ASTM A453 Grade 660 Fasteners, ASTM A453 Gr 660 Class B Bolts, ASTM A453 Gr 660 Nuts Manufacturer

ASTM A453 Grade 660 Carriage Bolts Stockist, ASTM A453 Gr 660 Allen Cap Screw, ASTM A453 Gr 660 Nuts, 1.4944 Threaded Rod, ASTM A453 Gr 660 Class D Screws, ASTM A453 Gr 660 Grade B Flat Washers, ASTM A453 Grade 660 Fasteners, A453 Grade 660 Hex Bolts, ASTM A453 Gr 660 Anchor Bolts Supplier in Mumbai, India.

It is an alloyed metal plate with excessive general, localized and pressure corrosion resistance properties further to excessive strength and remarkable effect toughness. This specific blend of materials makes these fasteners the proper desire for some of extraordinary critical applications in a variety of industries. The shape of these ASTM A453 Grade 660 Bolts includes austenite swimming pools surrounded via way of means of a non-stop ferrite phase. It reveals advanced corrosion resistance in seawater. It is as nicely used for Condenser Plates, Weld Torch Tips, Condensers, Heat Exchanger Tubes, Valve Bodies, and so on.

They are used as sea water condenser structures and desalination vegetation as a result of exact resistance in opposition to sea water corrosion. It may be fabricated via way of means of each warm and cold - working procedures, and is simply weldable. The resistance to soil erosion and abrasive fluids of these fasteners are incomparable withinthe aqueous conditions. ASME SA 453 Grade 660 Washers is used for piping, warmth exchangers and condensers in marine hardware, seawater structures, and every so often for the propellers, crankshafts and hulls of top rate tugboats, fishing boats and different working boats. Overall suitability has because been showed via way of means of persevering with use in these and different marine applications.

Standard Specification For ASTM A453 Gr 660 Fasteners

Specification	ASTM A453, ASME SA453
Standard	DIN, UNI, ISO, JIS, GB, IS, BS, ASME, ANSI, ASTM and all International Standards
Size	M2, M2.5, M3, M4, M5, M6, M8, M10, M12, M14, M16, M20, M24, M30, M36 to M160
Length	3 mm to 200 mm
Threads	METRIC, BSW, BSF, UNC, UNF or as required
Standard	ANSI – American National Standards Institute ANSI B 18.2.4 2M ANSI B 28.2.4 1M ASME B18.2.2 ASME B18.5 DIN: DIN 931, DIN 933, DIN 934, DIN 970 UTS – Unified Thread Standard : UNC, UNF, UNEF, UNS, NPT, NPTF ISO – International Organization for Standardization : ISO 4032, ISO 4033, JIS standards
In Form of	Hex, Square, Round, Threading as per Gauge Etc.
Head drive	Phillips, Slotted, Phillips/Slot, Six-Lobe, etc
Test Certificate:	Manufacturer Test Certificate as per EN 10204 / 3.1
Surface finishing	Zinc (yellow, white, blue, black), black oxide, Geometry, Dacroment, anodizing, nickel plated, plated zinc-nickel, Stainless steel: Passivated Self-Colour, Hot Dip Galvanised (HDG), Bright Zinc Plated (BZP), Sherardized, Stainless Steel, Mechanically Applied coating and some special one like DACROMET
Production process	M2-M24: Cold Froging, hot forging M24-M100, machining and CNC for Customized connecting element
Surface Coating	Teflon Coated Fasteners Phosphate Coated Fasteners Zinc Coated Fasteners Ptfe Coated Xylon Coated Fasteners Cadmium Coated Fasteners Hot Dipped Galvanizing Coated Fasteners All surface finishes offered including Geomet & PTFE, Galvanised, Zinc, Electroless Nickel, Sherardized, Dacromet
Packing	IN BULK: canton, pallet, Small Boxs / carton / pallet, or customer request

ASTM A453 Gr 660 Fasteners Equivalent Grade

AISI	UNS	BS	Wr No.	En Name	DIN EN	JIS	AMS	ASTM		other names	Additional Requirements
660	S 66286	HR 51	1.4944	X6NiCrTiMoV26-15	10269	SUS 660	5726	ASTM A453 GRADE 660A		incoloy a286	NACE MR-0175

Various Types Of ASTM A453 Gr 660 Fasteners

ASTM A453 Gr 660 Bolts

ASTM A453 Grade 660 Hex Bolts
ASTM A453 Grade 660 Bolts
ASTM A453 Gr 660 Bolts
ASTM A453 Gr 660 Heavy Hex Bolts

