Hastelloy C276 Equal Tee In Indonesia, Hastelloy Alloy C276 Pipe Cap Stockist, 2.4819 Reducer, Hastelloy C276 Two Joint Pipe Fittings, Hastelloy C276 Stub End, Nickel Alloy C276 Cross In Philippines, Hastelloy® Alloy C276 LR Elbow, UNS N10276 Pipe Fittings Supplier in Mumbai, India.
When that is combined, as is frequently the case, with publicity to saline and different corrosives, it ends in duplex being the material of choice. For applications requiring most ductility, these Pipe Fittings with low sulphur stages may be provided via way of means of manufacturers the use of ladle - refining techniques. Electro-sprucing or passivation of these Hastelloy Alloy WNR 2.4819 Short Radius Elbow Pipe Fittings can enhance corrosion resistance. It is relevant in aircraft, furnace and chemical manner components, honeycombs and fueloline turbine combustion segment components. It additionally withstands sulphuric, acetic, formic and phosphoric acids and different non - oxidizing media.
This means, for example, that the extraordinarily difficult martensitic in Pipe Fittings, that is typically produced via way of means of rapid quenching, may be produced at decrease cooling rates. This consequences in much less inner pressure in these Hastelloy Alloy C276 Long Radius Elbow Pipe Fittings and, maximum important, a deeper hardened quarter in the work - piece. Alloying dealers additionally allow tempering at better temperatures, which generates higher ductility on the identical hardness and strength. It is measured via way of means of urgent a diamond pyramid or a difficult metallic ball into the metallic at a particular load. With right warmth treatment, it's far used for such products as razor blades, cutlery, and tools.
Material Specification Chart of Hastelloy C276 Pipe Fittings
Specifications | ASTM B366 / ASME SB366 |
---|---|
Dimensions | ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, BS4504, BS4504, BS1560, BS10 |
Size | Seamless Fittings : 1/2" - 10" Welded Fittings : 1/2" - 48" |
Thickness | SCH10, SCH20, SCH30, STD SCH40, SCH60, XS, SCH 80, SCH 100, SCH 120, SCH 140, SCH 160, XXS available with NACE MR 01-75 |
Bending Radius | R=1D, 2D, 3D, 5D, 6D, 8D, 10D |
Size Range | ½" NB to 24" NB in Sch 10s, 40s, 80s, 160s, XXS. (DN6~DN100) |
Connection | Welding |
Manufacturing Process | Push, Press, Forge, Cast, etc. |
Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc |
Specialized Manufacturer of | 90 Deg. Elbows, 45 Deg. Elbow, Tee, Cross, Reducer, Pipe Cap, Stub End, Pipe Bend |
Hastelloy C276 PIPE FITTINGS MANUFACTURING STANDARDS
ASTM B366/B366M | Piping Fittings |
---|---|
ASME B16.9 | Factory-Made Wrought Fittings Buttwelding |
MSS SP-43 | Wrought & Fabricated Butt-Welding Fitting for Low Pressure, Corrosion Resistant Applications |
BS3799 – | Specification for pipe fittings, Socket-welding and threaded/screwed fitting for the petroleum industry |
ASTM B366 – ASME SB366 | Standard Specification for Piping Fitting |
ASME Standard | ASME/ANSI B16.9, ASME/ANSI B16.28, MSS-SP-43 |
DIN Standard | DIN28011, DIN2617, DIN2616, DIN2615, DIN2605 |
EN Standard | EN10253-2, EN10253-1 |
ASME B16.25 | Buttwelding Ends |
ASME B16.28 | SR Elbows and Buttwelding Returns |
API 590-605 ASME B16.9 |
