Alloy Steel F12 Nipple Outlets, Chrome Moly F12 Branch Connection Fittings, Alloy Steel F12 Branch Outlet Fittings, CrMo F12 Flexolet, Grade F12 Alloy Threadolet, UNS K11562 Weldolet, 1.7335 Latrolet, Alloy Steel F12 Sweepolet Stockist, Alloy Steel F12 Bran Outlet Fittings Supplier in Mumbai, India.
It suffers corrosive attack (maximum extreme in weldments) at sixty-five Degree C within the vapor segment and at eighty Degree C within the liquid segment. At hydrochloric acid concentrations, it offers a quantum development over the immaculate steels, and gives a whole lot more resistance hydrochloric acid within the attention range. Alloy Steel F12 Threadolet has to now no longer be utilized in carrier temperatures above 1250 Degree F because of the formation of damaging stages which shape above this temperature. It has excellent typical forming and welding characteristics. It can feature below very excessive temperatures and extreme mechanical stress, and additionally wherein excessive floor balance is required
The progressed thermal balance of retailers minimizes the issues related to fabrication of alloy components. Likewise, it does now no longer resist moist chlorine fueloline or hypochlorite bleach. It has negative corrosion resistance to oxidizing environments, therefore, it isn't encouraged to be used in oxidizing media or within the presence of ferric or cupric salts due to the fact they'll motive speedy untimely corrosion failure. These salts in shops might also additionally expand while hydrochloric acid comes in touch with iron and copper. It resists different vigorously corrosive dealers extraordinarily well. >Alloy Steel F12 Sockoletis frequently utilized in acetic acid manufacture, manufacturing of medicines, methyl metacrylate, fertilizers, vacuum furnaces, chemical processing, mechanical elements in decreasing conditions, etc.
Material Specification Chart of Alloy Steel F12 Olets
| Specifications | ASTM A182/ ASME SA182 |
|---|---|
| Dimensions | ASME / ANSI B16.11, MSS-SP-97, MSS-SP-79, JIS B2316, BS 3799 etc |
| Size | 1/8"-4" (DN6-DN100) |
| Connect Type | Welded, threaded, BW, SW |
| Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc |
| Specialized Manufacturer of | Weldolets, Threadolets, Sockolets, Elbolets, Elbolets, Nippolets, Lateral Outlet, Coupolet, Flexolet, Sweepolet, Brazolet |
| We provide Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175 | |
Alloy Steel F12 Olets Manufacturing Standards
| ASTM A182/A182M | Wrought Austenitic Alloy Steel F12 Outlet Fittings |
|---|---|
| ASME SA182 – ASTM A182 | Standard Specification for Wrought Austenitic Alloy Steel F12 Outlet Piping Fittings |
| MSS SP-97 | Integrally Reinforced Forged Branch Outlet Fittings – Socket Welding, Threaded and Buttwelding Ends |
| BS3799 – | Specification for Outlet Fittings for the petroleum industry |
| ASTM A182 – ASME SA182 | Standard Specification for Wrought Austenitic SS Outlet Fittings |
| ASME Standard | ASME/ANSI B16.11, MSS-SP-97 |
| DIN Standard | DIN28011, DIN2617, DIN2616, DIN2615, DIN2605 |
| EN Standard | EN10253-2, EN10253-1 |
| ASME B16.11 | Threaded, Welded, SW, BW |
Various Types Of Alloy Steel F12 Olets
