ASTM A194 GR.6 / 6X Fasteners

ASTM A194 Grade 6X Fasteners, ASTM A194 Grade 6X Bolts, ASTM A194 Grade 6 Nuts, ASTM A194 Gr 6 Washers, ASTM A194 Gr 6X Stud Bolts Price in India.

Bagoda Steel is a customaryseller of ASTM A193 Grade 6 / 6X Fasteners, whichhas the face-targeted cubic lattice structure. Typical applications for these fasteners have blanketed warmness shields, fueloline turbine engine ducting, furnace hardware, combustion liners, chemical plant hardware, unique seawater and spray bars applications. Stainless Steel ASTM A193 Grade 6Nutsis an alloy that capabilities tremendous resistance to deterioration, oxidation, and awesome overall performance at intense temperatures. However, whilst sulfur compounds are gift as well, or for ammonium hydroxide service, these fasteners is suggested. It is regularly utilized in Heat treating muffles and retorts, Aircraft exhaust liners and turbine seals, and High temperature furnace applications. It is an aggregate of nickel and chromium alloy that has awesome tensile strength and resistance to oxidation in addition to carburzation properties.

Industrial Product
ASTM A194 GR.6 / 6X Fasteners

ASTM A194 Gr 6X Allen Cap Screw, A194 Grade 6X Hex Bolts, ASTM A194 Grade 6 Carriage Bolts Stockist, ASTM A194 Gr 6 Nuts, ASTM A194 Gr 6X Screws, ASTM A194 Grade 6X Threaded Rod, ASTM A194 Gr 6 Anchor Bolts, ASTM A194 Gr 6X Fasteners, ASTM A194 Gr 6 Flat Washers Supplier in Mumbai, India.

+91 22 - 66151721
sales@bagodasteelproject.com
+91 9011334411

Hot working in these fasteners ought to be accomplished among 1600 Degree F and 2250 Degree F, fending off any work among 1200 Degree F and 1600 Degree F, because the ductility decreases on this temperature variety. It is likewise utilized in furnace trays, fuel stabilizer production, mufflers, hangers, evaporates, etc. These Stainless Steel ASME SA193 Grade 6X Bolts with tight tolerances may be furnished in nearly any length regardless of how small the dimensions or quantity.It is immune to corrosion in an extensive kind of system environments which include phosphoric, nitric, sulfuric, sulfurous, hydrofluoric and natural acids and alkalis consisting of sodium or potassium hydroxide, and acidic chloride solutions.

It has realistic immunity to chloride strain corrosion cracking (SCC), and additionally resists polythionic acid SCC. Applications of these fasteners encompass chemical processing, pollutants control, oil and fueloline recovery, acid production, pickling operations, nuclear gasoline reprocessing, and dealing with of radioactive wastes. Stainless Steel ASTM A193 Grade 6 Washers calls for no post - weld warmness treatment that is particularly immune to sulfuric and phosphoric acids.The forging temperature variety is 2150 Degree F / 1600 Degree F (1180 Degree C / 870 Degree C). The tiers of molybdenum and copper in these fasteners permit to face up to lowering marketers and acids.

Standard Specification For ASTM A194 GR.6 / 6X Fasteners

Dimensions ASME B18.2.1, B18.3
Size Size : M3 – M56 | 3/6″ to 2″ | Custom Sizes
Length 3 mm to 200 mm
Hex Nuts UNF, BSW, BSF, METRIC, UNC, or as required
Standard DIN : DIN 934, DIN 931, DIN 970, DIN 933 UTS : UNEF, NPT, UNC, UNS, UNF, NPTF ISO : JIS standards, ISO 4033, ISO 4032, ANSI – American National Standards Institute ASME B18.5 ANSI B 28.2.4 1M ANSI B 18.2.4 2M as per defined in ASME B18.2.2 Hex nuts
Form Hex, Threading, Square, Round as per Gauge Etc.
Threads Configuration ASME B1.1 2A/3A – 2B/3B Inch Unified Threads and B1.13M 6h-6G Metric Coarse Threads
Certification Dual Certified As per ASTM & ASME Codes
Dimensions DIN 931, 933, 934, 7991, 976, 125, ASME B18.2.1, B18.3
Threads Unless otherwise specified, the threads shall be rolled or cut and tapped horizontally or vertically
Test Certificate as per EN 10204 / 3.1 Manufacturer Test Certificate
Additional Certifications PED 97/23/EC Certified, Merkblatt AD 2000 W2 Certified
Production process M24-M100: hot forging , M2-M24: Cold Froging, for custom-made connecting element machining and CNC
Head drive Six-Lobe,Phillips,Phillips/Slot, Slotted etc
Surface Coating Ptfe Coated Nuts Phosphate Coating Teflon Coating Zinc Coating Hot Dipped Galvanizing Coating Cadmium Coating Xylon Coating
finishing Coatings & Finishes : Self-Colour, Passivated, Bright Zinc Plated (BZP), Hot Dip Galvanised (HDG), Sherardized, some special one like DACROMET Geometry and Mechanically Applied coating ,Dacroment, nickel plated, anodizing, plated zinc-nickel Zinc (blue, black, yellow, white), black oxide,

