ASTM A193 B6 Fasteners

ASTM A193 B6 Bolts, ASTM A193 Grade B6 Nuts, ASTM A193 B6 Washers, ASTM A193 Grade B6 Fasteners, ASTM A193 B6 Stud Bolts Price in India.

Bagoda Steel is a customary manufacturer of ASTM A193 Grade B6 Fasteners, which is right for sea water applications. Additionally, it grants sturdy strength traits at extended temperatures-as much as 2200 levels Fahrenheit. It in reality well-known shows true ductility after extended publicity at temperatures of 1200 Degree F, 1400 Degree F, 1600 Degree F (650 Degree C, 760 Degree C and 870 Degree C) for 16,000 hours. Stainless Steel ASTM A193 Grade B6 Nuts is one of the maximum extensively used nickel base super-alloys for fueloline turbine engine components. Electropolishing or passivation of these fasteners can enhance corrosion resistance. It has as nicely been located to be fairly proof against pressure-corrosion cracking in petrochemical applications. It has additionally been located to be fairly proof against pressure-corrosion cracking in petrochemical applications.

Industrial Product
ASTM A193 B6 Fasteners

ASTM A193 B6 Anchor Bolts, ASTM A193 B6 Allen Cap Screw, ASTM A193 B6 Nuts, ASTM A193 B6 Threaded Rod, ASTM A193 B6 Carriage Bolts Stockist, ASTM A193 Grade B6 Screws, ASTM A193 Grade B6 Flat Washers, A193 B6 Hex Bolts, ASTM A193 B6 Fasteners Supplier in Mumbai, India.

+91 22 - 66151721
sales@bagodasteelproject.com
+91 9011334411

Applications of these fasteners in air pollutants manipulate consist of ducts, dampers, stack liners, scrubbers, stack - fueloline re - heaters, enthusiasts and fan housings. Like different nickel alloys, Stainless Steel ASME SA 193 Grade B6 Bolts is simple to form, ductile, it is simple to weld, and possesses super resistance to pressure corrosion cracking in chloride - bearing solutions. It is a wrought alloy this is typically taken into consideration a flexible corrosion – resistant alloy. Because of splendid corrosion resistant capabilities, it's far utilized by a huge form of industries for critical applications. It keeps superb corrosion resistance in a wide form of chemical method and aqueous environments.

It is one of the few alloys proof against moist chloride fueloline, hypochlorite and chlorine dioxide solutions. The proscribing aspect of these fasteners whilst handling sturdy oxidizing environments is the low Cr content, because of this that that hot, focused nitric acid environments are NOT desirable. Furthermore, it's far very proof against sulphide pressure cracking and pressure corrosion cracking in sour, oilfield environments. Although there are numerous versions of the nickel alloy, it's far through a ways the maximum extensively used. SS ASTM A193 Grade B6 Washers well-known shows splendid resistance to each oxidizing and lowering acid environments in addition to the ones containing blended acids.

Standard Specification For ASTM A193 B6 Fasteners

Specification ASTM A193 / ASME SA193
Dimensions ASME B18.2.1, B18.3
Size M02 to M160, Custom Sizes
Length 3 mm to 200 mm
Threads METRIC, BSW, BSF, UNC, UNF or as required
In Form of Hex, Square, Round, Threading as per Gauge Etc.
Test Certificate: Manufacturer Test Certificate as per EN 10204 / 3.1
Surface finishing Zinc (yellow, white, blue, black), black oxide, Geometry, Dacroment, anodizing, nickel plated, plated zinc-nickel, Stainless steel: Passivated Self-Colour, Hot Dip Galvanised (HDG), Bright Zinc Plated (BZP), Sherardized, Stainless Steel, Mechanically Applied coating and some special one like DACROMET
Production process M2-M24: Cold Froging, hot forging M24-M100, machining and CNC for Customized connecting element
Surface Coating
  • Teflon Coated Fasteners
  • Phosphate Coated Fasteners
  • Zinc Coated Fasteners
  • Ptfe Coated
  • Xylon Coated Fasteners
  • Cadmium Coated Fasteners
  • Hot Dipped Galvanizing Coated Fasteners
All surface finishes offered including Geomet & PTFE, Galvanised, Zinc, Electroless Nickel, Sherardized, Dacromet
Packing IN BULK: canton, pallet, Small Boxs / carton / pallet, or customer request

