Super Duplex Steel S32760 Branch Connection Fittings, UNS S32750 Weldolet, Super Duplex Steel UNS S32750 Threadolet, SDSS F60 Branch Outlet Fittings, Super Duplex Grade F55 Sweepolet Stockist, Super Duplex 2507 Nipple Outlets, Super Duplex Stainless Steel Flexolet, 1.4410 Latrolet, Super Duplex Steel UNS S32760 Outlet Fittings Supplier in Mumbai, India.
It is utilized in industries consisting of Nuclear, Aerospace, Oil & Gas Extraction and Processing, Power Generation and Automotive. Super Duplex F55 Latrolet is a precipitation-hardenable alloy which has been utilized in applications consisting of excessive temperature structural contributors for fueloline turbines, nuclear electricity plant applications, jet engine parts, warmth-treating fixtures, extrusion dies and forming tools. It is used for its excessive strength, excessive toughness, and its oxidation and corrosion resistance.
It is a famous nickel-chromium alloy that gives customers an excessive degree of strength and simplicity of fabrication. Super Duplex F60 Insertweldolet is a nickel- chromium-molybdenum alloy with exceptional strength from room temperature as much as approximately 1500 Degree F (816 Degree C). It is a nickel-chromium-molybdenum-niobium alloy with exceptional resistance to a number of corrosive media. It presents warmth and corrosion-resistant alloy solutions for onshore and offshore extractions. It is a nickel-chromium-molybdenum alloy with an addition of niobium that acts with the molybdenum to stiffen the alloy's matrix and thereby offer excessive strength without a strengthening warmth treatment. .
Material Specification Chart of Super Duplex Steel S32750 / S32760 Olets
| Specifications | ASTM A182/ ASME SA182 |
|---|---|
| Dimensions | ASME / ANSI B16.11, MSS-SP-97, MSS-SP-79, JIS B2316, BS 3799 etc |
| Size | 1/8"-4" (DN6-DN100) |
| Connect Type | Welded, threaded, BW, SW |
| Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc |
| Specialized Manufacturer of | Weldolets, Threadolets, Sockolets, Elbolets, Elbolets, Nippolets, Lateral Outlet, Coupolet, Flexolet, Sweepolet, Brazolet |
| We provide Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175 | |
Super Duplex Steel S32750 / S32760 Olets Manufacturing Standards
| ASTM A182/A182M | Wrought Austenitic Super Duplex Steel S32750 / S32760 Outlet Fittings |
|---|---|
| ASME SA182 – ASTM A182 | Standard Specification for Wrought Austenitic Super Duplex Steel S32750 / S32760 Outlet Piping Fittings |
| MSS SP-97 | Integrally Reinforced Forged Branch Outlet Fittings – Socket Welding, Threaded and Buttwelding Ends |
| BS3799 – | Specification for Outlet Fittings for the petroleum industry |
| ASTM A182 – ASME SA182 | Standard Specification for Wrought Austenitic SS Outlet Fittings |
| ASME Standard | ASME/ANSI B16.11, MSS-SP-97 |
| DIN Standard | DIN28011, DIN2617, DIN2616, DIN2615, DIN2605 |
| EN Standard | EN10253-2, EN10253-1 |
| ASME B16.11 | Threaded, Welded, SW, BW |
