Copper Nickel 90 / 10 Hex Nuts, Cupro Nickel 90 / 10 Hex Nuts, Cu-Ni 90 / 10 Heavy Hex Nuts Manufacturer

Cu-Ni 90 / 10 Hexagonal Nylon Lock Nut, Copper Nickel 90 / 10 Machine Hex Nut, UNS C70600 Hex Flange Nut, CuNi 90 / 10 Long Hex Nuts, Cu-Ni 90 / 10 Finished Hex Nut Stockist, ASTM B151 Copper Nickel 90 / 10 Industrial Hex Nut, 2.0872 Hex Nuts, Cupro Nickel 90 / 10 Hex Jam Nuts Supplier in Mumbai, India.

It has a unique chemistry designed to gain a degree of thermal balance significantly advanced to that of its predecessors.However, whilst machining, these alloys work harden greater unexpectedly and require greater electricity to reduce than undeniable carbon steels. However, it isn't always immune to lowering sulfurizing atmospheres, whilst sulphur is ability as H2S.Liquid quenching in our alloys is impractical (due to the threat of cracking or distortion or due to cost).The exceptional of these alloys is ensured through the Quality Assurance procedures. Copper Nickel UNS C70600 Hex Nuts imparts specific upgrades in Roughness, Hardness and Wear resistance of the samples thereby widening the applications of the material.

They are being utilized in Hardware, Petro - Chemical Industry, Oil and Gas Industry, Nuclear Industry, etc.They are frequently particular whilst high strength is wanted in moderate – to – big sections.Where weight is important, it can be profitable to evaluate specific properties of alloys, e.g. the specific strength. Copper Nickel WNR 2.0872 Hex Nuts gives incredibly excessive iron content material that offers higher impingement assault resistance.They are tremendous for applications that want excessive creep - rupture strength and capacity to be welded with materials which have adequate strength properties on the preferred provider temperatures.It has been examined in extraordinarily annoying situations requiring excessive strength and notable abrasion resistance.

Material Specification Chart of Copper Nickel 90 / 10 Hex Nuts

Size	M3 – M56 \| 3/6″ to 2″ \| Custom Sizes
Length	3 mm to 200 mm
Hex Nuts	UNF, BSW, BSF, METRIC, UNC, or as required
Standard	DIN : DIN 934, DIN 931, DIN 970, DIN 933 UTS : UNEF, NPT, UNC, UNS, UNF, NPTF ISO : JIS standards, ISO 4033, ISO 4032, ANSI – American National Standards Institute ASME B18.5 ANSI B 28.2.4 1M ANSI B 18.2.4 2M as per defined in ASME B18.2.2 Hex nuts
Form	Hex, Threading, Square, Round as per Gauge Etc.
Threads Configuration	ASME B1.1 2A/3A – 2B/3B Inch Unified Threads and B1.13M 6h-6G Metric Coarse Threads
Certification	Dual Certified As per ASTM & ASME Codes
Dimensions	DIN 931, 933, 934, 7991, 976, 125, ASME B18.2.1, B18.3
Threads	Unless otherwise specified, the threads shall be rolled or cut and tapped horizontally or vertically
Test Certificate	as per EN 10204 / 3.1 Manufacturer Test Certificate
Additional Certifications	PED 97/23/EC Certified, Merkblatt AD 2000 W2 Certified
Production process	M24-M100: hot forging , M2-M24: Cold Froging, for custom-made connecting element machining and CNC
Head drive	Six-Lobe,Phillips,Phillips/Slot, Slotted etc
Surface Coating	Ptfe Coated Nuts Phosphate Coating Teflon Coating Zinc Coating Hot Dipped Galvanizing Coating Cadmium Coating Xylon Coating
Finishing	Coatings & Finishes : Self-Colour, Passivated, Bright Zinc Plated (BZP), Hot Dip Galvanised (HDG), Sherardized, some special one like DACROMET Geometry and Mechanically Applied coating ,Dacroment, nickel plated, anodizing, plated zinc-nickel Zinc (blue, black, yellow, white), black oxide

