Ti Alloy Gr 5 Long Hex Nuts, Titanium Alloy Gr 5 Finished Hex Nut Stockist, 3.7165 Hex Nuts, Titanium Alloy Gr 5 Hex Jam Nuts, Ti Alloy Gr 5 Hexagonal Nylon Lock Nut, Titanium Gr 5 Machine Hex Nut, UNS R56400 Hex Flange Nut, Titanium Gr 5 Industrial Hex Nut Supplier in Mumbai, India.
In well-known, natural acids are much less corrosive than mineral acids including hydrochloric and sulfuric acid. So as the molecular weight of natural acids increases, their corrosively decreases. Formic acid has the bottom molecular weight and is a vulnerable acid. It may be used with formic acid, even though it has a tendency to discolor the answer. Titanium WNR 3.7165 Hex Nuts are unaffected through susceptible bases including ammonium hydroxide, even in excessive concentrations and at excessive temperatures. The identical grades uncovered to more potent bases including sodium hydroxide at excessive concentrations and excessive temperatures will probable enjoy a few etching and cracking. Increasing chromium and nickel contents offer expanded resistance.
Localized corrosion can arise in numerous ways, e.g. pitting corrosion and crevice corrosion. These localized assaults are maximum not unusual within the presence of chloride ions. Higher chloride degrees require extra highly-alloyed steels.Localized corrosion may be hard to expect due to the fact it's miles depending on many factors, consisting of chloride ion awareness. Even whilst chloride answer awareness is known, Ti 6Al/4V Hex Nuts is nevertheless viable for localized corrosion to arise unexpectedly. Chloride ions can grow to be inconsistently focused in sure areas, including in crevices (e.g. beneath gaskets) or on surfaces in vapor areas because of evaporation and condensation.
Material Specification Chart of Titanium Gr 5 Hex Nuts
Size | M3 – M56 | 3/6″ to 2″ | Custom Sizes |
---|---|
Length | 3 mm to 200 mm |
Hex Nuts | UNF, BSW, BSF, METRIC, UNC, or as required |
Standard | DIN : DIN 934, DIN 931, DIN 970, DIN 933 UTS : UNEF, NPT, UNC, UNS, UNF, NPTF ISO : JIS standards, ISO 4033, ISO 4032, ANSI – American National Standards Institute ASME B18.5 ANSI B 28.2.4 1M ANSI B 18.2.4 2M as per defined in ASME B18.2.2 Hex nuts |
Form | Hex, Threading, Square, Round as per Gauge Etc. |
Threads Configuration | ASME B1.1 2A/3A – 2B/3B Inch Unified Threads and B1.13M 6h-6G Metric Coarse Threads |
Certification | Dual Certified As per ASTM & ASME Codes |
Dimensions | DIN 931, 933, 934, 7991, 976, 125, ASME B18.2.1, B18.3 |
Threads | Unless otherwise specified, the threads shall be rolled or cut and tapped horizontally or vertically |
Test Certificate | as per EN 10204 / 3.1 Manufacturer Test Certificate |