ASTM A194 Gr 6 / 6X Raw Material

STANDARD Grade Designation
ASTM A194 GR.6 / 6X AISI 410 Stainless Steel

ASTM A194 GR.6 / 6X Fasteners Manufacturing Standards

DIN Nuts Hexagon Nuts
Din 315 Wing Nut DIN 934 Finished Hex Nut
DIN 985 Hex Nylon Insert Lock Nut DIN 980V Hex Steel Prevailing Torque Lock Nut
DIN 8334 Rod Coupling Nut DIN 8923 Hex Flange Nut
Din 431 Nuts BS 1768
Din 555 Nuts BS 1769
Din 557 Nuts BS 1083
Din 562 Nuts BS 3692
Din 582 Nuts ISO 4032
Din 934 Nuts ISO 4033
Din 936 Nuts ANSI B18.2.2
Din 1587 Nuts
Din 6923 Nuts

Various Types Of ASTM A194 GR.6 / 6X Fasteners

ASTM A194 GR.6 / 6X Bolts
ASTM A194 GR.6 / 6X Bolts
  • ASTM A194 Grade 6X Hex Bolts
  • ASTM A194 Gr 6X Heavy Hex Bolts
  • ASTM A194 Gr 6 Bolts
  • ASTM A194 Grade 6 Bolts
ASTM A194 GR.6 / 6X Screw
ASTM A194 GR.6 / 6X Screw
  • ASTM A194 Grade 6X q Set Screws
  • ASTM A194 Gr 6 Hex Cap Screws
  • ASTM A194 Grade 6X Allen Cap Screw
  • ASTM A194 Grade 6 Screw
  • ASTM A194 Gr 6X Screw
ASTM A194 GR.6 / 6X Hex Bolts
ASTM A194 GR.6 / 6X Hex Bolts
  • ASTM A194 Gr 6 Hex Bolts
  • ASTM A194 Grade 6X Heavy Hex Bolts
  • ASTM A194 Grade 6 Hex Bolts
  • ASTM A194 Gr 6X Hex Head Bolts
Fasteners Dimensions

View Size Table Of ASTM A194 Gr 6 Fasteners, We have Global sales network for ASTM A194 Grade 6X Stud Bolts, Wide Stockist Of ASTM A194 Gr 6X Nuts, Bolts, Washers In India.

Size Chart of ASTM A194 GR.6 / 6X Fasteners

Nuts Size
(mm)		 Diameter*
(mm)		 Height
(mm)
Hex Nuts Jam Nuts Nylock Nuts
2 4 1.6 1.2 –
2.5 5 2 1.6 –
3 5.5 2.4 1.8 4
4 7 3.2 2.2 5
5 8 4 2.7 5
6 10 5 3.2 6
7 11 5.5 3.5 –
8 13 6.5 4 8
10 17 8 5 10
12 19 10 6 12
14 22 11 7 14
16 24 13 8 16
18 27 15 9 18.5
20 30 16 10 20
* This is the diameter across the flats. It is also the size of wrench to use.

Check available Sizes of ASTM A194 GR.6 Stud Bolt, Ask For Ready Stock of ASTM A194 Grade 6X Fasteners in Mumbai, India.

BAGODA

Quick Contact

ASTM A194 Gr 6 / 6X Nut Weight Chart

Size Finished Hex Heavy Hex Finished Jam Heavy Hex Jam Square Heavy Square
1/2″ 3.750 6.540 2.620 4.000 5.780 7.870
5/8″ 7.330 11.900 4.930 6.960 10.800 14.300
3/4″ 11.900 19.300 7.700 11.000 15.400 23.500
7/8″ 19.000 29.700 12.000 16.700 24.500 36.200
1″ 28.300 42.500 17.600 23.500 36.300 51.500
1-1/8″ 40.300 59.200 24.700 32.400 52.500 72.400
1-1/4″ 54.300 78.600 36.100 45.800 70.600 95.500
1-3/8″ 73.000 102.000 47.900 59.300 94.500 125.000
1-1/2″ 94.300 131.000 60.900 74.800 122.000 161.000
1-5/8″ 162.000 91.600
1-3/4″ 151.000 204.000 100.000 114.000
1-7/8″ 241.000 134.000
2″ 224.000 299.000 140.000 165.000
2-1/4″ 419.000 227.000
2-1/2″ 564.000 332.000
2-3/4″ 738.000 429.000
3″ 950.000 545.000
3-1/4″ 1194.000 651.000
3-1/2″ 1526.000 851.000
3-3/4″ 1812.000 1005.000
4″ 2180.000 1200.000