‘Factory-Made Wrought Butt-welding Fittings’ |
Various Types Of Hastelloy C276 Butt weld Pipe Fittings

- 2.4819 Short Radius Elbow
- Alloy C276 3D Butt weld Elbow In Indonesia
- ANSI B16.9 Hastelloy Alloy C276 5D Elbow
- Hastelloy C276 90 Degree Elbow In Malaysia
- Hastelloy® Alloy C276 45 Degree Elbow
- Nickel Alloy C276 180 Deg Elbow
- UNS N10276 LR Elbow

- Alloy C276 Equal Tee In Mexico
- Hastelloy C276 Unequal Tee In Philippines
- UNS N10276 Butt weld Tee
- Hastelloy C276 Tee
- ANSI B16.9 Hastelloy C276 Buttweld Tee
- Hastelloy® Alloy C276 Reducing Tee
- 2.4819 Buttweld Tees

- Alloy C276 Equal Cross In Japan
- Hastelloy Alloy C276 Unequal Cross
- Hastelloy C276 Reducing Cross
- ANSI B16.9 Hastelloy Alloy C276 Buttweld Cross
- Hastelloy C276 Cross In Italy
- 2.4819 Buttweld Cross
- UNS N10276 Butt weld Cross

- Nickel Alloy C276 Concentric Reducer In Spain
- ANSI B16.9 Hastelloy Alloy C276 Concentric Reducer
- Alloy C276 Concentric Reducer In Kuwait
- 2.4819 Concentric Reducer
- UNS N10276 Concentric Reducer

- 2.4819 Eccentric Reducer
- Nickel Alloy C276 Eccentric Reducer In Indonesia
- ANSI B16.9 Hastelloy Alloy C276 Eccentric Reducer
- Alloy C276 Eccentric Reducer In Singapore
- UNS N10276 Eccentric Reducer

- 2.4819 Short Stub End
- UNS N10276 Butt weld Stub End
- ANSI B16.9 Hastelloy Alloy C276 Lap Joint Stub End
- Alloy C276 Long Stub End In Mexico
- Hastelloy C276 Short Stub End In Singapore

- Hastelloy C276 End Cap In Philippines
- UNS N10276 Butt weld Cap
- ANSI B16.9 Hastelloy Alloy C276 Pipe End Cap
- 2.4819 End Pipe Cap
- Alloy C276 Pipe Cap In Japan

- Hastelloy C276 Nipple
- UNS N10276 Butt weld Nipple
- Alloy C276 Pipe Nipple
- 2.4819 Swage Nipple
- ANSI B16.9 Hastelloy Alloy C276 Barrel Nipple

- UNS N10276 Butt weld Bend
- ANSI B16.9 Hastelloy Alloy C276 Bend
- Hastelloy C276 Long Radius Bend In Italy
- 2.4819 Hot Induction Bend
- Alloy C276 Piggable Bend In Singapore
Equivalent Grades of Hastelloy C276 Buttweld Fittings
STANDARD | UNS | WNR. | EN | JIS | OR | GOST |
---|---|---|---|---|---|---|
Hastelloy C276 | N10276 | 2.4819 | NiMo16Cr15W | NW 0276 | ЭП760 | ХН65МВУ |

View Thickness Table Of Hastelloy C276 Buttweld Fittings, We have Global sales network for Hastelloy C276 LR Elbow, Wide Stockist Of Werkstoff No 2.4819 Seamless Fittings In India.
ASTM B366 Hastelloy C276 Buttweld Fittings
Seamless/ Welded 100% Radiography Tested | ||
Products | Size | |
ASTM B366 Alloy C276 Elbow – Long Radius | ASTM B366 Alloy C276 45° Elbow | Sizes 1/2″ – 48″ |
ASTM B366 Alloy C276 Elbow – Short Radius | ASTM B366 Alloy C276 Cross | |
ASTM B366 Alloy C276 3D Elbow | ASTM B366 Alloy C276 5D Elbow | |
ASTM B366 Alloy C276 Stub End | ASTM B366 Alloy C276 Pipe Bend | |
ASTM B366 Alloy C276 Fabricated Tee | ASTM B366 Alloy C276 End Cap | |
ASTM B366 Alloy C276 Reducer | ASTM B366 Alloy C276 Tee | |
ASTM B366 Alloy C276 Reducing Elbow | ASTM B366 Alloy C276 Pipe Nipple | |
ASTM B366 Alloy C276 Reducing Cross | ASTM B366 Alloy C276 Eccentric Reducer | |
ASTM B366 Alloy C276 Concentric Reducer | ASTM B366 Alloy C276 Welded Fittings |
Check available Sizes of ASME SB 366 Hastelloy C276 Pipe Reducer, Ask For Ready Stock of UNS N10276 Stub End in Mumbai, India.