Additional Certifications | PED 97/23/EC Certified, Merkblatt AD 2000 W2 Certified |
Production process | M24-M100: hot forging , M2-M24: Cold Froging, for custom-made connecting element machining and CNC |
Head drive | Six-Lobe,Phillips,Phillips/Slot, Slotted etc |
Surface Coating | Ptfe Coated Nuts Phosphate Coating Teflon Coating Zinc Coating Hot Dipped Galvanizing Coating Cadmium Coating Xylon Coating |
Finishing | Coatings & Finishes : Self-Colour, Passivated, Bright Zinc Plated (BZP), Hot Dip Galvanised (HDG), Sherardized, some special one like DACROMET Geometry and Mechanically Applied coating ,Dacroment, nickel plated, anodizing, plated zinc-nickel Zinc (blue, black, yellow, white), black oxide |
Various Types Of Titanium Gr 5 Hex Nuts
- UNS R56400 Hex Jam Nuts
- Titanium Gr 5 Heavy Hex Jam Nuts
- 3.7165 Hex Jam Nuts
- Ti Alloy Gr 5 Hex Jam Nut
- Titanium Alloy Gr 5 Hex Jam Nut
- 3.7165 Heavy Hex Nuts
- Titanium Gr 5 Heavy Hex Nuts
- Ti Alloy Gr 5 Heavy Hex Nut
- Titanium Alloy Gr 5 Heavy Hex Nut
- UNS R56400 Heavy Hex Nuts
- Titanium Alloy Gr 5 Hex Flange Nut
- Titanium Gr 5 Hex Flange Nut
- Ti Alloy Gr 5 Flange Hex Nuts
- 3.7165 Hex Flange Nuts
- UNS R56400 Hex Flange Nut
- Titanium Alloy Gr 5 Slotted Hex Nuts
- Ti Alloy Gr 5 Slotted Hex Nuts
- Titanium Gr 5 Slotted Hex Nut
- 3.7165 Beveled Slotted Hex Nut
- UNS R56400 Slotted Hex Nuts
- UNS R56400 Machine Hex Nuts
- 3.7165 Machine Hex Nuts
- Titanium Alloy Gr 5 Machine Hex Nut
- Titanium Gr 5 Machine Hex Nuts
- Ti Alloy Gr 5 Machine Hex Nut
- Ti Alloy Gr 5 Long Hex Nuts
- UNS R56400 Long Hex Nuts
- Titanium Gr 5 Coupling Hex Nuts
- 3.7165 Hex Coupling Nuts
- Titanium Alloy Gr 5 Long Hex Nuts
Equivalent Grades of Titanium Gr 5 Hex Nuts
STANDARD | UNS | WERKSTOFF NR. |
Titanium Gr 5 | R56400 | 3.7165 |
View Size Table Of Titanium Gr 5 Hex Nuts, We have Global sales network for Titanium Alloy Gr 5 Heavy Hex Nuts, Wide Stockist Of Werkstoff No 3.7165 Hex Head Nuts, Industrial Hex Nuts In India.
Dimensions of Titanium Gr 5 Hex Nuts
Nominal Size |
Basic Major Diameter of Thread |
F | G | H | H1 | Maximum Runout of Bearing Surface to Thread Axis, FIM |
||||||
Width Across Flats |
Width Across Corners |
Thickness Hex Nuts |
Thickness Jam Nuts |
Hex Nuts | Hex Jam Nuts |
|||||||
Min. | Max. | Min. | Max. | Min. | Max. | Min. | Max. | Specified Proof Load |
||||
Up to 150,000 psi |
150,000 psi and Greater |
All Strength Levels |
||||||||||
1/4 | 0.2500 | 0.428 | 0.438 | 0.488 | 0.505 | 0.212 | 0.226 | 0.150 | 0.163 | 0.015 | 0.010 | 0.015 |
5/16 | 0.3125 | 0.489 | 0.500 | 0.557 | 0.577 | 0.258 | 0.273 | 0.180 | 0.195 | 0.016 | 0.011 | 0.016 |