Various Types Of Super Duplex Steel S32750 / S32760 Olets
Super Duplex Steel S32750 / S32760 Weldolet
- 1.4410 Welding Outlet
- Super Duplex Steel UNS S32750 Weldolet
- Duplex 2507 Welding Outlet
- Super Duplex Steel F55 Weldolet
- UNS S32760 Weldolet
Super Duplex Steel S32750 / S32760 Threadolet
- 1.4410 Threadolet
- Super Duplex Steel UNS S32760 Threadolet
- Super Duplex Steel F60 Threading Outlet
- UNS S32750 Threaded Outlet
- Super Duplex 2507 Threadolet
Super Duplex Steel S32750 / S32760 Sockolet
- Super Duplex Stainless Steel UNS S32750 Socket Weld Outlets
- 1.4410 Sockolet
- Super Duplex Steel F55 Sockolet
- UNS S32760 Sockolet
- Super Duplex Steel F60 Socket Weld Olets
Super Duplex Steel S32750 / S32760 Elbolet
- Super Duplex Steel F55 Elbolet
- 1.4410 Elbolet
- UNS S32750 Elbolet
- SAF 2507 Elbow Outlets
Super Duplex Steel S32750 / S32760 Latrolet
- Super Duplex Steel F55 Latrolet
- UNS S32760 Latrolet
- 1.4410 Latrolet
- Super Duplex 2507 Lateral Outlet
Super Duplex Steel S32750 / S32760 Nippolet
- 1.4410 Nippolet
- UNS S32750 Nippolet
- Super Duplex Grade F60 Nipple Outlets
- Super Duplex Steel UNS S32760 Nippolet
Super Duplex Steel S32750 / S32760 Flexolet
- Super Duplex Grade S32750 Flexolet
- 1.4410 Flexolet
- UNS S32760 Flexolet
- Super Duplex Steel F60 Flexolet
Super Duplex Steel S32750 / S32760 Sweepolet
- Super Duplex Steel S32750 Swept Outlet
- Super Duplex Steel F55 Sweepolet
- 1.4410 Sweepolet
- UNS S32750 Sweepolet
Super Duplex Steel S32750 / S32760 Brazolet
- UNS S32760 Brazolet
- SAF 2507 Brazolet
- Super Duplex Steel F60 Brazolet
- 1.4410 Brazolet
Super Duplex Steel S32750 / S32760 Flangeolet
- Super Duplex Steel F55 Flangeolet
- UNS S32750 Flangeolet
- 1.4410 Flangeolet
- Super Duplex Stainless Steel Flangeolet
Super Duplex Steel S32750 / S32760 Coupolet
- UNS S32760 Coupolet
- 1.4410 Coupolet
- Super Duplex Steel UNS S32750 Coupolet
- Super Duplex Steel F55 Coupolet
Super Duplex Steel S32750 / S32760 Insert Weld Outlet
- UNS S32750 Insert Weld Outlet
- Super Duplex Steel F55 Insert Weld Outlet
- SAF 2507 Insert Weld Outlet
- 1.4410 Insert Weld Outlet
Equivalent Grades of Super Duplex Steel S32750 / S32760 Olets
| STANDARD | WERKSTOFF NR. | UNS |
| Super Duplex 2507 | 1.4410 | S32750 / S32760 |
View Thickness Table Of Super Duplex Steel S32750 Olets, We have Global sales network for Super Duplex F60 Outlet Connection Fittings, Wide Stockist Of Werkstoff No 1.4410 Socket Weld Outlets In India.
Check available Sizes of ASME SA 182 Super Duplex Steel F55 Branch Outlets Fittings, Ask For Ready Stock of UNS S32760 Threadolets in Mumbai, India.
BAGODA
Quick Contact
Super Duplex Steel S32750 / S32760 Weldolet Dimensions
| NPS | A | B | C | D |
|---|---|---|---|---|
| 1 | 1.1/16 26.99 |
2 50.80 |
1.7/16 36.51 |
1.1/32 26.19 |
| 1/2 | 3/4 19.05 |
1.3/8 34.93 |
15/16 23.81 |
5/8 15.88 |
| 3/4 | 7/8 22.23 |
1.5/8 41.28 |
1.3/16 30.16 |
13/16 20.64 |
| 1¼ | 1¼ 31.75 |
2.3/8 60.3 |