BAGODA
Quick ContactASME B16.9 Hastelloy C276 Short and Long Radius Elbows Dimensions
Nominal Pipe Size (inches) |
Outside Diameter | 45°Elbows | 90° Elbows | 180° Returns | ||||
Long Radius | Long Radius | Short Radius | Long Radius | |||||
(mm) | (inches) | Center to Face (inches) |
Radius (inches) |
Center to Face (inches) |
Center to Face (inches) |
Center to Center (inches) |
Back to face (inches) |
|
1 | 33.4 | 1.315 | 7/8 | 1 1/2 | 1 | 3 | 2 3/16 | |
1/2 | 21.3 | 0.840 | 5/8 | 1 1/2 | – | 2 | 1 7/8 | |
3/4 | 26.7 | 1.050 | 7/16 | 1 1/8 | – | 2 1/4 | 1 11/16 | |
1 1/4 | 42.2 | 1.660 | 1 | 1 7/8 | 1 1/4 | 3 3/4 | 2 3/4 | |
1 1/2 | 48.3 | 1.900 | 1 1/8 | 3 | 2 1/4 | 1 1/2 | 4 1/2 | 3 1/4 |
2 | 60.3 | 2.375 | 1 3/8 | 4 | 3 | 2 | 6 | 4 3/16 |
2 1/2 | 73.0 | 2.875 | 1 3/4 | 5 | 3 3/4 | 2 1/2 | 7 1/2 | 5 3/16 |
3 | 88.9 | 3.500 | 2 | 6 | 4 1/2 | 3 | 9 | 6 1/4 |
3 1/2 | 101.6 | 4.000 | 2 1/4 | 7 | 5 1/4 | 3 1/2 | 10 1/2 | 7 1/4 |
4 | 114.3 | 4.500 | 2 1/2 | 8 | 6 | 4 | 12 | 8 1/4 |
5 | 141.3 | 5.563 | 3 1/8 | 10 | 7 1/2 | 5 | 15 | 10 5/16 |
6 | 168.3 | 6.625 | 3 3/4 | 12 | 9 | 6 | 18 | 12 5/16 |
8 | 219.1 | 8.625 | 5 | 12 | 12 | 8 | 24 | 16 5/16 |
10 | 273.1 | 10.750 | 6 1/4 | 15 | 15 | 10 | 30 | 20 3/8 |
12 | 323.9 | 12.750 | 7 1/2 | 18 | 18 | 12 | 36 | 24 3/8 |
ASME B16.9 Hastelloy C276 Tee & Cap Dimensions
Nominal Pipe Size (inches) |
Outside Diameter |
Caps | Straight Crosses | Straight Tees | Stub Ends | |||
(mm) | (inches) | Length (inches) |
Center to End (inches) |
Center to End (inches) |
Lap Diameter (inches) |
Long Length (inches) |
Short Length (inches) |
|
1 | 33.4 | 1.315 | 1 1/2 | 1 1/2 | 1 1/2 | 2 | 4 | 2 |
1/2 | 21.3 | 0.840 | 1 | – | 1 | 1 3/8 | 3 | 2 |
3/4 | 26.7 | 1.050 | 1 | – | 1 1/8 | 1 11/16 | 3 | 2 |
1 1/4 | 42.2 | 1.660 | 1 1/2 | 1 7/8 | 1 7/8 | 2 1/2 | 4 | 2 |
1 1/2 | 48.3 | 1.900 | 1 1/2 | 2 1/4 | 2 1/4 | 2 7/8 | 4 | 2 |
2 | 60.3 | 2.375 | 1 1/2 | 2 1/2 | 2 1/2 | 3 5/8 | 6 | 2 1/2 |
2 1/2 | 73.0 | 2.875 | 1 1/2 | 3 | 3 | 4 1/8 | 6 | 2 1/2 |
3 | 88.9 | 3.500 | 2 | 3 3/8 | 3 3/8 | 5 | 6 | 2 1/2 |
3 1/2 | 101.6 | 4.000 | 2 1/2 | 3 3/4 | 3 3/4 | 5 1/2 | 6 | 3 |
4 | 114.3 | 4.500 | 2 1/2 | 4 1/8 | 4 1/8 | 6 3/16 | 6 | 3 |