ASTM A453 Gr 660 Screw

ASTM A453 Gr 660 Allen Cap Screw
ASTM A453 Grade 660 Screw
ASTM A453 Grade 660 q Set Screws
ASTM A453 Gr 660 Screw
ASTM A453 Gr 660 Hex Cap Screws

ASTM A453 Gr 660 Stud Bolts

ASTM A453 Grade 660 Stud Bolts
ASTM A453 Gr 660 Bolts
ASTM A453 Gr 660 Stud Bolts
ASTM A453 Gr 660 Stud

ASTM A453 Gr 660 Hex Bolts

ASTM A453 Gr 660 Hex Bolts
ASTM A453 Gr 660 Hex Head Bolts
ASTM A453 Grade 660 Hex Bolts
ASTM A453 Grade 660 Heavy Hex Bolts

View Size Table Of ASTM A453 Grade 660 Fasteners, We have Global sales network for ASTM A453 Grade 660 Stud Bolts, Wide Stockist Of ASTM A453 Gr 660 Nuts, Bolts, Washers In India.

ASTM A453 Gr 660 Fasteners Standard

Hexagon Bolt / Set Screws	Stud Bolt	Hexagon Nuts	Socket Cap screws
DIN 931	BS4882	DIN 934	DIN 912
DIN 933	DIN 976	BS 1768	DIN 6912
BS 1768		BS 1769	DIN 7984
UNI 5731		BS 1083	ANSI B18.3
UNI 5739		BS 3692	ISO 4762
ISO 4014		ISO 4032	UNI 5931
ISO 4017		ISO 4033	BS 2470
BS 1769		ANSI B18.2.2	BS 4168
BS 3692
ANSI B18.2.1
Socket & Slotted Set Screws	Socket & Slotted Countersunk Screws	Studs	Washers
DIN 913	DIN 963	DIN 938	DIN 125
DIN 914	DIN 7991	DIN 939	DIN 9021
DIN 915	BS 4168	DIN 2510	BS 4320
DIN 916	BS 1981	BS 4439	BS 3410
DIN 551	BS 483	BS 2693
DIN 553	BS 2470		Spring Washers
DIN 438			DIN 127
BS 4168			BS 4464
			BS 1802

Dimensions Of ASTM A453 Gr 660 Bolts

NOMINAL SIZE (D)	BODY DIAMETER		HEAD THICKNEASTM A193		ACROASTM A193 THE FLATS		ACROASTM A193 CORNERS
	D (MAX)	D (MIN)	H (MAX)	H (MIN)	F (MAX)	F (MIN)	C (MAX)	C (MIN)
m10	10.00	9.78	6.63	6.17	17.00	15.73	18.48	17.77
m12	12.00	11.73	7.76	4.24	19.00	17.73	20.78	20.03
m14	14.00	13.73	9.09	8.51	22.00	20.67	24.25	23.35
m16	16.00	15.73	10.32	9.68	24.00	23.67	27.71	26.75
m20	20.00	19.67	12.88	12.12	30.00	29.16	34.64	32.95
m24	24.00	23.67	15.44	14.56	36.00	35.00	41.57	39.55
m30	30.00	29.67	19.48	17.92	46.00	45.00	53.12	50.85
m36	36.00	35.61	23.38	21.63	55.00	53.80	63.51	60.79
m42	42.00	41.38	26.97	25.03	65.00	62.90	75.06	71.71
m48	48.00	47.38	31.07	28.93	75.00	72.60	86.60	82.76
m56	56.00	55.26	36.2	33.80	85.00	82.20	98.15	93.71
m64	64.00	63.26	41.32	38.68	95.00	91.80	109.70	104.65
m72	72.00	71.26	46.45	43.55	105.00	101.40	121.24	115.60
m80	80.00	79.26	51.58	48.42	115.00	111.00	132.72	126.54
m90	90.00	89.13	57.74	54.26	130.00	125.50	150.11	143.07
m100	90.00	99.13	63.9	60.10	145.00	140.00	167.43	159.60

Check available Sizes of ASTM A453 GR 660 Stud Bolt, Ask For Ready Stock of ASTM A453 Grade 660 Fasteners in Mumbai, India.

