ASTM A234 WP11 Stub End, Chrome Moly WP11 Pipe Cap In Indonesia, A234 WP11 Cross, Cr-Mo WP11 Reducer In Spain, A234 WP11 Equal Tee, A234 WP11 LR Elbow Supplier in Mumbai, India.
It is a nickel – iron – chromium alloy which has the addition of copper and molybdenum. It reveals superb corrosion resistance in chemical environments containing phosphoric acid, nitric acid, chlorides and sulphuric acid. It additionally has correct mechanical properties at each ambient and increased temperatures. For applications requiring most ductility, our ASTM A234 Alloy Steel WP11 Concentric Reducer Pipe Fittings with low sulphur stages may be provided through manufacturers the usage of ladle - refining techniques. Liquid quenching in these pipe fittings is impractical (due to the threat of cracking or distortion or due to cost). It confer by means of the decrease carbon content material to permit for extra corrosion safety whilst welding.
Low - carbon nickel or nickel - molybdenum steels, inclusive of our pipe fittings, within the normalized – and – tempered situation may be used for low – temperature service. The standard outcomes of these situations are qualitatively comparable in these ASME SA 234 Alloy Steel WP11 Eccentric Reducer Pipe Fittings that is frequently utilized in several applications inclusive of Calorifiers, Columns, Filters, Dished ends, etc. They are used for a selection of applications in which first - charge corrosion and notable hardness is necessary. It additionally gives better creep, strain to rupture and tensile strength at increased temperatures, similarly to tremendous corrosion resistance properties alongside with strength properties.
Material Specification Chart of Alloy Steel A234 WP11 Pipe Fittings
| Specifications | ASTM A234/ ASME SA234 |
|---|---|
| Dimensions | ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, BS4504, BS4504, BS1560, BS10 |
| Size | Seamless Fittings : 1/2" - 10" Welded Fittings : 1/2" - 48" |
| Thickness | SCH10, SCH20, SCH30, STD SCH40, SCH60, XS, SCH 80, SCH 100, SCH 120, SCH 140, SCH 160, XXS available with NACE MR 01-75 |
| Bending Radius | R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom |
| Size Range | ½" NB to 24" NB in Sch 10s, 40s, 80s, 160s, XXS. (DN6~DN100) |
| Connection | Welding |
| Manufacturing Process | Push, Press, Forge, Cast, etc. |
| Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc |
| Specialized Manufacturer of | 90 Deg. Elbows, 45 Deg. Elbow, Tee, Cross, Reducer, Pipe Cap, Stub End, Pipe Bend |
Alloy Steel A234 WP11 Pipe Fittings Manufacturing Standards
| ASTM A234/A234M | Alloy Steel Piping Fittings |
|---|---|
| ASME B16.9 | Factory-Made Wrought Fittings Buttwelding |
| MSS SP-43 | Wrought & Fabricated Butt-Welding Fitting for Low Pressure, Corrosion Resistant Applications |
| BS3799 – | Specification for pipe fittings, Socket-welding and threaded/screwed fitting for the petroleum industry |