5 | 141.3 | 5.563 | 3 | 4 7/8 | 4 7/8 | 7 5/16 | 8 | 3 |
6 | 168.3 | 6.625 | 3 1/2 | 5 5/8 | 5 5/8 | 8 1/2 | 8 | 3 1/2 |
8 | 219.1 | 8.625 | 4 | 7 | 7 | 10 5/8 | 8 | 4 |
10 | 273.1 | 10.750 | 5 | 8 1/2 | 8 1/2 | 12 3/4 | 10 | 5 |
12 | 323.9 | 12.750 | 6 | 10 | 10 | 15 | 10 | 6 |
ASME B16.9 Hastelloy C276 Concentric & Eccentric Reducer Dimensions
Nominal Pipe Size |
Outside Diameter | Reducers | ||
Reduced from (inches) |
(mm) | (inches) | Reduced to (inches) | Concentric & Eccentric Length (inches) |
1 | 33.4 | 1.315 | 3/8 | 2 |
1/2 | 2 | |||
3/4 | 2 | |||
1/2 | 21.3 | 0.840 | 1/4 | 1 1/2 |
3/8 | 1 1/2 | |||
3/4 | 26.7 | 1.050 | 3/8 | 2 |
1/2 | 2 | |||
1 1/4 | 42.2 | 1.660 | 1/2 | 2 |
3/4 | 2 | |||
1 | 2 | |||
1 1/2 | 48.3 | 1.900 | 1/2 | 2 1/2 |
3/4 | 2 1/2 | |||
1 | 2 1/2 | |||
1 1/4 | 2 1/2 | |||
2 | 60.3 | 2.375 | 3/4 | 3 |
1 | 3 | |||
1 1/4 | 3 | |||
1 1/2 | 3 | |||
2 1/2 | 73.0 | 2.875 | 1 | 3 1/2 |
1 1/4 | 3 1/2 | |||
1 1/2 | 3 1/2 | |||
2 | 3 1/2 | |||
3 | 88.9 | 3.500 | 1 | 3 1/2 |
1 1/2 | 3 1/2 | |||
2 | 3 1/2 | |||
2 1/2 | 3 1/2 | |||
3 1/2 | 101.6 | 4.000 | 1 1/4 | 4 |
1 1/2 | 4 | |||
2 | 4 | |||
2 1/2 | 4 | |||
3 | 4 | |||
4 | 114.3 | 4.500 | 1 1/2 | 4 |
2 | 4 | |||
2 1/2 | 4 | |||
3 | 4 | |||
3 1/2 | 4 | |||
5 | 141.3 | 5.563 | 2 | 5 |
2 1/2 | 5 | |||
3 | 5 | |||
3 1/2 | 5 | |||
4 | 5 | |||
6 | 168.3 | 6.625 | 2 1/2 | 5 1/2 |
3 | 5 1/2 | |||
3 1/2 | 5 1/2 | |||
4 | 5 1/2 | |||
5 | 5 1/2 | |||
8 | 219.1 | 8.625 | 3 | 6 |
3 1/2 | 6 | |||
4 | 6 | |||
5 | 6 | |||
6 | 6 | |||
10 | 273.1 | 10.750 | 4 | 7 |
5 | 7 | |||
6 | 7 | |||
8 | 7 | |||
12 | 323.9 | 12.750 | 5 | 8 |
6 | 8 | |||
8 | 8 | |||
10 | 8 |
Hastelloy C276 Buttweld Fittings Weights(Kg)
Product range and theoretical weights (kg) | |||||||||
DN | Schedule 10S | Schedule 40S | Schedule 80S | ||||||
90° Elbow | 45° Elbow | Equal tee | 90° Elbow | 45° Elbow | Equal tee | 90° Elbow | 45° Elbow | Equal tee | |
8 | 0.02 | 0.01 | 0.03 | 0.03 | 0.02 | 0.06 | 0.04 | 0.03 | 0.07 |
10 | 0.03 | 0.02 | 0.05 | 0.03 | 0.02 | 0.03 | 0.06 | 0.04 | 0.09 |
15 | 0.06 | 0.03 | 0.09 | 0.08 | 0.04 | 0.10 | 0.10 | 0.05 | 0.14 |
20 | 0.07 | 0.03 | 0.13 | 0.08 | 0.04 | 0.17 | 0.11 | 0.05 | 0.20 |
25 | 0.14 | 0.08 | 0.28 | 0.15 | 0.11 | 0.29 | 0.22 | 0.14 | 0.38 |