3/8 | 0.3750 | 0.551 | 0.563 | 0.628 | 0.650 | 0.320 | 0.337 | 0.210 | 0.227 | 0.017 | 0.012 | 0.017 |
7/16 | 0.4375 | 0.675 | 0.688 | 0.768 | 0.794 | 0.365 | 0.385 | 0.240 | 0.260 | 0.018 | 0.013 | 0.018 |
1/2 | 0.5000 | 0.736 | 0.750 | 0.840 | 0.866 | 0.427 | 0.448 | 0.302 | 0.323 | 0.019 | 0.014 | 0.019 |
9/16 | 0.5625 | 0.861 | 0.875 | 0.982 | 1.010 | 0.473 | 0.496 | 0.301 | 0.324 | 0.020 | 0.015 | 0.020 |
5/8 | 0.6250 | 0.922 | 0.938 | 1.051 | 1.083 | 0.535 | 0.559 | 0.363 | 0.387 | 0.021 | 0.016 | 0.021 |
3/4 | 0.7500 | 1.088 | 1.125 | 1.240 | 1.299 | 0.617 | 0.665 | 0.398 | 0.446 | 0.023 | 0.018 | 0.023 |
7/8 | 0.8750 | 1.269 | 1.312 | 1.447 | 1.516 | 0.724 | 0.776 | 0.458 | 0.510 | 0.025 | 0.020 | 0.025 |
1 | 1.0000 | 1.450 | 1.500 | 1.653 | 1.732 | 0.831 | 0.887 | 0.519 | 0.575 | 0.027 | 0.022 | 0.027 |
1-1/8 | 1.1250 | 1.631 | 1.688 | 1.859 | 1.949 | 0.939 | 0.999 | 0.579 | 0.639 | 0.030 | 0.025 | 0.030 |
1-1/4 | 1.2500 | 1.812 | 1.875 | 2.066 | 2.165 | 1.030 | 1.094 | 0.687 | 0.751 | 0.033 | 0.028 | 0.033 |
1-3/8 | 1.3750 | 1.994 | 2.062 | 2.273 | 2.382 | 1.138 | 1.206 | 0.747 | 0.815 | 0.036 | 0.031 | 0.036 |
1-1/2 | 1.5000 | 2.175 | 2.250 | 2.480 | 2.598 | 1.245 | 1.317 | 0.808 | 0.880 | 0.039 | 0.034 | 0.039 |
1-5/8 | 1.6250 | 2.35 | 2.43 | 2.679 | 2.805 | 1.364 | 1.416 | 0.868 | 0.944 | 0.044 | 0.038 | 0.044 |
1-3/4 | 1.7500 | 2.538 | 2.625 | 2.893 | 3.031 | 1.460 | 1.540 | 0.929 | 1.009 | 0.048 | 0.041 | 0.048 |
1-7/8 | 1.8750 | 2.722 | 2.813 | 3.103 | 3.247 | 1.567 | 1.651 | 0.989 | 1.073 | 0.051 | 0.044 | 0.051 |
2 | 2.0000 | 2.900 | 3.000 | 3.306 | 3.464 | 1.675 | 1.763 | 1.050 | 1.138 | 0.055 | 0.047 | 0.055 |
2-1/4 | 2.2500 | 3.263 | 3.375 | 3.719 | 3.897 | 1.890 | 1.986 | 1.155 | 1.267 | 0.061 | 0.052 | 0.061 |
2-1/2 | 2.5000 | 3.625 | 3.750 | 4.133 | 4.330 | 2.105 | 2.209 | 1.401 | 1.427 | 0.068 | 0.058 | 0.068 |
2-3/4 | 2.7500 | 3.998 | 4.125 | 4.546 | 4.763 | 2.319 | 2.431 | 1.522 | 1.556 | 0.074 | 0.064 | 0.074 |
3 | 3.0000 | 4.350 | 4.500 | 4.959 | 5.196 | 2.534 | 2.654 | 1.643 | 1.685 | 0.081 | 0.070 | 0.081 |
3-1/4 | 3.2500 | 4.713 | 4.875 | 5.373 | 5.629 | 2.749 | 2.877 | 1.748 | 1.814 | 0.087 | 0.075 | 0.087 |
3-1/2 | 3.5000 | 5.075 | 5.250 | 5.786 | 6.062 | 2.964 | 3.100 | 1.870 | 1.943 | 0.094 | 0.081 | 0.094 |
3-3/4 | 3.7500 | 5.438 | 5.625 | 6.199 | 6.495 | 3.178 | 3.322 | 1.990 | 2.072 | 0.100 | 0.087 | 0.100 |
4 | 4.0000 | 5.800 | 6.000 | 6.612 | 6.928 | 3.393 | 3.545 | 2.112 | 2.201 | 0.107 | 0.093 | 0.107 |
Dimensions of Titanium Gr 5 Heavy Hex Nuts & Heavy Hex Jam Nuts
Nominal Size | Basic Major Diameter of Thread |
F | G | H | H1 | Maximum Runout of Bearing Surface to Thread Axis, FIM |
|||||||||
Width Across Flats | Width Across Corners |
