaded Rods In Indonesia
  • UNS N08020 Threaded Rods
  • ASME SB366 Incoloy® Alloy 20 Threaded Rods
  • ASTM B366 ALLOY 20CB-3® Threaded Rods
  • Alloy 20 Threaded Rods In Singapore
  • 2.4660 Threaded Rods
Alloy 20 Stud Bolts
Alloy 20 Stud Bolts
  • ASTM B366 En NiCr20CuMo Stud Bolts
  • Carpenter 20 Tie Rods In Malaysia
  • UNS N08020 Stud Bolts
  • 2.4660 Stud Bolts
  • ASME SB366 Alloy 20 Stud
  • Alloy 20 Stud Bolts In Spain
Alloy 20 Anchor Bolts
Alloy 20 Anchor Bolts
  • Alloy 20 Anchor Bolts In Mexico
  • 2.4660 J Anchor Bolts
  • ASME SB366 Incoloy® Alloy 20 Self Tapping Anchor
  • Carpenter 20Cb-3® Wedge Anchor Bolt In Spain
  • ASTM B366 Alloy 20 Anchor Bolts
  • UNS N08020 Concrete Anchors

Equivalent Grades of Alloy 20 Fasteners

STANDARD  WERKSTOFF NR. UNS AFNOR EN
Alloy 20 2.4660 N08020 Z2NCUD31-20AZ NiCr20CuMo
Fasteners Dimensions

View Size Table Of Alloy 20 Fasteners, We have Global sales network for Carpenter 20 Stud Bolts, Wide Stockist Of Werkstoff No 2.4660 Nuts, Bolts, Washers In India.

Size Chart of Alloy 20 Bolts

Nominal or Basic Product Diameter E F G H J LT (Thread Length) Y
Body Diameter Width Across Flats Width Across Corners Head Height Wrenching Height For Screw Lengths For Screw Lengths Transition Thread Length
1/4 0.25 0.25 0.245 7/16 0.438 0.428 0.505 0.488 5/32 0.163 0.150 0.106 0.750 1.000 0.250
5/16 0.3125 0.3125 0.3065 1/2 0.500 0.489 0.577 0.557 13/64 0.211 0.195 0.140 0.875 1.125 0.278
3/8 0.375 0.375 0.369 9/16 0.562 0.551 0.650 0.628 15/64 0.243 0.226 0.160 1.000 1.250 0.312
7/16 0.4375 0.4375 0.4305 5/8 0.625 0.612 0.722 0.698 9/32 0.291 0.272 0.195 1.125 1.375 0.357
1/2 0.5 0.5 0.493 3/4 0.750 0.736 0.866 0.840 5/16 0.323 0.302 0.215 1.250 1.500 0.385
9/16 0.5625 0.5625 0.5545 13/16 0.812 0.798 0.938 0.910 23/64 0.371 0.348 0.250 1.375 1.625 0.417
5/8 0.625 0.625 0.617 15/16 0.938 0.922 1.083 1.051 25/64 0.403 0.378 0.269 1.500 1.750 0.455
3/4 0.75 0.75 0.741 1-1/8 1.125 1.100 1.299 1.254 15/32 0.483 0.455 0.324 1.750 2.000 0.500
7/8 0.875 0.875 0.866 1-5/16 1.312 1.285 1.516 1.465 35/64 0.563 0.531 0.378 2.000 2.250 0.556
1 1 1 0.99 1-1/2 1.500 1.469 1.732 1.675 39/64 0.627 0.591 0.416 2.250 2.500 0.625
1-1/8 1.125 1.125 1.114 1-11/16 1.688 1.631 1.949 1.859 11/16 0.718 0.658 0.461 2.500 2.750 0.714
1-1/4 1.25 1.25 1.239 1-7/8 1.875 1.812 2.165 2.066 25/32 0.813 0.749 0.530 2.750 3.000 0.714
1-1/2 1.5 1.5 1.488 2-1/4 2.250 2.175 2.598 2.480 15/16 0.974 0.902 0.640 3.250 3.500 0.833

Check available Sizes of ASME SB 366 Alloy 20 Stud Bolt, Ask For Ready Stock of UNS N08020 Fasteners in Mumbai, India.