| ASTM A234 – ASME SA234 | Standard Specification for Wrought Austenitic SS Piping Fitting |
| ASME Standard | ASME/ANSI B16.9, ASME/ANSI B16.28, MSS-SP-43 |
| DIN Standard | DIN28011, DIN2617, DIN2616, DIN2615, DIN2605 |
| EN Standard | EN10253-2, EN10253-1 |
| ASME B16.25 | Buttwelding Ends |
| ASME B16.28 | Wrought Steel SR Elbows and Buttwelding Returns |
| API 590-605 ASME B16.9 |
‘Factory-Made Wrought Butt-welding Fittings’ |
Various Types Of Cr-Mo WP11 Butt weld Pipe Fittings
- Alloy Steel A234 WP11 90 Degree Elbow In Indonesia
- Cr-Mo WP11 45 Degree Elbow In Singapore
- Alloy Steel A234 WP11 180 Deg Elbow
- Cr-Mo WP11 3D Butt weld Elbow
- ASTM A234 CRMO WP11 LR Elbow
- ANSI B16.9 Chromium Molybdenum WP11 5D Elbow
- Chrome Moly WP11 Short Radius Elbow
- Chrome Moly WP11 Buttweld Tees In Kuwait
- Alloy Steel A234 WP11 Tee In Malaysia
- Chromium Molybdenum WP11 Butt weld Tee
- WP11 Alloy Steel Reducing Tee
- ANSI B16.9 Alloy Steel A234 WP11 Buttweld Tee
- Cr-Mo WP11 Equal Tee
- Alloy Steel A234 WP11 Unequal Tee
- Cr-Mo WP11 Equal Cross In Mexico
- Chrome Moly WP11 Unequal Cross
- Chromium Molybdenum WP11 Buttweld Cross
- ANSI B16.9 Alloy Steel A234 WP11 Buttweld Cross
- Alloy Steel A234 WP11 Cross
- Alloy Steel A234 Butt weld Cross In Spain
- Alloy Steel WP11 Reducing Cross
- Chrome Moly WP11 Butt weld Concentric Reducer In Italy
- ANSI B16.9 Chromium Molybdenum WP11 Concentric Reducer
- Cr-Mo WP11 Concentric Reducer
- AS WP11 Concentric Reducer In Philippines
- CrMo A234 WP11 Concentric Reducer
- Alloy Steel WP11 Eccentric Reducer In Japan
- AS A234 WP11 Eccentric Reducer In Mexico
- WP11 Alloy Steel Butt weld Eccentric Reducer
- ANSI B16.9 Alloy Steel A234 WP11 Eccentric Reducer
- Cr-Mo WP11 Eccentric Reducer
- WP11 Alloy Steel Butt weld Stub End
- Alloy Steel A234 WP11 Short Stub End In Italy
- Chromium Molybdenum WP11 Short Stub End
- ANSI B16.9 Alloy Steel A234 WP11 Lap Joint Stub End
- Cr-Mo WP11 Long Stub End In Indonesia
- Alloy Steel A234 WP11 End Cap In Malaysia
- Alloy Steel A234 WP11 Butt weld Cap
- ANSI B16.9 Chromium Molybdenum WP11 Pipe End Cap
- Cr-Mo WP11 Pipe Cap In Spain
- Chrome Moly WP11 End Pipe Cap
- Alloy Steel A234 WP11 Nipple In Indonesia
- Cr-Mo WP11 Swage Nipple In Kuwait
- Chrome Moly WP11 Butt weld Nipple
- ANSI B16.9 Chromium Molybdenum WP11 Barrel Nipple
- Cr-Mo WP11 Pipe Nipple
- Chrome Moly WP11 Hot Induction Bend In Singapore
- ASTM A234 CRMO WP11 Butt weld Bend
- ANSI B16.9 Alloy Steel A234 WP11 Bend
- Alloy Steel A234 WP11 Long Radius Bend
- Cr-Mo WP11 Piggable Bend In Philippines
View Thickness Table Of Cr-Mo WP11 Buttweld Fittings, We have Global sales network for Alloy Steel A234 WP11 LR Elbow, Wide Stockist Of Alloy Steel A234 WP11 Seamless Fittings In India.
Check available Sizes of ASME SA 234 WP11 Pipe Reducer, Ask For Ready Stock of Alloy Steel WP11 Stub End in Mumbai, India.