ASTM A193 Grade B6 Raw Material

GradeDescription
ASTM A193 B6 Bolts(AISI 410 Stainless Steel) 13% Chromium Ferritic Steel

ASTM A193 B6 Fasteners Manufacturing Standards

Hexagon Bolt / Set Screws Stud Bolt Hexagon Nuts Socket Cap screws
DIN 931 BS4882 DIN 934 DIN 912
DIN 933 DIN 976 BS 1768 DIN 6912
BS 1768 BS 1769 DIN 7984
UNI 5731 BS 1083 ANSI B18.3
UNI 5739 BS 3692 ISO 4762
ISO 4014 ISO 4032 UNI 5931
ISO 4017 ISO 4033 BS 2470
BS 1769 ANSI B18.2.2 BS 4168
BS 3692
ANSI B18.2.1
Socket & Slotted Set Screws Socket & Slotted Countersunk Screws Studs Washers
DIN 913 DIN 963 DIN 938 DIN 125
DIN 914 DIN 7991 DIN 939 DIN 9021

Various Types Of ASTM A193 B6 Fasteners

ASTM A193 B6 Bolts
ASTM A193 B6 Bolts
  • ASTM A193 Grade B6 Bolts
  • ASTM A193 B6 Bolts
  • ASTM A193 Grade B6 Hex Bolts
  • ASTM A193 B6 Heavy Hex Bolts
ASTM A193 B6 Screw
ASTM A193 B6 Screw
  • ASTM A193 B6 Screw
  • ASTM A193 B6 Hex Cap Screws
  • ASTM A193 Grade B6 Screw
  • ASTM A193 B6 q Set Screws
  • ASTM A193 Grade B6 Allen Cap Screw
ASTM A193 B6 Stud Bolts
ASTM A193 B6 Stud Bolts
  • ASTM A193 Grade B6 Stud Bolts
  • ASTM A193 Gr B6 Bolts
  • ASTM A193 B6 Stud Bolts
  • ASTM A193 B6 Stud
ASTM A193 B6 Hex Bolts
ASTM A193 B6 Hex Bolts
  • ASTM A193 Grade B6 Hex Bolts
  • ASTM A193 Gr B6 Hex Bolts
  • ASTM A193 B6 Heavy Hex Bolts
  • ASTM A193 B6 Hex Head Bolts
Fasteners Dimensions

View Size Table Of ASTM A193 B6 Fasteners, We have Global sales network for ASTM A193 Grade B6 Stud Bolts, Wide Stockist Of ASTM A193 Gr B6 Nuts, Bolts, Washers In India.

Dimensions Of ASTM A193 B6 Bolts

**All measurements in millimeters**
NOMINAL SIZE (D) BODY DIAMETER HEAD THICKNEASTM A193 ACROASTM A193 THE FLATS ACROASTM A193 CORNERS
D (MAX) D (MIN) H (MAX) H (MIN) F (MAX) F (MIN) C (MAX) C (MIN)
m10 10.00 9.78 6.63 6.17 17.00 15.73 18.48 17.77
m12 12.00 11.73 7.76 4.24 19.00 17.73 20.78 20.03
m14 14.00 13.73 9.09 8.51 22.00 20.67 24.25 23.35
m16 16.00 15.73 10.32 9.68 24.00 23.67 27.71 26.75
m20 20.00 19.67 12.88 12.12 30.00 29.16 34.64 32.95
m24 24.00 23.67 15.44 14.56 36.00 35.00 41.57 39.55
m30 30.00 29.67 19.48 17.92 46.00 45.00 53.12 50.85
m36 36.00 35.61 23.38 21.63 55.00 53.80 63.51 60.79
m42 42.00 41.38 26.97 25.03 65.00 62.90 75.06 71.71
m48 48.00 47.38 31.07 28.93 75.00 72.60 86.60 82.76
m56 56.00 55.26 36.2 33.80 85.00 82.20 98.15 93.71
m64 64.00 63.26 41.32 38.68 95.00 91.80 109.70 104.65
m72 72.00 71.26 46.45 43.55 105.00 101.40 121.24 115.60
m80 80.00 79.26 51.58 48.42 115.00 111.00 132.72 126.54
m90 90.00 89.13 57.74 54.26 130.00 125.50 150.11 143.07
m100 90.00 99.13 63.9 60.10 145.00 140.00 167.43 159.60

Check available Sizes of ASTM A193 B6 Stud Bolt, Ask For Ready Stock of ASTM A193 Grade B6 Fasteners in Mumbai, India.