Thickness Heavy Hex Nuts |
Thickness Heavy Hex Jam Nuts |
Heavy Hex Nuts | Heavy Hex Jam Nuts |
||||||||||
Specified Proof Load | |||||||||||||||
Basic | Min. | Max. | Min. | Max. | Basic | Min. | Max. | Basic | Min. | Max. | Up to 150,000 psi |
150,000 psi and Greater |
All Strength Levels |
||
1/4 | 0.2500 | 1/2 | 0.488 | 0.500 | 0.556 | 0.577 | 15/64 | 0.218 | 0.250 | 11/64 | 0.156 | 0.188 | 0.017 | 0.011 | 0.017 |
5/16 | 0.3125 | 9/16 | 0.546 | 0.562 | 0.622 | 0.650 | 19/64 | 0.280 | 0.314 | 13/64 | 0.186 | 0.220 | 0.020 | 0.012 | 0.020 |
3/8 | 0.3750 | 11/16 | 0.669 | 0.688 | 0.763 | 0.794 | 23/64 | 0.341 | 0.377 | 15/64 | 0.216 | 0.252 | 0.021 | 0.014 | 0.021 |
7/16 | 0.4375 | 3/4 | 0.728 | 0.750 | 0.830 | 0.866 | 27/64 | 0.403 | 0.441 | 17/64 | 0.247 | 0.285 | 0.022 | 0.015 | 0.022 |
1/2 | 0.5000 | 7/8 | 0.850 | 0.875 | 0.969 | 1.010 | 31/64 | 0.464 | 0.504 | 19/64 | 0.277 | 0.317 | 0.023 | 0.016 | 0.023 |
9/16 | 0.5625 | 15/16 | 0.909 | 0.938 | 1.037 | 1.083 | 35/64 | 0.526 | 0.568 | 21/64 | 0.307 | 0.349 | 0.024 | 0.017 | 0.024 |
5/16 | 0.6250 | 1-1/16 | 1.031 | 1.062 | 1.175 | 1.227 | 39/64 | 0.587 | 0.631 | 23/64 | 0.337 | 0.381 | 0.025 | 0.018 | 0.025 |
3/4 | 0.7500 | 1-1/4 | 1.212 | 1.250 | 1.382 | 1.443 | 47/64 | 0.710 | 0.758 | 27/64 | 0.398 | 0.446 | 0.027 | 0.020 | 0.027 |
7/8 | 0.8750 | 1-7/16 | 1.394 | 1.438 | 1.589 | 1.660 | 55/64 | 0.833 | 0.885 | 31/64 | 0.458 | 0.510 | 0.029 | 0.022 | 0.029 |
1 | 1.0000 | 1-5/8 | 1.575 | 1.625 | 1.796 | 1.876 | 63/64 | 0.956 | 1.012 | 35/64 | 0.519 | 0.575 | 0.031 | 0.024 | 0.031 |
1-1/8 | 1.1250 | 1-13/16 | 1.756 | 1.812 | 2.002 | 2.093 | 1-7/64 | 1.079 | 1.139 | 39/64 | 0.579 | 0.639 | 0.033 | 0.027 | 0.033 |
1-1/4 | 1.2500 | 2 | 1.938 | 2.000 | 2.209 | 2.309 | 1-7/32 | 1.187 | 1.251 | 23/32 | 0.687 | 0.751 | 0.035 | 0.030 | 0.035 |
1-3/8 | 1.3750 | 2-3/16 | 2.119 | 2.188 | 2.416 | 2.526 | 1-11/32 | 1.310 | 1.378 | 25/32 | 0.747 | 0.815 | 0.038 | 0.033 | 0.038 |
1-1/2 | 1.5000 | 2-3/8 | 2.300 | 2.375 | 2.622 | 2.742 | 1-15/32 | 1.433 | 1.505 | 27/32 | 0.808 | 0.880 | 0.041 | 0.036 | 0.041 |
1-5/8 | 1.6250 | 2-9/16 | 2.481 | 2.562 | 2.828 | 2.959 | 1-19/32 | 1.556 | 1.632 | 29/32 | 0.868 | 0.944 | 0.044 | 0.038 | 0.044 |
1-3/4 | 1.7500 | 2-3/4 | 2.662 | 2.750 | 3.035 | 3.175 | 1-23/32 | 1.679 | 1.759 | 31/32 | 0.929 | 1.009 | 0.048 | 0.041 | 0.048 |
1-7/8 | 1.8750 | 2-15/16 | 2.844 | 2.938 | 3.242 | 3.392 | 1-27/32 | 1.802 | 1.886 | 1-1/32 | 0.989 | 1.073 | 0.051 | 0.044 | 0.051 |
2 | 2.0000 | 3-1/8 | 3.025 | 3.125 | 3.449 | 3.608 | 1-31/32 | 1.925 | 2.013 | 1-3/32 | 1.050 | 1.138 | 0.055 | 0.047 | 0.055 |