BAGODA
Quick Contact
ASME B16.9 Alloy Steel WP11 Short and Long Radius Elbows Dimensions
| Nominal Pipe Size (inches) |
Outside Diameter | 45°Elbows | 90° Elbows | 180° Returns | ||||
| Long Radius | Long Radius | Short Radius | Long Radius | |||||
| (mm) | (inches) | Center to Face (inches) |
Radius (inches) |
Center to Face (inches) |
Center to Face (inches) |
Center to Center (inches) |
Back to face (inches) |
|
| 1 | 33.4 | 1.315 | 7/8 | 1 1/2 | 1 | 3 | 2 3/16 | |
| 1/2 | 21.3 | 0.840 | 5/8 | 1 1/2 | – | 2 | 1 7/8 | |
| 3/4 | 26.7 | 1.050 | 7/16 | 1 1/8 | – | 2 1/4 | 1 11/16 | |
| 1 1/4 | 42.2 | 1.660 | 1 | 1 7/8 | 1 1/4 | 3 3/4 | 2 3/4 | |
| 1 1/2 | 48.3 | 1.900 | 1 1/8 | 3 | 2 1/4 | 1 1/2 | 4 1/2 | 3 1/4 |
| 2 | 60.3 | 2.375 | 1 3/8 | 4 | 3 | 2 | 6 | 4 3/16 |
| 2 1/2 | 73.0 | 2.875 | 1 3/4 | 5 | 3 3/4 | 2 1/2 | 7 1/2 | 5 3/16 |
| 3 | 88.9 | 3.500 | 2 | 6 | 4 1/2 | 3 | 9 | 6 1/4 |
| 3 1/2 | 101.6 | 4.000 | 2 1/4 | 7 | 5 1/4 | 3 1/2 | 10 1/2 | 7 1/4 |
| 4 | 114.3 | 4.500 | 2 1/2 | 8 | 6 | 4 | 12 | 8 1/4 |
| 5 | 141.3 | 5.563 | 3 1/8 | 10 | 7 1/2 | 5 | 15 | 10 5/16 |
| 6 | 168.3 | 6.625 | 3 3/4 | 12 | 9 | 6 | 18 | 12 5/16 |
| 8 | 219.1 | 8.625 | 5 | 12 | 12 | 8 | 24 | 16 5/16 |
| 10 | 273.1 | 10.750 | 6 1/4 | 15 | 15 | 10 | 30 | 20 3/8 |
| 12 | 323.9 | 12.750 | 7 1/2 | 18 | 18 | 12 | 36 | 24 3/8 |
ASME B16.9 Alloy Steel A234 WP11 Tee & Cap Dimensions
| Nominal Pipe Size (inches) |
Outside Diameter |
Caps | Straight Crosses | Straight Tees | Stub Ends | |||
| (mm) | (inches) | Length (inches) |
Center to End (inches) |
Center to End (inches) |
Lap Diameter (inches) |
Long Length (inches) |
Short Length (inches) |
|
| 1 | 33.4 | 1.315 | 1 1/2 | 1 1/2 | 1 1/2 | 2 | 4 | 2 |
| 1/2 | 21.3 | 0.840 | 1 | – | 1 | 1 3/8 | 3 | 2 |
| 3/4 | 26.7 | 1.050 | 1 | – | 1 1/8 | 1 11/16 | 3 | 2 |
| 1 1/4 | 42.2 | 1.660 | 1 1/2 | 1 7/8 | 1 7/8 | 2 1/2 | 4 | 2 |
| 1 1/2 | 48.3 | 1.900 | 1 1/2 | 2 1/4 | 2 1/4 | 2 7/8 | 4 | 2 |
| 2 | 60.3 | 2.375 | 1 1/2 | 2 1/2 | 2 1/2 | 3 5/8 | 6 | 2 1/2 |
| 2 1/2 | 73.0 | 2.875 | 1 1/2 | 3 | 3 | 4 1/8 | 6 | 2 1/2 |
| 3 | 88.9 | 3.500 | 2 | 3 3/8 | 3 3/8 | 5 | 6 | 2 1/2 |
| 3 1/2 | 101.6 | 4.000 | 2 1/2 | 3 3/4 | 3 3/4 | 5 1/2 | 6 | 3 |
| 4 | 114.3 | 4.500 | 2 1/2 | 4 1/8 | 4 1/8 | 6 3/16 | 6 | 3 |