BAGODA

Quick Contact

ASTM A193 B6 Bolts Weight Chart

MM THREADS AS PER IS 1363/67
APPROXIMATE WEIGHT IN KGS FOR 100 NOS
LENGTH DIAMETER
M 5 M 6 M 8 M 10 M 12 M 14 M 16 M 18 M 20 M 22
16 mm 0.448 0.743 1.590 3.211
20 mm 0.598 0.812 1.711 3.411 4.892
25 mm 0.660 0.897 1.871 3.660 5.252 8.170
30 mm 0.737 1.010 2.070 3.912 5.574 9.690 10.707 18.657
35 mm 0.804 1.120 2.271 4.223 5.974 10.000 11.416 16.026 19.608
40 mm 0.881 1.230 2.470 4.533 6.410 10.288 12.107 16.667 20.747
45 mm 0.958 1.340 2.671 4.840 6.859 10.504 12.821 17.241 21.739
50 mm 1.030 1.450 2.870 5.155 7.299 11.261 13.624 17.857 22.727 28.409
55 mm 1.560 3.071 5.464 7.740 11.628 14.409 18.868 23.810 30.120
60 mm 1.670 3.270 5.774 8.183 12.255 15.244 20.000 25.126 32.051
65 mm 1.781 3.472 6.083 8.621 12.626 16.026 21.008 26.455 34.014
70 mm 1.890 3.671 6.394 9.058 12.987 16.835 22.124 27.778 35.461
75 mm 2.000 3.873 6.702 9.506 13.228 17.606 23.256 29.070 39.063
80 mm 2.111 4.072 7.013 10.000 13.889 18.248 24.510 30.303 40.000
90 mm 4.472 7.634 10.917 14.925 19.841 26.042 33.113 41.667
100 mm 4.873 8.251 11.820 16.340 21.459 27.778 35.714 46.296
110 mm 8.881 12.723 17.730 23.041 31.250 38.168 47.170
120 mm 9.506 13.624 18.797 24.631 32.895 40.984 50.000
130 mm 10.101 14.535 20.000 26.316 34.722 43.478 52.632
140 mm 10.707 15.432 20.833 27.933 35.461 46.296 55.556
150 mm 11.312 16.340 22.222 29.412 37.594 48.544 58.824
160 mm 11.905 17.241 24.272 31.056 40.984 50.505 61.728
170 mm 12.500 18.116 32.680 53.191 64.935
180 mm 13.123 19.011 26.882 34.247 55.556 67.568
190 mm 13.736 19.920 35.971 58.140 70.423
200 mm 14.327 20.833 29.586 37.594 49.020 60.976 73.529
220 mm 15.528 22.624 40.650 65.789 79.365
240 mm 16.722 24.510 43.860 71.429 84.746
250 mm 17.301 25.381 45.455 74.627 87.719
260 mm 17.921 26.316 47.170 76.923 90.909
280 mm 19.157 28.090 50.505 81.967 98.039
300 mm 20.325 29.940 53.763 87.719 104.167
320 mm 31.646 56.818 92.593
340 mm 33.557 60.241 98.039
360 mm 35.211 63.291 104.167
380 mm 37.037 66.667 108.696
400 mm 39.063 69.444 113.636

ASTM A193 B6 Stud Bolts Dimensions

Diameter Diameter in mm Diameter in inch Nut Sizes
M12 12 0.4724 19
M10 10 0.3937 17
M14 14 0.5512 22
M18 18 0.7087 27
M16 16 0.6299 24
M20 20 0.7874 30
M24 24 0.9449 36
M22 22 0.8661 32
M27 27 1.063 41
M33 33 1.2992 50
M30 30 1.1811 46
M36 36 1.4173 55
M42 42 1.6535 65
M39 39 1.5354 60
M45 45 1.7717 70
M52 52 2.0472 80
M48 48 1.8898 75
M56 56 2.2047 85
M64 64 2.5197 95
M60 60 2.3622 90
M68 68 2.6772 100
M76 76 2.9921 110
M72 72 2.8346 105
M80 80 3.1496 115
M90 90 3.5433 130
M85 85 3.3464 120
M100 100 3.937 145
M160 160 6.2992 230
M125 125 4.9212 180
M110 110 4.3307 155
M140 140 5.5118 200