BAGODA

Quick Contact

Call Us

+91 22 - 66151721

Need Help? Send us Email

sales@bagodasteelproject.com

ASTM A453 Gr 660 Fasteners Torque Chart

Torque Specifications
Bolt Size Inches or #	Threads Per Inch	Standard Dry Torque in Inch-Pounds
Bolt Size Inches or #	Threads Per Inch	ASTM A453 Gr 660	ASTM A453 Gr 660
#2	56	2.5	2.6
#2	64	3.0	3.2
#3	48	3.9	4.0
#3	56	4.4	4.6
#4	40	5.2	5.5
#4	48	6.6	6.9
#5	40	7.7	8.1
#5	44	9.4	9.8
#6	32	9.6	10.1
#6	40	12.1	12.7
#8	32	19.8	20.7
#8	36	22.0	23.0
#10	24	22.8	23.8
#10	32	31.7	33.1
Bolt Size Inches or #	Threads Per Inch	Standard Dry Torque in Inch-Pounds
Bolt Size Inches or #	Threads Per Inch	ASTM A453 Gr 660	ASTM A453 Gr 660
1/4	20	75.2	78.8
1/4	28	94.0	99.0
5/16	18	132	138
5/16	24	142	147
3/8	16	236	247
3/8	24	259	271
7/16	14	376	393
7/16	20	400	418
1/2	13	517	542
1/2	20	541	565
Bolt Size Inches or #	Threads Per Inch	Standard Dry Torque in Inch-Pounds
Bolt Size Inches or #	Threads Per Inch	ASTM A453 Gr 660	ASTM A453 Gr 660
9/16	12	682	713
9/16	18	752	787
5/8	11	1110	1160
5/8	18	1244	1301
3/4	10	1530	1582
3/4	16	1490	1558
7/8	9	2328	2430
7/8	14	2318	2420
1	8	3440	3595
1	14	3110	3250
Bolt Size Inches or #	Threads Per Inch	Standard Dry Torque in Foot-Pounds
Bolt Size Inches or #	Threads Per Inch	ASTM A453 Gr 660	ASTM A453 Gr 660
1 1/8	7	413	432
1 1/8	12	390	408
1 1/4	7	523	546
1 1/4	12	480	504
1 1/2	6	888	930
1 1/2	12	703	732

ASTM A453 Gr 660 Nut Weight Chart

AS PER IS 1363/67 MM THREADS
FOR 100 NOS APPROXIMATE WEIGHT IN KGS
LENGTH	Stainless Steel Fasteners DIAMETER
LENGTH	M 6	M 5	M 8	M 12	M 10	M 14	M 18	M 22	M 16	M 20
16 mm	0.743	0.448	1.590		3.211
20 mm	0.812	0.598	1.711	4.892	3.411
25 mm	0.897	0.660	1.871	5.252	3.660	8.170
30 mm	1.010	0.737	2.070	5.574	3.912	9.690			10.707	18.657
35 mm	1.120	0.804	2.271	5.974	4.223	10.000	16.026		11.416	19.608
40 mm	1.230	0.881	2.470	6.410	4.533	10.288	16.667		12.107	20.747
45 mm	1.340	0.958	2.671	6.859	4.840	10.504	17.241		12.821	21.739
50 mm	1.450	1.030	2.870	7.299	5.155	11.261	17.857	28.409	13.624	22.727
55 mm	1.560		3.071	7.740	5.464	11.628	18.868	30.120	14.409	23.810
60 mm	1.670		3.270	8.183	5.774	12.255	20.000	32.051	15.244	25.126
65 mm	1.781		3.472	8.621	6.083	12.626	21.008	34.014	16.026	26.455
70 mm	1.890		3.671	9.058	6.394	12.987	22.124	35.461	16.835	27.778
75 mm	2.000		3.873	9.506	6.702	13.228	23.256	39.063	17.606	29.070
80 mm	2.111		4.072	10.000	7.013	13.889	24.510	40.000	18.248	30.303
90 mm			4.472	10.917	7.634	14.925	26.042	41.667	19.841	33.113
100 mm			4.873	11.820	8.251	16.340	27.778	46.296	21.459	35.714
110 mm				12.723	8.881	17.730	31.250	47.170	23.041	38.168
120 mm				13.624	9.506	18.797	32.895	50.000	24.631	40.984
130 mm				14.535	10.101	20.000	34.722	52.632	26.316	43.478
140 mm				15.432	10.707	20.833	35.461	55.556	27.933	46.296
150 mm				16.340	11.312	22.222	37.594	58.824	29.412	48.544
160 mm				17.241	11.905	24.272	40.984	61.728	31.056	50.505
170 mm				18.116	12.500			64.935	32.680	53.191
180 mm				19.011	13.123	26.882		67.568	34.247	55.556
190 mm				19.920	13.736			70.423	35.971	58.140
200 mm				20.833	14.327	29.586	49.020	73.529	37.594	60.976
220 mm				22.624	15.528			79.365	40.650	65.789
240 mm				24.510	16.722			84.746	43.860	71.429
250 mm				25.381	17.301			87.719	45.455	74.627
260 mm				26.316	17.921			90.909	47.170	76.923
280 mm				28.090	19.157			98.039	50.505	81.967
300 mm				29.940	20.325			104.167	53.763	87.719
320 mm				31.646					56.818	92.593
340 mm				33.557					60.241	98.039
360 mm				35.211					63.291	104.167
380 mm				37.037					66.667	108.696
400 mm				39.063					69.444	113.636