Dimensions of ASTM A194 Grade 6 / 6X Hex Nuts

Nominal Size or Basic Major Thread DiameterFGH
Width
Across Flats		Width
Across Corners		Thickness
BasicMaxMinMaxMinBasicMaxMin
1/4 Hex Nuts.25007/16.438.428.505.4887/32.226.212
5/16 Hex Nuts.31251/2.500.489.577.55717/64.273.258
3/8 Hex Nuts.37509/16.562.551.650.62821/64.337.320
7/16 Hex Nuts.437511/16.688.675.794.7683/8.385.365
1/2 Hex Nuts.50003/4.750.736.866.8407/16.448.427
9/16 Hex Nuts.56257/8.875.8611.010.98231/64.496.473
5/8 Hex Nuts.625015/16.938.9221.0831.05135/64.559.535
3/4 Hex Nuts.75001-1/81.1251.0881.2991.24041/64.665.617
7/8 Hex Nuts.87501-5/161.3121.2691.5161.4473/4.776.724
1 Hex Nuts1.00001-1/21.5001.4501.7321.65355/64.887.831
1-1/8 Hex Nuts1.12501-11/161.6881.6311.9491.85931/32.999.939
1-3/8 Hex Nuts1.37502-1/162.0621.9942.3822.2731-11/641.2061.138
1-1/2 Hex Nuts1.5002-1/42.2502.1752.5982.4801-9/321.3171.245
1-5/8 Hex Nuts1.62502-7/162.4382.3562.8152.6861-25/641.4291.353
1-3/4 Hex Nuts1.75002-5/82.6252.5383.0312.8931-1/21.5401.460
2 Hex Nuts2.000033.0002.9003.4643.3061-23/321.7631.675
2-1/4 Hex Nuts2.25003-3/83.3753.2633.8973.7191-15/161.9861.890
2-1/2 Hex Nuts2.50003-3/43.7503.6254.3304.1332-5/322.2092.105
2-3/4 Hex Nuts2.75004-1/84.1253.9884.7634.5462-3/82.4312.319

ASTM A194 Grade 6 / 6X Heavy Hex Nut Dimensions

Nominal Size or Basic Major Thread DiameterFGH
Width Across FlatsWidth Across CornersThickness
BasicMaxMinMaxMinBasicMaxMin
1/4 Heavy Hex Nut.25001/2.500.488.577.55615/64.250.218
5/16 Heavy Hex Nut.31259/16.562.546.650.62219/64.314.280
3/8 Heavy Hex Nut.375011/16.688.669.794.76323/64.377.341
7/16 Heavy Hex Nut.43753/4.750.728.866.83027/64.441.403
1/2 Heavy Hex Nut.50007/8.875.8501.010.96931/64.504.464
9/16 Heavy Hex Nut.562515/16.938.9091.0831.03735/64.568.526
5/8 Heavy Hex Nut.62501-1/161.0621.0311.2271.17539/64.631.587
3/4 Heavy Hex Nut.75001-1/41.2501.2121.4431.38247/64.758.710
7/8 Heavy Hex Nut.87501-7/161.4381.3941.6601.58955/64.885.833
1 Heavy Hex Nut1.00001-5/81.3251.5751.8761.79663/641.012.956
1-1/8 Heavy Hex Nut1.12501-13/161.8121.7562.0932.0021-7/641.1391.079
1-1/4 Heavy Hex Nut1.250022.0001.9382.3092.2091-7/321.2511.187
1-3/8 Heavy Hex Nut1.37502-3/162.1882.1192.5262.4161-11/321.3781.310
1-1/2 Heavy Hex Nut1.50002-3/82.3752.3002.7422.6221-15/321.5051.433
1-5/8 Heavy Hex Nut1.62502-9/162.5622.4812.9592.8281-19/321.6321.556
1-3/4 Heavy Hex Nut1.75002-3/42.7502.6623.1753.0351-23/321.7591.679
2 Heavy Hex Nut2.00003-1/83.1253.0253.6083.4491-31/322.0131.925
2-1/4 Heavy Hex Nut2.25003-1/23.5003.3884.0413.8622-13/642.2512.155
2-1/2 Heavy Hex Nut2.50003-7/83.8753.7504.4744.2752-29/642.5052.401
2-3/4 Heavy Hex Nut2.75004-1/44.2504.1124.9074.6882-45/642.7592.647
3 Heavy Hex Nut3.00004-5/84.6254.4755.3405.1022-61/643.0132.893
3-1/4 Heavy Hex Nut3.250055.0004.8385.7745.5153-3/163.2523.124
3-1/2 Heavy Hex Nut3.50005-3/85.3755.2006.2075.9283-7/163.5063.370
3-3/4 Heavy Hex Nut3.75005-3/45.7505.5626.6406.3413-11/163.6703.616
4 Heavy Hex Nut4.00006-1/86.1255.9257.0736.7553-15/164.0143.862