| 5 | 141.3 | 5.563 | 3 | 4 7/8 | 4 7/8 | 7 5/16 | 8 | 3 |
| 6 | 168.3 | 6.625 | 3 1/2 | 5 5/8 | 5 5/8 | 8 1/2 | 8 | 3 1/2 |
| 8 | 219.1 | 8.625 | 4 | 7 | 7 | 10 5/8 | 8 | 4 |
| 10 | 273.1 | 10.750 | 5 | 8 1/2 | 8 1/2 | 12 3/4 | 10 | 5 |
| 12 | 323.9 | 12.750 | 6 | 10 | 10 | 15 | 10 | 6 |
ASME B16.9 Alloy Steel WP11 Concentric & Eccentric Reducer Dimensions
| Nominal Pipe Size |
Outside Diameter | Reducers | ||
| Reduced from (inches) |
(mm) | (inches) | Reduced to (inches) | Concentric & Eccentric Length (inches) |
| 1 | 33.4 | 1.315 | 3/8 | 2 |
| 1/2 | 2 | |||
| 3/4 | 2 | |||
| 1/2 | 21.3 | 0.840 | 1/4 | 1 1/2 |
| 3/8 | 1 1/2 | |||
| 3/4 | 26.7 | 1.050 | 3/8 | 2 |
| 1/2 | 2 | |||
| 1 1/4 | 42.2 | 1.660 | 1/2 | 2 |
| 3/4 | 2 | |||
| 1 | 2 | |||
| 1 1/2 | 48.3 | 1.900 | 1/2 | 2 1/2 |
| 3/4 | 2 1/2 | |||
| 1 | 2 1/2 | |||
| 1 1/4 | 2 1/2 | |||
| 2 | 60.3 | 2.375 | 3/4 | 3 |
| 1 | 3 | |||
| 1 1/4 | 3 | |||
| 1 1/2 | 3 | |||
| 2 1/2 | 73.0 | 2.875 | 1 | 3 1/2 |
| 1 1/4 | 3 1/2 | |||
| 1 1/2 | 3 1/2 | |||
| 2 | 3 1/2 | |||
| 3 | 88.9 | 3.500 | 1 | 3 1/2 |
| 1 1/2 | 3 1/2 | |||
| 2 | 3 1/2 | |||
| 2 1/2 | 3 1/2 | |||
| 3 1/2 | 101.6 | 4.000 | 1 1/4 | 4 |
| 1 1/2 | 4 | |||
| 2 | 4 | |||
| 2 1/2 | 4 | |||
| 3 | 4 | |||
| 4 | 114.3 | 4.500 | 1 1/2 | 4 |
| 2 | 4 | |||
| 2 1/2 | 4 | |||
| 3 | 4 | |||
| 3 1/2 | 4 | |||
| 5 | 141.3 | 5.563 | 2 | 5 |
| 2 1/2 | 5 | |||
| 3 | 5 | |||
| 3 1/2 | 5 | |||
| 4 | 5 | |||
| 6 | 168.3 | 6.625 | 2 1/2 | 5 1/2 |
| 3 | 5 1/2 | |||
| 3 1/2 | 5 1/2 | |||
| 4 | 5 1/2 | |||
| 5 | 5 1/2 | |||
| 8 | 219.1 | 8.625 | 3 | 6 |
| 3 1/2 | 6 | |||
| 4 | 6 | |||
| 5 | 6 | |||
| 6 | 6 | |||
| 10 | 273.1 | 10.750 | 4 | 7 |
| 5 | 7 | |||
| 6 | 7 | |||
| 8 | 7 | |||
| 12 | 323.9 | 12.750 | 5 | 8 |
| 6 | 8 | |||
| 8 | 8 | |||
| 10 | 8 | |||
A234 WP11 Alloy Steel Buttweld Fittings Weights(Kg)
| Product range and theoretical weights (kg) | |||||||||
| DN | Schedule 10S | Schedule 40S | Schedule 80S | ||||||
| 90° Elbow | 45° Elbow | Equal tee | 90° Elbow | 45° Elbow | Equal tee | 90° Elbow | 45° Elbow | Equal tee | |
| 8 | 0.02 | 0.01 | 0.03 | 0.03 | 0.02 | 0.06 | 0.04 | 0.03 | 0.07 |
| 10 | 0.03 | 0.02 | 0.05 | 0.03 | 0.02 | 0.03 | 0.06 | 0.04 | 0.09 |
| 15 | 0.06 | 0.03 | 0.09 | 0.08 | 0.04 | 0.10 | 0.10 | 0.05 | 0.14 |