32 | 0.23 | 0.11 | 0.49 | 0.26 | 0.17 | 0.59 | 0.40 | 0.23 | 0.68 |
40 | 0.30 | 0.17 | 0.68 | 0.40 | 0.23 | 0.86 | 0.51 | 0.29 | 1.02 |
50 | 0.50 | 0.25 | 0.85 | 0.70 | 0.4 | 1.28 | 0.91 | 0.59 | 1.59 |
65 | 0.85 | 0.48 | 1.41 | 1.40 | 0.77 | 2.19 | 1.81 | 0.99 | 3.13 |
80 | 1.25 | 0.63 | 1.77 | 2.20 | 1.08 | 3.31 | 2.97 | 1.50 | 4.45 |
90 | 1.70 | 0.75 | 2.67 | 2.83 | 1.42 | 4.08 | 4.00 | 2.00 | 5.44 |
100 | 2.10 | 1.08 | 3.46 | 4.47 | 2.09 | 5.27 | 6.18 | 2.81 | 7.71 |
150 | 5.45 | 2.72 | 8.07 | 10.89 | 5.44 | 10.99 | 16.32 | 8.16 | 13.61 |
200 | 10.20 | 5.33 | 15.65 | 21.54 | 10.77 | 20.91 | 33.11 | 16.96 | 28.12 |
250 | 18.15 | 9.75 | 26.46 | 38.56 | 19.27 | 35.38 | 51.71 | 25.86 | 49.90 |
300 | 25.80 | 13.62 | 39.46 | 59.42 | 29.71 | 62.14 | 79.38 | 39.69 | 83.91 |
Product range and theoretical weights (kg) | |||||||||
DN | Schedule 10S | Schedule 40S | Schedule 80S | ||||||
Con reducer | Ecc reducer | Reducing tee | Con reducer | Ecc reducer | Reducing tee | Con reducer | Ecc reducer | Reducing tee | |
40x.25 | 0.19 | 0.19 | 0.60 | 0.26 | 0.26 | 0.76 | 0.34 | 0.34 | 0.90 |
50x25 | 0.28 | 0.28 | 0.73 | 0.40 | 0.40 | 1.10 | 0.54 | 0.54 | 1.37 |
50x40 | 0.31 | 0.31 | 0.76 | 0.45 | 0.45 | 1.15 | 0.59 | 0.59 | 1.43 |
80x.50 | 0.55 | 0.55 | 1.56 | 1.00 | 1.00 | 2.91 | 1.79 | 1.79 | 3.91 |
100x50 | 0.78 | 0.78 | 2.94 | 1.50 | 1.50 | 4.48 | 1.95 | 1.95 | 6.55 |
100x80 | 0.87 | 0.87 | 3.04 | 1.74 | 1.74 | 4.64 | 2.33 | 2.33 | 6.79 |
150x80 | 1.82 | 1.82 | 6.86 | 3.95 | 3.95 | 9.68 | 5.51 | 5.51 | 11.57 |
150x100 | 1.96 | 1.96 | 7.10 | 4.07 | 4.07 | 11.94 | 5.96 | 5.96 | 11.97 |
200x100 | 3.01 | 3.01 | 13.46 | 6.55 | 6.55 | 17.98 | 9.23 | 9.23 | 24.18 |
200x150 | 3.19 | 3.19 | 14.08 | 6.74 | 6.74 | 18.82 | 10.12 | 10.12 | 25.31 |
Ready Stock Hastelloy C276 Pipe Fittings
- ANSI B16.9 Hastelloy C276 Pipe Cap
- Hastelloy® Alloy C276 Equal Cross In Indonesia
- Nickel Alloy C276 Pipe Fittings Manufacturer
- Hastelloy C276 SR Elbow In Malaysia
- Hastelloy C276 Piggable Bends In Mexico
- ASME B16.9 Schedule 10 Hastelloy® Alloy C276 Elbow
- Alloy C276 Barrel Nipple Supplier in Mumbai
- UNS N10276 Pipe Fittings
- Hastelloy JIS NCF C276 Mandrel Pipe Bend