Alloy Steel F12 Weldolet
- Alloy Steel F12 Welding Outlet
- UNS K11562 Weldolet
- 1.7335 Welding Outlet
- Cr-Mo A182 F12 Weldolet
- Grade F12 Alloy Weldolet
Alloy Steel F12 Threadolet
- 1.7335 Threadolet
- Chrome Moly F12 Threading Outlet
- Alloy Steel F12 Threadolet
- UNS K11562 Threaded Outlet
- Alloy Steel F12 Threadolet
Alloy Steel F12 Sockolet
- 1.7335 Sockolet
- UNS K11562 Sockolet
- CrMo F12 Socket Weld Outlets
- F12 Alloy Steel Sockolet
- Alloy Steel F12 Socket Weld Olets
Alloy Steel F12 Elbolet
- Chrome Moly F12 Elbow Outlets
- UNS K11562 Elbolet
- Alloy Steel F12 Elbolet
- 1.7335 Elbolet
Alloy Steel F12 Latrolet
- 1.7335 Latrolet
- UNS K11562 Latrolet
- Alloy Steel F12 Latrolet
- F12 Alloy Steel Lateral Outlet
Alloy Steel F12 Nippolet
- Alloy Steel F12 Nippolet
- UNS K11562 Nippolet
- 1.7335 Nippolet
- Cr-Mo A182 F12 Nipple Outlets
Alloy Steel F12 Flexolet
- Chrome Moly F12 Flexolet
- 1.7335 Flexolet
- Alloy Steel F12 Flexolet
- UNS K11562 Flexolet
Alloy Steel F12 Sweepolet
- 1.7335 Sweepolet
- Alloy Steel F12 Swept Outlet
- Grade F12 Alloy Sweepolet
- UNS K11562 Sweepolet
Alloy Steel F12 Brazolet
- UNS K11562 Brazolet
- 1.7335 Brazolet
- Alloy Steel F12 Brazolet
- F12 CrMo Brazolet
Alloy Steel F12 Flangeolet
- UNS K11562 Flangeolet
- CrMo F12 Flangeolet
- Alloy Steel F12 Flangeolet
- 1.7335 Flangeolet
Alloy Steel F12 Coupolet
- Alloy Steel F12 Coupolet
- 1.7335 Coupolet
- UNS K11562 Coupolet
- Cr-Mo A182 F12 Coupolet
Alloy Steel F12 Insert Weld Outlet
- UNS K11562 Insert Weld Outlet
- Chrome Moly F12 Insert Weld Outlet
- Alloy Steel F12 Insert Weld Outlet
- 1.7335 Insert Weld Outlet
Equivalent Grades of Alloy Steel F12 Insert Weld Outlet
- DIN 1.7335 Socket Weld Outlets
- F12 Alloy Steel4 Branch Connection
- F12 Alloy Steel Nipple Outlet Exporter
- F12 Alloy Steel Sockolet
- F12 Alloy Stee Pipe Outlets
- ASME SA182 Alloy Steel F12 Threadolet
- Chrome Moly F12 Flangeolet
- F12 Alloy Steel Sweepolet
- 5" Nb Grade F12 Alloy Elbolet
- Cr-Mo A182 F12 Branch Outlets Fittings
- F12 Alloy Steel Threading Outlet
- F12 CrMo Outlets
- CrMo F12 Olets Manufacturer
- Alloy Steel F12 Nippolet
- Alloy Steel F12 Olet Fittings
- Alloy Steel F12 Insert Welding Outlet Manufacturer
- Alloy Steel F12 Coupolet
- Grade F12 Alloy Insertweldolet
- CrMo F12 Latrolet
- ASTM A182 Alloy Steel F12 Flexible Outlet
- F12 CrMo Welding Outlets
- Alloy Steel F12 Threading Outlet
- Alloy Steel Fl Coupling Outlet
- ASTM A182 Alloy Steel F12 Olets Branch Fittings
- Chrome Moly F12 Outlet Fittings
- CrMo F12 Olet Fittings
- Cr-Mo A182 F12 Brazolet Supplier in Mumbai
- UNS K11562 Olet Fittings
- ASTM A182 Alloy Steel F12 Flexolet
- F12 Alloy Steel Industrial Olets
- Alloy Steel F12 Weldolet Distributor
- Alloy Steel F12 Olets
| STANDARD | WERKSTOFF NR. | UNS | EN |
| A182 F12 | 1.7335 | K11562 | 1Cr-1/2Mo |
View Thickness Table Of Alloy Steel F12 Olets, We have Global sales network for Grade F12 Alloy Outlet Connection Fittings, Wide Stockist Of Werkstoff No 1.7335 Socket Weld Outlets In India.
Check available Sizes of ASME SA 182 Alloy Steel F12 Branch Outlets Fittings, Ask For Ready Stock of UNS K11562 Threadolets in Mumbai, India.