Various Types Of Copper Nickel 90 / 10 Hex Nuts

Copper Nickel 90 / 10 Hex Jam Nut

Copper Nickel 90 / 10 Heavy Hex Jam Nuts
UNS C70600 Hex Jam Nuts
2.0872 Hex Jam Nuts
Cu-Ni 90 / 10 Hex Jam Nut
CuNi 90 / 10 Hex Jam Nut

Copper Nickel 90 / 10 Heavy Hex Nut

2.0872 Heavy Hex Nuts
CuNi 90 / 10 Heavy Hex Nut
Cu-Ni 90 / 10 Heavy Hex Nuts
Copper Nickel 90 / 10 Heavy Hex Nut
UNS C70600 Heavy Hex Nuts

Copper Nickel 90 / 10 Hex Flange Nut

Copper Nickel 90 / 10 Hex Flange Nut
CuNi 90 / 10 Flange Hex Nuts
2.0872 Hex Flange Nuts
Cu-Ni 90 / 10 Hex Flange Nut
UNS C70600 Hex Flange Nut

Copper Nickel 90 / 10 Slotted Hex Nut

UNS C70600 Slotted Hex Nuts
Copper Nickel 90 / 10 Slotted Hex Nut
Cu-Ni 90 / 10 Slotted Hex Nuts
2.0872 Beveled Slotted Hex Nut
Cupro Nickel 90 / 10 Slotted Hex Nuts

Copper Nickel 90 / 10 Machine Hex Nut

2.0872 Machine Hex Nuts
Cu-Ni 90 / 10 Machine Hex Nut
Copper Nickel 90 / 10 Machine Hex Nuts
Cupro Nickel 90 / 10 Machine Hex Nut
UNS C70600 Machine Hex Nuts

Copper Nickel 90 / 10 Long Hex Nut

2.0872 Hex Coupling Nuts
Copper Nickel 90 / 10 Coupling Hex Nuts
Cu-Ni 90 / 10 Long Hex Nuts
UNS C70600 Long Hex Nuts
CuNi 90 / 10 Long Hex Nuts

Equivalent Grades of Copper Nickel 90 / 10 Hex Nuts

STANDARD	WERKSTOFF NR.	UNS
Cupro Nickel 90/10	2.0872	C70600

View Size Table Of Copper Nickel 90 / 10 Hex Nuts, We have Global sales network for Cupro Nickel 90 / 10 Heavy Hex Nuts, Wide Stockist Of Werkstoff No 2.0872 Hex Head Nuts, Industrial Hex Nuts In India.