Ready Stock ASTM A453 Gr 660 Fasteners

ASTM A453 Gr 660 Hex Domed Cap Nuts
ASTM A453 Grade 660 Flange Bolt
ASTM A453 Gr 660 Socket Cap Screw
ASTM A453 Gr 660 Wing Nuts
ASTM A453 Grade 660 Hex Head Bolt
ASTM A453 Gr 660 Class A Carriage Bolt Stockist
ASTM A453 Gr 660 Washers
ASTM A453 Gr 660 Class B Hex Washers
ASTM A453 Grade 660 Nyloc Nuts
ASTM A453 Gr 660 Coupling Nut
ASTM A453 Grade 660 Heavy Hex Nuts
ASTM A453 Gr 660 Class B Fasteners
ASTM A453 Gr 660 T-Head Bolts
ASTM A453 Grade 660 Stud Bolts
ASTM A453 Grade 660 Hexagonal Washer
ASTM A453 Gr 660 Class A Hex Coupling Nut
ASTM A453 Gr 660 Plain Washer Supplier in Mumbai
ASTM A453 Gr 660 Self Locking Nuts
ASTM A453 Gr 660 Fasteners
ASTM A453 Gr 660 Concrete Screw
ASTM A453 Grade 660 Anchor Bolts
ASTM A453 Gr 660 Class C Double Ended Stud
ASTM A453 Grade 660 Threaded Rod
ASTM A453 Gr 660 Stud Bolts
ASTM A453 Gr 660 Class C Hex Set Screw Manufacturer
ASTM A453 Gr 660 Acorn Nuts
ASTM A453 Gr 660 Class C Bolts
ASTM A453 Gr 660 Machine Fasteners Exporter
ASTM A453 Gr 660 Eye Bolts
ASTM A453 Gr 660 Structural Bolts
ASTM A453 Gr 660 Elevator Bolt
ASTM A453 Grade 660 Countersunk Washer
ASTM A453 Gr 660 Class A Hex Head Bolts
ASTM A453 Gr 660 Class B Bolts
ASTM A453 Grade 660 Class C Foundation Bolts Manufacturer
ASTM A453 Gr 660 Flat Washers
ASTM A453 Gr 660 Class A Fasteners
ASTM A453 Grade 660 Class D Ogee Washer
ASTM A453 Gr 660 Class D Lock Nut
ASTM A453 Gr 660 Screws Distributor
ASTM A453 Gr 660 Split / Lock Washer
ASTM A453 Gr 660 Machine Bolt
ASTM A453 Gr 660 Wing Nuts
ASTM A453 Grade 660 Square Nuts
ASTM A453 Gr 660 Class D Allen Cap Screw
ASTM A453 Gr 660 Tie Rods
ASTM A453 Gr 660 Fender Washer
ASTM A453 Gr 660 Class B Dock Washer Stockholder
ASTM A453 Grade 660 Customized Washer
ASTM A453 Gr 660 Tooth Lock Washer
ASTM A453 Gr 660 Class D Heavy Hex Bolts

ASTM A453 Gr 660 Fasteners Chemical Composition

Element	C	Mn	P	S	Si	Ni	Cr	Mo	Ti	Al	V	B
Grade 660	0.08 max	2.00 max	0.040 max	0.030 max	1.00 max	24.0-27.0	13.5-16.0	1.00-1.50	1.9-2.35	0.35 max	0.10-0.50	0.001-0.010

ASTM A453 Gr 660 Mechanical Properties

ASTM A453	Class	Tensile, Mpa	Yield, Mpa	Elong. %, min	RA %, min
Grade 660	A, B , C & D	895 min	585 min	15	18