- ASTM B366 Hastelloy C276 Stub End
- Hastelloy Alloy C276 Two Joint Pipe Fittings In Philippines
- C276 Hastelloy 180° LR Return Bends
- Alloy C276 1D Elbow/3D Elbow/5D Elbow In Japan
- Hastelloy® Alloy C276 Butt weld Tee
- Hastelloy® Alloy C276 Elbow In Italy
- Alloy C276 LR Elbow Stockist
- 15 NB SCH 10 Hastelloy C276 90° Short Radius Elbow
- ASME B16.9 Hastelloy C276 Buttweld Fittings
- Hastelloy C276 Reducer
- Nickel Alloy C276 End Cap Distributor
- ANSI B16.9 Hastelloy C276 Short Stub End
- Alloy C276 Reducing Nipple In Spain
- Schedule 80 Hastelloy C276 Grade Long Stub End
- 2.4819 Butt weld Fittings
- Alloy C276 Eccentric Reducer Manufacturer
- ASME SB366 Hastelloy® Alloy C276 Lateral Tee
- Hastelloy C276 Buttweld Fittings In Kuwait
- ASTM B366 Hastelloy C276 Pipe Fittings
- 5" Nb Sch10s Hastelloy C276 90° Short Radius Elbow
- DIN 2605 Hastelloy C276 Elbow Exporter
- Hastelloy C276 Long Stub End In Singapore
- ASTM B366 Hastelloy C276 Buttweld Fittings
- Hastelloy Alloy C276 Eccentric Reducer
- Hastelloy C276 Butt Weld Pipe Fittings In Indonesia
- Hastelloy Alloy C276 Long Radius Bend Stockholder
- Sch 80 Hastelloy C276 Pipe Fittings
- Hastelloy C276 Seamless Fittings
- Hastelloy C276 Welded Fittings In Malaysia
- Hastelloy C276 Two Halve Butt weld Fittings
- Hastelloy® Alloy C276 Lap Joint Stub End In Mexico
- 1/2” - 16” ASTM B366 Alloy C276 Butt weld Elbow
- DIN 2.4819 Swage Nipple
- Alloy C276 Long Radius Elbow
- ASTM B366 Alloy C276 45 Degree Elbow
- Hastelloy C276 Pipe Bend In Philippines
- SCH 60 Hastelloy® Alloy C276 Pipe Nipples
- C276 Hastelloy Buttweld Nipple In Japan
- Hastelloy® Alloy C276 Pipe Elbow In Italy
Hastelloy C276 Butt weld Fittings Chemical Composition
Grade | Ni | C | Mo | Mn | Si | Fe | P | S | Co | Cr | W | V |
---|---|---|---|---|---|---|---|---|---|---|---|---|
Alloy C276 | Balance | 0.01 max | 15–17 | 1.0 max | 0.08 max | 4–7 | 0.04 max | 0.03 max | 2.5 max | 14.5–16.5 | 3–4.5 | 0.35 max |
Hastelloy C276 Pipe Fittings Mechanical Properties
Grade | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
---|---|---|---|---|---|
Hastelloy C276 | 8.89 g/cm3 | 1370 °C (2500 °F) | Psi – 1,15,000 , MPa – 790 | Psi – 52,000 , MPa – 355 | 40 % |