Dimensions of Copper Nickel 90 / 10 Hex Nuts

Nominal Size	Basic Major Diameter of Thread	F		G		H		H1		Maximum Runout of Bearing Surface to Thread Axis, FIM
		Width Across Flats		Width Across Corners		Thickness Hex Nuts		Thickness Jam Nuts		Hex Nuts		Hex Jam Nuts
		Min.	Max.	Min.	Max.	Min.	Max.	Min.	Max.	Specified Proof Load		Hex Jam Nuts
		Min.	Max.	Min.	Max.	Min.	Max.	Min.	Max.	Up to 150,000 psi	150,000 psi and Greater	All Strength Levels
1/4	0.2500	0.428	0.438	0.488	0.505	0.212	0.226	0.150	0.163	0.015	0.010	0.015
5/16	0.3125	0.489	0.500	0.557	0.577	0.258	0.273	0.180	0.195	0.016	0.011	0.016
3/8	0.3750	0.551	0.563	0.628	0.650	0.320	0.337	0.210	0.227	0.017	0.012	0.017
7/16	0.4375	0.675	0.688	0.768	0.794	0.365	0.385	0.240	0.260	0.018	0.013	0.018
1/2	0.5000	0.736	0.750	0.840	0.866	0.427	0.448	0.302	0.323	0.019	0.014	0.019
9/16	0.5625	0.861	0.875	0.982	1.010	0.473	0.496	0.301	0.324	0.020	0.015	0.020
5/8	0.6250	0.922	0.938	1.051	1.083	0.535	0.559	0.363	0.387	0.021	0.016	0.021
3/4	0.7500	1.088	1.125	1.240	1.299	0.617	0.665	0.398	0.446	0.023	0.018	0.023
7/8	0.8750	1.269	1.312	1.447	1.516	0.724	0.776	0.458	0.510	0.025	0.020	0.025
1	1.0000	1.450	1.500	1.653	1.732	0.831	0.887	0.519	0.575	0.027	0.022	0.027
1-1/8	1.1250	1.631	1.688	1.859	1.949	0.939	0.999	0.579	0.639	0.030	0.025	0.030
1-1/4	1.2500	1.812	1.875	2.066	2.165	1.030	1.094	0.687	0.751	0.033	0.028	0.033
1-3/8	1.3750	1.994	2.062	2.273	2.382	1.138	1.206	0.747	0.815	0.036	0.031	0.036
1-1/2	1.5000	2.175	2.250	2.480	2.598	1.245	1.317	0.808	0.880	0.039	0.034	0.039
1-5/8	1.6250	2.35	2.43	2.679	2.805	1.364	1.416	0.868	0.944	0.044	0.038	0.044
1-3/4	1.7500	2.538	2.625	2.893	3.031	1.460	1.540	0.929	1.009	0.048	0.041	0.048
1-7/8	1.8750	2.722	2.813	3.103	3.247	1.567	1.651	0.989	1.073	0.051	0.044	0.051
2	2.0000	2.900	3.000	3.306	3.464	1.675	1.763	1.050	1.138	0.055	0.047	0.055
2-1/4	2.2500	3.263	3.375	3.719	3.897	1.890	1.986	1.155	1.267	0.061	0.052	0.061
2-1/2	2.5000	3.625	3.750	4.133	4.330	2.105	2.209	1.401	1.427	0.068	0.058	0.068
2-3/4	2.7500	3.998	4.125	4.546	4.763	2.319	2.431	1.522	1.556	0.074	0.064	0.074
3	3.0000	4.350	4.500	4.959	5.196	2.534	2.654	1.643	1.685	0.081	0.070	0.081
3-1/4	3.2500	4.713	4.875	5.373	5.629	2.749	2.877	1.748	1.814	0.087	0.075	0.087
3-1/2	3.5000	5.075	5.250	5.786	6.062	2.964	3.100	1.870	1.943	0.094	0.081	0.094
3-3/4	3.7500	5.438	5.625	6.199	6.495	3.178	3.322	1.990	2.072	0.100	0.087	0.100
4	4.0000	5.800	6.000	6.612	6.928	3.393	3.545	2.112	2.201	0.107	0.093	0.107