BAGODA

Quick Contact

Alloy 20 Washer Weight & Dimensions

Bolt Size A B C Weight (lbs.) Per 100 Pieces
ID OD Thickness
1/2 9/16 13/8 0.109 4
5/8 11/16 13/4 0.134 8
3/4 13/16 2 0.148 11
7/8 15/16 21/4 0.165 15
1 11/16 21/2 0.165 19
11/8 11/4 23/4 0.165 22
11/4 13/8 3 0.165 26
13/8 11/2 31/4 0.180 33
11/2 15/8 31/2 0.180 38
15/8 13/4 33/4 0.180 43
13/4 17/8 4 0.180 50
17/8 2 41/4 0.180 57
2 21/8 41/2 0.180 63
21/4 23/8 43/4 0.220 83
21/2 25/8 5 0.238 96
23/4 27/8 51/4 0.259 110
3 31/8 51/2 0.284 130

Alloy 20 Stud Bolt Size Chart

Class 150 Flanges ASME B16.5 (Stud bolt sizes) Length of Stud Bolts
NPS Outside Diameter of Flange The diameter of Bolt Circle The diameter of Bolt Holes Number of Bolts Diameter of Bolts Raised Face
0.06 in		 Ring Joint
1/2 3 1/2 2 3/8 5/8 4 1/2 2 1/4 –
3/4 3 7/8 2 3/4 5/8 4 1/2 2 1/2 –
1 4 1/4 3 1/8 5/8 4 1/2 2 1/2 3
1 1/4 4 5/8 3 1/2 5/8 4 1/2 2 3/4 3 1/4
1 1/2 5 3 7/8 5/8 4 1/2 2 3/4 3 1/4
2 6 4 3/4 3/4 4 5/8 3 1/4 3 3/4
2 1/2 7 5 1/2 3/4 4 5/8 3 1/2 4
3 7 1/2 6 3/4 4 5/8 3 1/2 4
3 1/2 8 1/2 7 3/4 8 5/8 3 1/2 4
4 9 7 1/2 3/4 8 5/8 3 1/2 4
5 10 8 1/2 7/8 8 3/4 3 3/4 4 1/4
6 11 9 1/2 7/8 8 3/4 4 4 1/2
8 13 1/2 11 3/4 7/8 8 3/4 4 1/4 4 3/4
10 16 14 3/4 1 12 7/8 4 1/2 5
12 19 17 1 12 7/8 4 3/4 5 1/4
14 21 18 3/4 1 1/8 12 1 5 1/4 5 3/4
16 23 1/2 21 1/4 1 1/8 16 1 5 1/4 5 3/4
18 25 22 3/4 1 1/4 16 1 1/8 5 3/4 6 1/4
20 27 1/2 25 1 1/4 20 1 1/8 6 1/4 6 3/4
24 32 29 1/2 1 1/4 20 1 1/4 6 3/4 7 1/4
Class 300 Flanges ASME B16.5 Length of Stud Bolts
NPS Outside Diameter of Flange The diameter of Bolt Circle The diameter of Bolt Holes Number of Bolts Diameter of Bolts Raised Face
0.06 in		 Ring Joint
1/2 3 3/4 2 5/8 5/8 4 1/2 2 1/2 3
3/4 4 5/8 3 1/4 3/4 4 5/8 3 3 1/2
1 4 7/8 3 1/2 3/4 4 5/8 3 3 1/2
1 1/4 5 1/4 3 7/8 3/4 4 5/8 3 1/4 3 3/4
1 1/2 6 1/8 4 1/2 7/8 4 3/4 3 1/2 4
2 6 1/2 5 3/4 8 5/8 3 1/2 4
2 1/2 7 1/2 5 7/8 7/8 8 3/4 4 4 1/2
3 8 1/4 6 5/8 7/8 8 3/4 4 1/4 4 3/4
3 1/2 9 7 1/4 7/8 8 3/4 4 1/4 5
4 10 7 7/8 7/8 8 3/4 4 1/2 5
5 11 9 1/4 7/8 8 3/4 4 3/4 5 1/4
6 12 1/2 10 5/8 7/8 12 3/4 4 3/4 5 1/2
8 15 13 1 12 7/8 5 1/2 6
10 17 1/2 15 1/4 1 1/8 16 1 6 1/4 6 3/4
12 20 1/2 17 3/4 1 1/4 16 1 1/8 6 3/4 7 1/4
14 23 20 1/4 1 1/4 20 1 1/8 7 7 1/2
16 25 1/2 22 1/2 1 3/8 20 1 1/4 7 1/2 8
18 28 24 3/4 1 3/8 24 1 1/4 7 3/4 8 1/4
20 30 1/2 27 1 3/8 24 1 1/4 8 8 3/4
24 36 32 1 5/8 24 1 1/2 9 10