BAGODA
Quick Contact
Alloy Steel F12 Weldolet Dimensions
| NPS | A | B | C | D |
|---|---|---|---|---|
| 1 | 1.1/16 26.99 |
2 50.80 |
1.7/16 36.51 |
1.1/32 26.19 |
| 1/2 | 3/4 19.05 |
1.3/8 34.93 |
15/16 23.81 |
5/8 15.88 |
| 3/4 | 7/8 22.23 |
1.5/8 41.28 |
1.3/16 30.16 |
13/16 20.64 |
| 1¼ | 1¼ 31.75 |
2.3/8 60.3 |
1.3/4 44.45 |
1.3/8 34.93 |
| 1½ | 1.5/16 33.34 |
2.7/8 73 |
2 50.80 |
1.5/8 41.28 |
| 2 | 1½ 38.10 |
3½ 88.90 |
2.9/16 65.09 |
2.1/16 52.39 |
| 2½ | 1.5/8 41.28 |
4.1/16 103.19 |
3 76.20 |
2.7/16 61.91 |
| 3 | 1.3/4 44.45 |
4.13/16 122.24 |
3.11/16 93.66 |
3.1/16 77.79 |
| 3½ | 2 50.80 |
5.3/8 136.53 |
3.7/8 98.43 |
3.9/16 90.49 |
| 4 | 2 50.80 |
6 152.40 |
4.3/4 120.65 |
4 101.60 |
| 5 | 2¼ 57.15 |
7.1/8 180.98 |
5.9/16 141.29 |
5.1/16 128.59 |
| 6 | 2.3/8 60.3 |
8½ 215.90 |
6.11/16 169.86 |
6.1/16 153.99 |
| 8 | 2.3/4 69.85 |
10.3/8 263.53 |
8.11/16 220.66 |
7.15/16 201.61 |
| 10 | 3.1/16 77.79 |
12.9/16 319.09 |
10.13/16 274.64 |
10 254.00 |
| 12 | 3.3/8 85.73 |
14.7/8 377.83 |
12.13/16 325.44 |
12 304.80 |
| 14 | 3½ 88.90 |
16.1/8 409.58 |
14.1/16 357.19 |
13¼ 336.55 |
| 16 | 3.11/16 93.66 |
18¼ 463.55 |
16.1/16 407.99 |
15¼ 387.35 |
| 18 | 4.1/16 103.19 |
20.3/4 527.05 |
18.5/8 473.08 |
17¼ 438.15 |
| 20 | 4.5/8 117.48 |
23.1/16 585.79 |
20.1/16 509.59 |
19¼ 488.95 |
| 24 | 5.3/8 136.53 |
27.7/8 708.03 |
25.1/8 638.18 |
23¼ 590.55 |
| NPS | A | B | C | D |
Alloy Steel F12 Sockolet Dimensions
| Nominal Pipe Size | Socket (C) Minimum |
Face to Crotch (L) | |
| 3000 Lbs | 6000 Lbs | ||
| 1″ | 13 | 22 | 29 |
| 1/8″ | 10 | 10 | – |
| 1/4″ | 10 | 10 | – |
| 3/8″ | 10 | 13 | – |
| 1/2″ | 10 | 16 | 24 |
| 3/4″ | 13 | 16 | 25 |
| 1 1/4″ | 13 | 22 | 30 |
| 1 1/2″ | 13 | 24 | 32 |
| 2″ | 16 | 24 | 37 |
| 2 1/2″ | 16 | 25 | – |
| 3″ | 16 | 30 | – |
| 4″ | 19 | 30 | – |
Alloy Steel F12 Threadolet Dimensions
| Nominal Pipe Size | Face to Crotch (L) | |
| 3000 Lbs | 6000 Lbs | |
| 1″ | 33 | 40 |
| 1/8″ | 19 | – |
| 1/4″ | 19 | – |
| 3/8″ | 21 | – |
| 1/2″ | 25 | 32 |
| 3/4″ | 27 | 37 |
| 1 1/4″ | 33 | 41 |
| 1 1/2″ | 35 | 43 |
| 2″ | 38 | 52 |
| 2 1/2″ | 46 | – |
| 3″ | 51 | – |
| 4″ | 57 | – |
Alloy Steel F12 Nipolet Dimensions
| Nominal Pipe Size | Face to Crotch (L) | |
| 3000 Lbs | 6000 Lbs | |