Ready Stock ASTM A194 GR.6 / 6X Fasteners

  • ASTM A194 Gr 6X Socket Cap Screw
  • ASTM A194 Gr 6 Hex Set Screw Manufacturer
  • ASTM A194 Gr 6X Fasteners
  • ASTM A194 Gr 6 Allen Cap Screw
  • ASTM A194 Gr 6X Self Locking Nuts
  • ASTM A194 Gr 6 Coupling Nut
  • ASTM A194 Gr 6X Eye Bolts
  • ASTM A194 Gr 6 Washers
  • ASTM A194 Grade 6X Ogee Washer
  • ASTM A194 Gr 6X Structural Bolts
  • ASTM A194 Gr 6 Lock Nut
  • ASTM A194 Grade 6X Flange Bolt
  • ASTM A194 Grade 6X Anchor Bolts
  • ASTM A194 Grade 6X Foundation Bolts Manufacturer
  • ASTM A194 Gr 6X T-Head Bolts
  • ASTM A194 Grade 6 Hex Head Bolt
  • ASTM A194 Grade 6X Threaded Rod
  • ASTM A194 Gr 6 Stud Bolts
  • ASTM A194 Gr 6X Hex Head Bolts
  • ASTM A194 Grade 6X Heavy Hex Nuts
  • ASTM A194 Grade 6 Dock Washer Stockholder
  • ASTM A194 Gr 6 Wing Nuts
  • ASTM A194 Grade 6 Split / Lock Washer
  • ASTM A194 Grade 6X Plain Washer Supplier in Mumbai
  • ASTM A194 Grade 6X Elevator Bolt
  • ASTM A194 Grade 6X Flat Washers
  • ASTM A194 Gr 6 Wing Nuts
  • ASTM A194 Grade 6 Double Ended Stud
  • ASTM A194 Grade 6 Heavy Hex Bolts
  • ASTM A194 Gr 6 Screws Distributor
  • ASTM A194 Grade 6 Bolts
  • ASTM A194 Gr 6X Fasteners
  • ASTM A194 Gr 6X Acorn Nuts
  • ASTM A194 Gr 6 Hex Domed Cap Nuts
  • ASTM A194 Grade 6 Machine Fasteners Exporter
  • ASTM A194 Grade 6 Tie Rods
  • ASTM A194 Gr 6 Fasteners
  • ASTM A194 Grade 6 Hex Washers
  • ASTM A194 Grade 6 Fender Washer
  • ASTM A194 Gr 6X Concrete Screw
  • ASTM A194 Gr 6X Hex Coupling Nut
  • ASTM A194 Grade 6X Countersunk Washer
  • ASTM A194 Grade 6X Square Nuts
  • ASTM A194 Gr 6X Carriage Bolt Stockist
  • ASTM A194 Grade 6X Stud Bolts
  • ASTM A194 Grade 6 Customized Washer
  • ASTM A194 Gr 6 Machine Bolt
  • ASTM A194 Grade 6 Hexagonal Washer
  • ASTM A194 Grade 6X Nyloc Nuts
  • ASTM A194 Gr 6X Bolts
  • ASTM A194 Gr 6 Tooth Lock Washer

ASTM A194 GR.6 / 6X Fasteners Chemical Composition

Grade C Mn P S Si Cr
ASTM A194 GR.6/6X 0.15% 1.00% 0.04% 0.03% 1.00% 11.5-13.5%

ASTM A194 GR.6 / 6X Mechanical Properties

Tensile Strength/ (UTS) – (Mpa)Yield Strength/(0.2% Offset) – (Mpa)Elongation in 4D (El)ReductionHardness – (BHN)
5502403040223