1.3/4 44.45 |
1.3/8 34.93 |
| 1½ | 1.5/16 33.34 |
2.7/8 73 |
2 50.80 |
1.5/8 41.28 |
| 2 | 1½ 38.10 |
3½ 88.90 |
2.9/16 65.09 |
2.1/16 52.39 |
| 2½ | 1.5/8 41.28 |
4.1/16 103.19 |
3 76.20 |
2.7/16 61.91 |
| 3 | 1.3/4 44.45 |
4.13/16 122.24 |
3.11/16 93.66 |
3.1/16 77.79 |
| 3½ | 2 50.80 |
5.3/8 136.53 |
3.7/8 98.43 |
3.9/16 90.49 |
| 4 | 2 50.80 |
6 152.40 |
4.3/4 120.65 |
4 101.60 |
| 5 | 2¼ 57.15 |
7.1/8 180.98 |
5.9/16 141.29 |
5.1/16 128.59 |
| 6 | 2.3/8 60.3 |
8½ 215.90 |
6.11/16 169.86 |
6.1/16 153.99 |
| 8 | 2.3/4 69.85 |
10.3/8 263.53 |
8.11/16 220.66 |
7.15/16 201.61 |
| 10 | 3.1/16 77.79 |
12.9/16 319.09 |
10.13/16 274.64 |
10 254.00 |
| 12 | 3.3/8 85.73 |
14.7/8 377.83 |
12.13/16 325.44 |
12 304.80 |
| 14 | 3½ 88.90 |
16.1/8 409.58 |
14.1/16 357.19 |
13¼ 336.55 |
| 16 | 3.11/16 93.66 |
18¼ 463.55 |
16.1/16 407.99 |
15¼ 387.35 |
| 18 | 4.1/16 103.19 |
20.3/4 527.05 |
18.5/8 473.08 |
17¼ 438.15 |
| 20 | 4.5/8 117.48 |
23.1/16 585.79 |
20.1/16 509.59 |
19¼ 488.95 |
| 24 | 5.3/8 136.53 |
27.7/8 708.03 |
25.1/8 638.18 |
23¼ 590.55 |
| NPS | A | B | C | D |
Super Duplex Steel S32750 / S32760 Sockolet Dimensions
| Nominal Pipe Size | Socket (C) Minimum |
Face to Crotch (L) | |
| 3000 Lbs | 6000 Lbs | ||
| 1″ | 13 | 22 | 29 |
| 1/8″ | 10 | 10 | – |
| 1/4″ | 10 | 10 | – |
| 3/8″ | 10 | 13 | – |
| 1/2″ | 10 | 16 | 24 |
| 3/4″ | 13 | 16 | 25 |
| 1 1/4″ | 13 | 22 | 30 |
| 1 1/2″ | 13 | 24 | 32 |
| 2″ | 16 | 24 | 37 |
| 2 1/2″ | 16 | 25 | – |
| 3″ | 16 | 30 | – |
| 4″ | 19 | 30 | – |
Super Duplex Steel S32750 / S32760 Threadolet Dimensions
| Nominal Pipe Size | Face to Crotch (L) | |
| 3000 Lbs | 6000 Lbs | |
| 1″ | 33 | 40 |
| 1/8″ | 19 | – |
| 1/4″ | 19 | – |
| 3/8″ | 21 | – |
| 1/2″ | 25 | 32 |
| 3/4″ | 27 | 37 |
| 1 1/4″ | 33 | 41 |
| 1 1/2″ | 35 | 43 |
| 2″ | 38 | 52 |
| 2 1/2″ | 46 | – |
| 3″ | 51 | – |
| 4″ | 57 | – |
Super Duplex Steel S32750 / S32760 Nipolet Dimensions
| Nominal Pipe Size | Face to Crotch (L) | |
| 3000 Lbs | 6000 Lbs | |
| 1/2″ | 25 | 32 |
| 3/4″ | 27 | 37 |
| 1 1/4″ | 33 | 41 |
| 1″ | 33 | 40 |
| 1/8″ | 19 | – |
| 1/4″ | 19 | – |
| 3/8″ | 21 | – |
| 1 1/2″ | 35 | 43 |
| 2″ | 38 | 52 |
| 2 1/2″ | 46 | – |
| 3″ | 51 | – |
| 4″ | 57 | – |
Super Duplex Steel S32750 / S32760 Latrolet Dimensions
| Nominal Pipe Size | Face to Crotch (L) | |
| 3000 Lbs | 6000 Lbs | |
| 1/2″ | 25 | 32 |
| 3/4″ | 27 | 37 |
| 1 1/4″ | 33 | 41 |
| 1″ | 33 | 40 |
| 1/8″ | 19 | – |
| 1/4″ | 19 | – |
| 3/8″ | 21 | – |
| 1 1/2″ | 35 | 43 |
| 2″ | 38 | 52 |
| 2 1/2″ | 46 | – |
| 3″ | 51 | – |
| 4″ | 57 | – |
Super Duplex Steel S32750 / S32760 Elbolet Dimensions
| Nominal Pipe Size | Face to Crotch (L) | |
| 3000 Lbs | 6000 Lbs | |
| 1/2″ | 25 | 32 |
| 3/4″ | 27 | 37 |
| 1 1/4″ | 33 | 41 |
| 1″ | 33 | 40 |
| 1/8″ | 19 | – |
| 1/4″ | 19 | – |
| 3/8″ | 21 | – |
| 1 1/2″ | 35 | 43 |
| 2″ | 38 | 52 |
| 2 1/2″ | 46 | – |
| 3″ | 51 | – |
| 4″ | 57 | – |
| Product range and theoretical weights (kg) | |||||||||