| 1/2″ | 25 | 32 |
| 3/4″ | 27 | 37 |
| 1 1/4″ | 33 | 41 |
| 1″ | 33 | 40 |
| 1/8″ | 19 | – |
| 1/4″ | 19 | – |
| 3/8″ | 21 | – |
| 1 1/2″ | 35 | 43 |
| 2″ | 38 | 52 |
| 2 1/2″ | 46 | – |
| 3″ | 51 | – |
| 4″ | 57 | – |
Alloy Steel F12 Latrolet Dimensions
| Nominal Pipe Size | Face to Crotch (L) | |
| 3000 Lbs | 6000 Lbs | |
| 1/2″ | 25 | 32 |
| 3/4″ | 27 | 37 |
| 1 1/4″ | 33 | 41 |
| 1″ | 33 | 40 |
| 1/8″ | 19 | – |
| 1/4″ | 19 | – |
| 3/8″ | 21 | – |
| 1 1/2″ | 35 | 43 |
| 2″ | 38 | 52 |
| 2 1/2″ | 46 | – |
| 3″ | 51 | – |
| 4″ | 57 | – |
Alloy Steel F12 Elbolet Dimensions
| Nominal Pipe Size | Face to Crotch (L) | |
| 3000 Lbs | 6000 Lbs | |
| 1/2″ | 25 | 32 |
| 3/4″ | 27 | 37 |
| 1 1/4″ | 33 | 41 |
| 1″ | 33 | 40 |
| 1/8″ | 19 | – |
| 1/4″ | 19 | – |
| 3/8″ | 21 | – |
| 1 1/2″ | 35 | 43 |
| 2″ | 38 | 52 |
| 2 1/2″ | 46 | – |
| 3″ | 51 | – |
| 4″ | 57 | – |
| Product range and theoretical weights (kg) | |||||||||
| DN | Schedule 10S | Schedule 40S | Schedule 80S | ||||||
| Con reducer | Ecc reducer | Reducing tee | Con reducer | Ecc reducer | Reducing tee | Con reducer | Ecc reducer | Reducing tee | |
| 40x.25 | 0.19 | 0.19 | 0.60 | 0.26 | 0.26 | 0.76 | 0.34 | 0.34 | 0.90 |
| 50x25 | 0.28 | 0.28 | 0.73 | 0.40 | 0.40 | 1.10 | 0.54 | 0.54 | 1.37 |
| 50x40 | 0.31 | 0.31 | 0.76 | 0.45 | 0.45 | 1.15 | 0.59 | 0.59 | 1.43 |
| 80x.50 | 0.55 | 0.55 | 1.56 | 1.00 | 1.00 | 2.91 | 1.79 | 1.79 | 3.91 |
| 100x50 | 0.78 | 0.78 | 2.94 | 1.50 | 1.50 | 4.48 | 1.95 | 1.95 | 6.55 |
| 100x80 | 0.87 | 0.87 | 3.04 | 1.74 | 1.74 | 4.64 | 2.33 | 2.33 | 6.79 |
| 150x80 | 1.82 | 1.82 | 6.86 | 3.95 | 3.95 | 9.68 | 5.51 | 5.51 | 11.57 |
| 150x100 | 1.96 | 1.96 | 7.10 | 4.07 | 4.07 | 11.94 | 5.96 | 5.96 | 11.97 |
| 200x100 | 3.01 | 3.01 | 13.46 | 6.55 | 6.55 | 17.98 | 9.23 | 9.23 | 24.18 |
| 200x150 | 3.19 | 3.19 | 14.08 | 6.74 | 6.74 | 18.82 | 10.12 | 10.12 | 25.31 |
Ready Stock Alloy Steel F12 Olets
Alloy Steel F12 Olets Chemical Composition
| Grade | C | Mn | Si | P | S | Cr | Mo |
| Alloy Steel F12 | 0.10-0.20 | 0.40-0.65 | 0.50 - 0.80 | 0.025 | 0.040 | 1 - 1.5 | 0.044 - 0.65 |
Alloy Steel F12 Olets Mechanical Properties
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min |
| A182 F12 | 205 | 415 | 20 |