Dimensions of Copper Nickel 90 / 10 Heavy Hex Nuts & Heavy Hex Jam Nuts

Nominal Size	Basic Major Diameter of Thread	F			G		H			H1			Maximum Runout of Bearing Surface to Thread Axis, FIM
		Width Across Flats			Width Across Corners		Thickness Heavy Hex Nuts			Thickness Heavy Hex Jam Nuts			Heavy Hex Nuts		Heavy Hex Jam Nuts
		Width Across Flats			Width Across Corners		Thickness Heavy Hex Nuts			Thickness Heavy Hex Jam Nuts			Specified Proof Load		Heavy Hex Jam Nuts
		Basic	Min.	Max.	Min.	Max.	Basic	Min.	Max.	Basic	Min.	Max.	Up to 150,000 psi	150,000 psi and Greater	All Strength Levels
1/4	0.2500	1/2	0.488	0.500	0.556	0.577	15/64	0.218	0.250	11/64	0.156	0.188	0.017	0.011	0.017
5/16	0.3125	9/16	0.546	0.562	0.622	0.650	19/64	0.280	0.314	13/64	0.186	0.220	0.020	0.012	0.020
3/8	0.3750	11/16	0.669	0.688	0.763	0.794	23/64	0.341	0.377	15/64	0.216	0.252	0.021	0.014	0.021
7/16	0.4375	3/4	0.728	0.750	0.830	0.866	27/64	0.403	0.441	17/64	0.247	0.285	0.022	0.015	0.022
1/2	0.5000	7/8	0.850	0.875	0.969	1.010	31/64	0.464	0.504	19/64	0.277	0.317	0.023	0.016	0.023
9/16	0.5625	15/16	0.909	0.938	1.037	1.083	35/64	0.526	0.568	21/64	0.307	0.349	0.024	0.017	0.024
5/16	0.6250	1-1/16	1.031	1.062	1.175	1.227	39/64	0.587	0.631	23/64	0.337	0.381	0.025	0.018	0.025
3/4	0.7500	1-1/4	1.212	1.250	1.382	1.443	47/64	0.710	0.758	27/64	0.398	0.446	0.027	0.020	0.027
7/8	0.8750	1-7/16	1.394	1.438	1.589	1.660	55/64	0.833	0.885	31/64	0.458	0.510	0.029	0.022	0.029
1	1.0000	1-5/8	1.575	1.625	1.796	1.876	63/64	0.956	1.012	35/64	0.519	0.575	0.031	0.024	0.031
1-1/8	1.1250	1-13/16	1.756	1.812	2.002	2.093	1-7/64	1.079	1.139	39/64	0.579	0.639	0.033	0.027	0.033
1-1/4	1.2500	2	1.938	2.000	2.209	2.309	1-7/32	1.187	1.251	23/32	0.687	0.751	0.035	0.030	0.035
1-3/8	1.3750	2-3/16	2.119	2.188	2.416	2.526	1-11/32	1.310	1.378	25/32	0.747	0.815	0.038	0.033	0.038
1-1/2	1.5000	2-3/8	2.300	2.375	2.622	2.742	1-15/32	1.433	1.505	27/32	0.808	0.880	0.041	0.036	0.041
1-5/8	1.6250	2-9/16	2.481	2.562	2.828	2.959	1-19/32	1.556	1.632	29/32	0.868	0.944	0.044	0.038	0.044
1-3/4	1.7500	2-3/4	2.662	2.750	3.035	3.175	1-23/32	1.679	1.759	31/32	0.929	1.009	0.048	0.041	0.048
1-7/8	1.8750	2-15/16	2.844	2.938	3.242	3.392	1-27/32	1.802	1.886	1-1/32	0.989	1.073	0.051	0.044	0.051
2	2.0000	3-1/8	3.025	3.125	3.449	3.608	1-31/32	1.925	2.013	1-3/32	1.050	1.138	0.055	0.047	0.055
2-1/4	2.2500	3-1/2	3.388	3.500	3.862	4.041	2-13/64	2.155	2.251	1-13/64	1.155	1.251	0.061	0.052	0.061
2-1/2	2.5000	3-7/8	3.750	3.875	4.275	4.474	2-29/64	2.401	2.505	1-29/64	1.401	1.505	0.068	0.058	0.068
2-3/4	2.7500	4-1/4	4.112	4.250	4.688	4.907	2-45/64	2.647	2.759	1-37/64	1.522	1.634	0.074	0.064	0.074
3	3.0000	4-5/8	4.475	4.625	5.102	5.340	2-61/64	2.893	3.013	1-45/64	1.643	1.763	0.081	0.070	0.081
3-1/4	3.2500	5	4.838	5.000	5.515	5.774	3-3/16	3.124	3.252	1-13/16	1.748	1.876	0.087	0.075	0.087
3-1/4	3.5000	5-3/8	5.200	5.375	5.928	6.207	3-7/16	3.370	3.506	1-15/16	1.870	2.006	0.094	0.081	0.094
3-3/4	3.7500	5-3/4	5.562	5.750	6.341	6.640	3-11/16	3.616	3.760	2-1/16	1.990	2.134	0.100	0.087	0.100
4	4.0000	6-1/4	5.925	6.125	6.755	7.073	3-15/16	3.862	4.014	2-3/16	2.112	2.264	0.107	0.093	0.107