2-1/4 | 2.2500 | 3-1/2 | 3.388 | 3.500 | 3.862 | 4.041 | 2-13/64 | 2.155 | 2.251 | 1-13/64 | 1.155 | 1.251 | 0.061 | 0.052 | 0.061 |
2-1/2 | 2.5000 | 3-7/8 | 3.750 | 3.875 | 4.275 | 4.474 | 2-29/64 | 2.401 | 2.505 | 1-29/64 | 1.401 | 1.505 | 0.068 | 0.058 | 0.068 |
2-3/4 | 2.7500 | 4-1/4 | 4.112 | 4.250 | 4.688 | 4.907 | 2-45/64 | 2.647 | 2.759 | 1-37/64 | 1.522 | 1.634 | 0.074 | 0.064 | 0.074 |
3 | 3.0000 | 4-5/8 | 4.475 | 4.625 | 5.102 | 5.340 | 2-61/64 | 2.893 | 3.013 | 1-45/64 | 1.643 | 1.763 | 0.081 | 0.070 | 0.081 |
3-1/4 | 3.2500 | 5 | 4.838 | 5.000 | 5.515 | 5.774 | 3-3/16 | 3.124 | 3.252 | 1-13/16 | 1.748 | 1.876 | 0.087 | 0.075 | 0.087 |
3-1/4 | 3.5000 | 5-3/8 | 5.200 | 5.375 | 5.928 | 6.207 | 3-7/16 | 3.370 | 3.506 | 1-15/16 | 1.870 | 2.006 | 0.094 | 0.081 | 0.094 |
3-3/4 | 3.7500 | 5-3/4 | 5.562 | 5.750 | 6.341 | 6.640 | 3-11/16 | 3.616 | 3.760 | 2-1/16 | 1.990 | 2.134 | 0.100 | 0.087 | 0.100 |
4 | 4.0000 | 6-1/4 | 5.925 | 6.125 | 6.755 | 7.073 | 3-15/16 | 3.862 | 4.014 | 2-3/16 | 2.112 | 2.264 | 0.107 | 0.093 | 0.107 |
Ready Stock Titanium Gr 5 Hex Nuts
- Titanium Gr 5 Flanged Hex Nuts Stockholder
- Titanium Gr 5 Hex Jam Nuts
- Titanium Gr 5 Hexagonal Nylon Lock Nut
- Titanium Gr 5 Coupling Nuts
- Ti Alloy Gr 5 Hex Socket Nut
- Titanium Alloy Gr 5 Heavy Hex Jam Nuts
- Ti Alloy Gr 5 Slotted Hex Nuts
- Titanium Gr 5 Alloy Hex Sleeve Nuts
- Titanium Alloy Gr 5 Heavy Hexagon Nuts
- Titanium Gr 5 Hex Nut Manufacturer
- Ti Alloy Gr 5 Nylon Insert Lock Nuts
- Titanium Alloy Gr 5 Heavy Hex Nuts
- 3.7165 Thin Hex Nuts
- Ti Alloy Gr 5 Hexagon Nuts
- Titanium Gr 5 Industrial Hex Nuts
- Ti Alloy Gr 5 Heavy Hex Nuts
- Titanium Alloy Gr 5 Hex Flange Nut
- Ti Alloy Gr 5 Heavy Hex Nuts Distributor
- Titanium Alloy Gr 5 Self Locking Hex Nuts
- Ti Alloy Gr 5 Hex Nuts
- Titanium Gr 5 Hex Head Nut
- UNS R56400 Hex Nuts
- Titanium Alloy Gr 5 Slotted Hex Nuts
- Ti Alloy Gr 5 Hex Round Nut
- Titanium Gr 5 Serrated Hex Flange Nut
- Ti Alloy Gr 5 Hexagonal Nylon Lock Nut
- Titanium Gr 5 Hex Machine Nut Stockist
- Titanium Gr 5 Hexagon Nut Supplier in Mumbai
- Titanium Gr 5 Machine Hex Nuts
- Titanium Gr 5 Finished Hex Nuts
- Titanium Gr 5 Hex Nuts Manufacturer
- Ti Alloy Gr 5 Heavy Hex Nuts
- Titanium Gr 5 Industrial Hex Nuts Exporter
- Ti Alloy Gr 5 Long Hex Nut
- DIN 3.7165 Hex Nuts
- Ti Alloy Gr 5 Semi-Finished Hex Nuts
Titanium Alloy Gr 5 Hex Nuts Chemical Composition
Grade | N | C | H | Fe | O | Al | V |
Ti Grade 5 | 0.05 max | 0.10 max | 0.01 max | 0.40 max | 0.20 max | 5.50-6.75 | 3.50-4.50 |
Titanium Gr 5 Hex Nuts Mechanical Properties
Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
Titanium Gr 5 | 4.43 g/cm3 | 1632 °C (2970 °F) | Psi – 138000 , MPa – 950 | Psi – 128000 , MPa – 880 | 14 % |