ASTM A193 B6 Studs Torque Chart

BOLT
DIA		 Torque FT-LBS
30% Initial
Torque		 70%
Torque		 100% Final
Torque
1/2 16 36 52
9/16 23 53 75
5/8 31 73 104
3/4 55 129 184
7/8 71 166 237
1 107 249 356
1.1/8 127 297 424
1.1/4 179 417 596
1.3/8 186 435 622
1.1/2 246 574 821
1.9/16 168 392 560
1.5/8 191 445 636
1.3/4 240 561 801
1.7/8 298 696 994
2 366 853 1219
2.1/4 529 1234 1762
2.1/2 733 1709 2442
2.3/4 986 2300 3285
3 1289 3008 4297

Ready Stock ASTM A193 B6 Fasteners

  • ASTM A193 B6 Elevator Bolt
  • ASTM A193 B6 Acorn Nuts
  • ASTM A193 B6 Hex Washers
  • ASTM A193 Grade B6 Fasteners
  • ASTM A193 B6 Anchor Bolts
  • ASTM A193 B6 Tie Rods
  • ASTM A193 Gr B6 T-Head Bolts
  • ASTM A193 B6 Square Nuts
  • ASTM A193 Grade B6 Self Locking Nuts
  • ASTM A193 B6 Customized Washer
  • ASTM A193 B6 Structural Bolts
  • ASTM A193 B6 Stud Bolts
  • ASTM A193 Gr B6 Hex Domed Cap Nuts
  • ASTM A193 B6 Fasteners
  • ASTM A193 Grade B6 Wing Nuts
  • ASTM A193 B6 Hex Coupling Nut
  • ASTM A193 B6 Bolts
  • ASTM A193 Grade B6 Hex Head Bolts
  • ASTM A193 B6 Heavy Hex Nuts
  • ASTM A193 B6 Hex Set Screw Manufacturer
  • ASTM A193 Grade B6 Wing Nuts
  • ASTM A193 Grade B6 Allen Cap Screw
  • ASTM A193 B6 Double Ended Stud
  • ASTM A193 B6 Dock Washer Stockholder
  • ASTM A193 Gr B6 Countersunk Washer
  • ASTM A193 Gr B6 Socket Cap Screw
  • ASTM A193 B6 Foundation Bolts Manufacturer
  • ASTM A193 B6 Flat Washers
  • ASTM A193 B6 Nyloc Nuts
  • ASTM A193 Grade B6 Stud Bolts
  • ASTM A193 B6 Hexagonal Washer
  • ASTM A193 B6 Lock Nut
  • ASTM A193 B6 Threaded Rod
  • ASTM A193 Grade B6 Split / Lock Washer
  • ASTM A193 Gr B6 Eye Bolts
  • ASTM A193 Gr B6 Machine Fasteners Exporter
  • ASTM A193 Gr B6 Carriage Bolt Stockist
  • ASTM A193 Gr B6 Fasteners
  • ASTM A193 B6 Washers
  • ASTM A193 B6 Fender Washer
  • ASTM A193 B6 Hex Head Bolt
  • ASTM A193 B6 Plain Washer Supplier in Mumbai
  • ASTM A193 B6 Flange Bolt
  • ASTM A193 Gr B6 Machine Bolt
  • ASTM A193 Gr B6 Screws Distributor
  • ASTM A193 B6 Heavy Hex Bolts
  • ASTM A193 Grade B6 Tooth Lock Washer
  • ASTM A193 Grade B6 Concrete Screw
  • ASTM A193 B6 Coupling Nut
  • ASTM A193 Grade B6 Bolts
  • ASTM A193 B6 Ogee Washer

ASTM A193 B6 Fasteners Chemical Composition

Grade C Mn Si P S Cr
ASTM A193 B6 0.15 max. 1.00 max 1.00 max 0.040 max 0.030 max 11.5-13.5

ASTM A193 B6 Mechanical Properties

Yeild strength Mpa minTensile strength Mpa minElongation % minReduction
5857601550