Ready Stock Copper Nickel 90 / 10 Hex Nuts

CuNi 90 / 10 Long Hex Nut
CuNi 90 / 10 Heavy Hex Nuts
Copper Nickel 90 / 10 Heavy Hex Nuts
Cupro Nickel 90 / 10 Hex Jam Nuts
Copper Nickel 90 / 10 Hex Nuts Manufacturer
Copper Nickel 90 / 10 Heavy Hex Nuts
CuNi 90 / 10 Hex Socket Nut
Copper Nickel 90 / 10 Finished Hex Nuts
Copper Nickel 90 / 10 Serrated Hex Flange Nut
Cupro Nickel 90 / 10 Heavy Hexagon Nuts
Cupro Nickel 90 / 10 Self Locking Hex Nuts
Copper Nickel 90 / 10 Hex Round Nut
Copper Nickel 90 / 10 Industrial Hex Nuts Exporter
Copper Nickel 90 / 10 Hex Nuts
UNS C70600 Hex Nuts
CuNi 90 / 10 Hexagonal Nylon Lock Nut
ASTM B151 CuNi 90 / 10 Heavy Hex Nuts Distributor
CuNi 90 / 10 Slotted Hex Nuts
Copper Nickel 90 / 10 Hex Nut Manufacturer
Copper Nickel 90 / 10 Hex Machine Nut Stockist
Copper Nickel 90 / 10 Hexagon Nut Supplier in Mumbai
Copper Nickel 90 / 10 Hex Head Nut
ASME SB151 Copper Nickel 90 / 10 Flanged Hex Nuts Stockholder
Cu-Ni 90 / 10 Heavy Hex Jam Nuts
Copper Nickel 90 / 10 Hex Sleeve Nuts
DIN 2.0872 Hex Nuts
ASTM B151 Copper Nickel 90 / 10 Coupling Nuts
CuNi 90 / 10 Nylon Insert Lock Nuts
Copper Nickel 90 / 10 Machine Hex Nuts
CuNi 90 / 10 Hex Flange Nut
ASME SB151 Copper Nickel 90 / 10 Industrial Hex Nuts
CuNi 90 / 10 Semi-Finished Hex Nuts
Cupro Nickel 90 / 10 Slotted Hex Nuts
CuNi 90 / 10 Hexagon Nuts
2.0872 Thin Hex Nuts
Copper Nickel 90 / 10 Hexagonal Nylon Lock Nut

Copper Nickel 90 / 10 Hex Nuts Chemical Composition

Grade	Cu	Mn	Pb	Ni	Fe	Zn
Cupro Nickel 90/10	88.6 min	1.0 max	0.05 max	9-11 max	1.8 max	1 max

Copper Nickel 90 / 10 Hex Nuts Mechanical Properties

Element	Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
Cupro Nickel 90/10	0.323 lb/in3 at 68 F	2260 F	50000 psi	20000 psi	30 %

Copper Nickel 90 / 10 Hex Nuts

Copper Nickel 90 / 10 Hex Head Nut, Copper Nickel 90 / 10 Hexagonal Nut, Cupro Nickel 90 / 10 Hex Nuts, CuNi 90 / 10 Heavy Hex Nut, Cu-Ni 90 / 10 Hex Nuts Price in India.