| 20 | 0.07 | 0.03 | 0.13 | 0.08 | 0.04 | 0.17 | 0.11 | 0.05 | 0.20 |
| 25 | 0.14 | 0.08 | 0.28 | 0.15 | 0.11 | 0.29 | 0.22 | 0.14 | 0.38 |
| 32 | 0.23 | 0.11 | 0.49 | 0.26 | 0.17 | 0.59 | 0.40 | 0.23 | 0.68 |
| 40 | 0.30 | 0.17 | 0.68 | 0.40 | 0.23 | 0.86 | 0.51 | 0.29 | 1.02 |
| 50 | 0.50 | 0.25 | 0.85 | 0.70 | 0.4 | 1.28 | 0.91 | 0.59 | 1.59 |
| 65 | 0.85 | 0.48 | 1.41 | 1.40 | 0.77 | 2.19 | 1.81 | 0.99 | 3.13 |
| 80 | 1.25 | 0.63 | 1.77 | 2.20 | 1.08 | 3.31 | 2.97 | 1.50 | 4.45 |
| 90 | 1.70 | 0.75 | 2.67 | 2.83 | 1.42 | 4.08 | 4.00 | 2.00 | 5.44 |
| 100 | 2.10 | 1.08 | 3.46 | 4.47 | 2.09 | 5.27 | 6.18 | 2.81 | 7.71 |
| 150 | 5.45 | 2.72 | 8.07 | 10.89 | 5.44 | 10.99 | 16.32 | 8.16 | 13.61 |
| 200 | 10.20 | 5.33 | 15.65 | 21.54 | 10.77 | 20.91 | 33.11 | 16.56 | 28.12 |
| 250 | 18.15 | 9.75 | 26.46 | 38.56 | 19.27 | 35.38 | 51.71 | 25.86 | 49.90 |
| 300 | 25.80 | 13.62 | 39.46 | 59.42 | 29.71 | 62.14 | 79.38 | 39.69 | 83.91 |
| Product range and theoretical weights (kg) | |||||||||
| DN | Schedule 10S | Schedule 40S | Schedule 80S | ||||||
| Con reducer | Ecc reducer | Reducing tee | Con reducer | Ecc reducer | Reducing tee | Con reducer | Ecc reducer | Reducing tee | |
| 40x.25 | 0.19 | 0.19 | 0.60 | 0.26 | 0.26 | 0.76 | 0.34 | 0.34 | 0.90 |
| 50x25 | 0.28 | 0.28 | 0.73 | 0.40 | 0.40 | 1.10 | 0.54 | 0.54 | 1.37 |
| 50x40 | 0.31 | 0.31 | 0.76 | 0.45 | 0.45 | 1.15 | 0.59 | 0.59 | 1.43 |
| 80x.50 | 0.55 | 0.55 | 1.56 | 1.00 | 1.00 | 2.91 | 1.79 | 1.79 | 3.91 |
| 100x50 | 0.78 | 0.78 | 2.94 | 1.50 | 1.50 | 4.48 | 1.95 | 1.95 | 6.55 |
| 100x80 | 0.87 | 0.87 | 3.04 | 1.74 | 1.74 | 4.64 | 2.33 | 2.33 | 6.79 |
| 150x80 | 1.82 | 1.82 | 6.86 | 3.95 | 3.95 | 9.68 | 5.51 | 5.51 | 11.57 |
| 150x100 | 1.96 | 1.96 | 7.10 | 4.07 | 4.07 | 11.94 | 5.96 | 5.96 | 11.97 |
| 200x100 | 3.01 | 3.01 | 13.46 | 6.55 | 6.55 | 17.98 | 9.23 | 9.23 | 24.18 |
| 200x150 | 3.19 | 3.19 | 14.08 | 6.74 | 6.74 | 18.82 | 10.12 | 10.12 | 25.31 |
Ready Stock Alloy Steel A234 WP11 Pipe Fittings
- Sch 80 Alloy Steel WP11 Pipe Fittings
- Alloy Steel A234 WP11 Buttweld Fittings In Indonesia
- A234 WP11 Alloy Steel Pipe Fittings Manufacturer
- A234 WP11 Alloy Steel Pipe Elbow In Malaysia
- Alloy Steel WP11 Seamless Fittings In Mexico
- Alloy Steel WP11 Mandrel Pipe Bend In Philippines