Ready Stock Alloy 20 Fasteners

  • Alloy 20 Screws Distributor
  • En NiCr20CuMo Eye Bolts
  • Alloy 20 Heavy Hex Nuts In Spain
  • Alloy 20 Elevator Bolt In Mexico
  • Alloy 20 Lock Nut In Malaysia
  • UNS N08020 Fasteners
  • 2.4660 Fasteners
  • Alloy 20 Bolts In Philippines
  • Alloy 20 Fasteners
  • ASTM B366 Alloy 20 Wing Nuts
  • Alloy 20 Hex Domed Cap Nuts
  • Carpenter 20 Structural Bolts
  • Alloy 20 Hex Set Screw Manufacturer
  • Alloy 20 Stud Bolts In Japan
  • Alloy 20 Hex Head Bolts In Italy
  • Alloy 20 Dock Washer Stockholder
  • Alloy 20CB-3® Wing Nuts
  • Alloy 20 Ogee Washer In Spain
  • Alloy 20 Plain Washer Supplier in Mumbai
  • Alloy 20 Customized Washer
  • Alloy 20 Tooth Lock Washer In Singapore
  • Inconel® Alloy 20 Acorn Nuts
  • En NiCr20CuMo Socket Cap Screw
  • Alloy 20 Hexagonal Washer In Kuwait
  • Alloy 20 T-Head Bolts
  • Inconel® Alloy 20 Foundation Bolts Manufacturer
  • Alloy 20 Washers
  • Alloy 20 Heavy Hex Bolts
  • Alloy 20 Threaded Rod
  • Alloy 20 Coupling Nut
  • Carpenter 20 Anchor Bolts
  • ASME SB366 Alloy 20 Fender Washer
  • Alloy 20 Bolts In Indonesia
  • Alloy 20 Hex Coupling Nut
  • ASTM B366 Alloy 20 Nyloc Nuts
  • ASTM B366 Alloy 20 Fasteners
  • Alloy 20 Square Nuts In Malaysia
  • Alloy 20 Stud Bolts In Mexico
  • Carpenter 20Cb-3® Self Locking Nuts
  • Alloy 20 Tie Rods
  • Alloy 20CB-3® Hex Washers In Philippines
  • Alloy 20 Hex Head Bolt
  • Alloy 20 Machine Fasteners Exporter
  • Alloy 20 Split / Lock Washer In Japan
  • Alloy 20 Carriage Bolt Stockist
  • Alloy 20 Flange Bolt In Kuwait
  • Inconel® Alloy 20 Allen Cap Screw
  • DIN 2.4660 Countersunk Washer
  • Alloy 20 Double Ended Stud In Italy
  • Alloy 20 Concrete Screw In Spain
  • ASTM B366 Alloy 20 Flat Washers
  • Carpenter 20Cb-3® Machine Bolt In Singapore

Alloy 20 Chemical Composition

Grade  Ni Fe C Mn Si Cu Cr Mo S P Nb
Alloy 20 32 – 38 Bal 0.02 max 1 – 2 0.7 max 3 – 4 19 – 21 2 – 3 0.005 max 0.02 max> 0.1 – 0.3

Alloy 20 Fasteners Mechanical Properties

Element  Density Melting Point Tensile Strength Yield Strength (0.2%Offset) Elongation
Alloy 20 8.1 g/cm3 1443 °C (2430 °F) Psi -80,000, MPa -551 Psi – 35,000, MPa – 241 30 %