| DN | Schedule 10S | Schedule 40S | Schedule 80S | ||||||
| Con reducer | Ecc reducer | Reducing tee | Con reducer | Ecc reducer | Reducing tee | Con reducer | Ecc reducer | Reducing tee | |
| 40x.25 | 0.19 | 0.19 | 0.60 | 0.26 | 0.26 | 0.76 | 0.34 | 0.34 | 0.90 |
| 50x25 | 0.28 | 0.28 | 0.73 | 0.40 | 0.40 | 1.10 | 0.54 | 0.54 | 1.37 |
| 50x40 | 0.31 | 0.31 | 0.76 | 0.45 | 0.45 | 1.15 | 0.59 | 0.59 | 1.43 |
| 80x.50 | 0.55 | 0.55 | 1.56 | 1.00 | 1.00 | 2.91 | 1.79 | 1.79 | 3.91 |
| 100x50 | 0.78 | 0.78 | 2.94 | 1.50 | 1.50 | 4.48 | 1.95 | 1.95 | 6.55 |
| 100x80 | 0.87 | 0.87 | 3.04 | 1.74 | 1.74 | 4.64 | 2.33 | 2.33 | 6.79 |
| 150x80 | 1.82 | 1.82 | 6.86 | 3.95 | 3.95 | 9.68 | 5.51 | 5.51 | 11.57 |
| 150x100 | 1.96 | 1.96 | 7.10 | 4.07 | 4.07 | 11.94 | 5.96 | 5.96 | 11.97 |
| 200x100 | 3.01 | 3.01 | 13.46 | 6.55 | 6.55 | 17.98 | 9.23 | 9.23 | 24.18 |
| 200x150 | 3.19 | 3.19 | 14.08 | 6.74 | 6.74 | 18.82 | 10.12 | 10.12 | 25.31 |
Ready Stock Super Duplex Steel S32750 / S32760 Olets
- Super Duplex Steel F60 Sweepolet
- SDSS SAF 2507 Insertweldolet
- Super Duplex Steel UNS S32750 Sockolet
- Super Duplex Steel F60 Olet Fittings
- Super Duplex Steel F55 Threading Outlet
- SAF 2507 Coupolet
- ASME SA182 Super Duplex Steel Threadolet
- Super Duplex Steel F55 Threading Outlet
- Super Duplex Steel F55 Olets Manufacturer
- DIN 1.4410 Socket Weld Outlets
- Super Duplex Grade UNS S32750 Weldolet Distributor
- Super Duplex Steel F60 Olets
- ASTM A182 Duples Steel F60 Olets Branch Fittings
- Super Duplex Grade F55 Olet Fittings
- SAF 2507 Coupling Outlet
- Super Duplex Steel F60 Nippolet
- Super Duplex Steel UNS S32760 Nipple Outlet Exporter
- Super Duplex Steel F55 Industrial Olets
- Super Duplex 2507 Flangeolet
- Super Duplex Steel UNS S32760 Outlet Fittings
- Super Duplex Steel UNS S32760 Branch Connection
- ASTM A182 SDSS F55 Flexible Outlet
- ASTM A182 Super Duplex Steel F60 Flexolet
- Super Duplex Stel F60 Branch Outlets Fittings
- Super Duplex Stainless Steel Pipe Outlets
- Super Duplex Steel UNS S32750 Outlets
- Super Duplex Grade UNS S32760 Welding Outlets
- UNS S32760 Olet Fittings
- SAF 2507 Latrolet
- Super Duplex Steel Brazolet Supplier in Mumbai
- 5" Nb SDSS UNS S32750 Elbolet
- Super Duplex 2507 Insert Welding Outlet Manufacturer
Super Duplex Steel S32750 / S32760 Olets Chemical Composition
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | Fe |
| S32750 | 0.030 max | 1.20 max | 0.80 max | 0.035 max | 0.020 max | 24.00 – 26.00 | 3.00 – 5.00 | 6.00 – 8.00 | 0.24 – 0.32 | 58.095 min |
| S32760 | 0.05 max | 1.00 max | 1.00 max | 0.030 max | 0.010 max | 24.00 – 26.00 | 3.00 – 4.00 | 6.00 – 8.00 | 0.20 – 0.30 | 57.61 min |
Super Duplex Steel S32750 / S32760 Olets Mechanical Properties
| Density | Melting Point | Tensile Strength, ksi | 0.2% Yield Strength, ksi | Elongation, % | Hardness Rockwell C |
| 7.8 (g/cm 3) / 0.281 (lb/in 3) | 1350 °C (2460 °F) | 116 min. | 80 min. | 15 min | 32 max. |