- SCH 60 WP11 Alloy Steel Pipe Nipples
- Alloy Steel A234 WP11 Butt Weld Pipe Fittings In Japan
- ANSI B16.9 Alloy Steel A234 WP11 Pipe Cap
- Cr-Mo WP11 Eccentric Reducer Manufacturer
- Chrome Moly WP11 Butt weld Fittings In Italy
- Chrome Moly WP11 Pipe Fittings In Spain
- Cr-Mo WP11 1D Elbow/3D Elbow/5D Elbow
- Cr-Mo WP11 Reducing Nipple In Kuwait
- Alloy Steel WP11 Swage Nipple
- Chromium Molybdenum WP11 180° LR Return Bends
- A234 WP11 Alloy Steel Lap Joint Stub End
- 5" Nb Sch10s CrMo WP11 90° Short Radius Elbow
- Chromium Molybdenum WP11 SR Elbow In Singapore
- DIN 2605 Alloy Steel WP11 Elbow Exporter
- Cr-Mo WP11 Long Radius Elbow In Indonesia
- ASTM A234 CRMO WP11 Buttweld Fittings
- Alloy Steel A234 WP11 Reducer In Malaysia
- Alloy Steel A234 WP11 Pipe Bend
- Cr-Mo WP11 LR Elbow Stockist
- ASME SA234 WP11 Alloy Steel Lateral Tee
- A234 WP11 Alloy Steel Buttweld Nipple
- ASTM A234 CRMO WP11 Stub End
- Alloy Steel A234 WP11 Welded Fittings In Mexico
- Alloy Steel A234 WP11 Long Stub End In Philippines
- Schedule 80 Cr-Mo WP11 Grade Long Stub End
- Alloy Steel WP11 Two Halve Butt weld Fittings In Japan
- Alloy Steel A234 WP11 Piggable Bends
- 15 NB SCH 10 CrMo WP11 90° Short Radius Elbow
- ASME B16.9 Alloy Steel A234 WP11 Buttweld Fittings
- Cr-Mo WP11 Two Joint Pipe Fittings
- Cr-Mo WP11 Barrel Nipple Supplier in Mumbai
- ASTM A234 CRMO WP11 45 Degree Elbow In Kuwait
- 1/2” - 16” ASTM A234 CRMO WP11 Butt weld Elbow
- Cr-Mo WP11 End Cap Distributor
- A234 WP11 Alloy Steel Equal Cross In Spain
- ASTM A234 Alloy Steel WP11 Pipe Fittings
- Alloy Steel WP11 Long Radius Bend Stockholder
- ANSI B16.9 Alloy Steel WP11 Short Stub End
- ASME B16.9 Schedule 10 A234 WP11 Alloy Steel Elbow
- A234 WP11 Alloy Steel Butt weld Tee
- Cr-Mo WP11 Eccentric Reducer In Italy
- A234 WP11 Alloy Steel Elbow In Singapore
Alloy Steel A234 WP11 Butt weld Fittings Chemical Composition
| Grade | C | Mn | Si | S | P | Cr | Mo |
|---|---|---|---|---|---|---|---|
| A234 WP11 | 0.05-0.2 | 0.3-0.8 | 0.5-1 | ≤0.030 | ≤0.030 | 1-1.5 | 1-1.5 |
A234 WP11 Alloy Steel Pipe Fittings Mechanical Properties
| Grade | Tensile Strength (Mpa) | Yield Strength (Mpa) | Elongation % |
|---|---|---|---|
| A234 WP11 | 415 – 585 | ≥205 | ≥20 |
